2015 LEXUS LS600H seat memory

TABLE OF CONTENTS2
LS600hL_U(OM50E41U)For your information ................................... 8
Reading this manual................................... 14
How to search ..............................................15
Pictorial index ............................................... 16
1-1. For safe use
Before driving................................. 32
For safety drive............................... 34
Seat belts .......................................... 36
SRS airbags ......................................42
Front passenger occupant classification system.................. 55
Safety information for children ..................................... 61
Child restraint systems ................62
Installing child restraints............. 66
Exhaust gas precautions .............75
1-2. Hybrid system Hybrid system features................ 76
Hybrid system precautions.........81
1-3. Theft deterrent system Immobilizer system ......................88
Alarm ................................................. 90 2. Instrument cluster
Warning lights and indicators....................................... 94
Gauges and meters ..................... 99
Multi-information display ........ 105
Energy monitor/ consumption screen ................. 112
3-1. Key information Keys ...................................................120
3-2. Opening, closing and locking the doors and
trunk
Smart access system with push-button start ......................125
Wireless remote control ............ 141
Doors ................................................ 145
Trunk.................................................. 149
3-3. Adjusting the seats Front seats.......................................156
Power rear seat............................. 162
Driving position memory.......... 172
Rear seat position memory......................................... 177
Head restraints ............................. 179
3-4. Adjusting the steering wheel and mirrors
Steering wheel ..............................182
Inside rear view mirror ............. 183
Outside rear view mirrors .......................................... 185
1For safety and security
2Instrument cluster
3Operation of
each component

26Pictorial index
LS600hL_U(OM50E41U)
■Rear interior (5-seat models)
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 179
Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 361
Personal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 362
Assist grips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 402
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 376
Coat hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 4 0 1
Seat position memory switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 1771
2
3
4
5
6

28Pictorial index
LS600hL_U(OM50E41U)
■Rear interior (4-seat models)
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 179
Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 361
Personal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 362
Assist grips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 402
Rear seat entertainment system display
*2
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 376
Coat hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 4 0 1
Seat position memory switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 177
1
2
3
4
5
6
7

381-1. For safe use
LS600hL_U(OM50E41U)
If the system determines that a collision is unavoidable, the front seat belts
will retract before the collision. ( P. 2 9 6 )
■Child seat belt usage
The seat belts of your vehicle were princi pally designed for persons of adult size.
●Use a child restraint system appropriate for the child, until the child becomes large
enough to properly wear the vehicle’s seat belt. ( P. 6 2 )
●When the child becomes large enough to properly wear the vehicle’s seat belt, fol-
low the instructions regarding seat belt usage. ( P. 3 6 )
■Automatic adjustment of the seat belt shoulder anchor height (front seats)
A desired seat belt shoulder anchor height can be entered to memory and recalled
automatically by the driving position memory and seat position memory. (P. 1 7 2 )
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also lock if
you lean forward too quickly. A slow, easy motion will allow the belt to extend so that
you can move around fully.
■Automatic locking retractor (ALR)
When a passenger’s shoulder belt is comp letely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is used
to hold the child restraint system (CRS) firmly. To free the belt again, fully retract the
belt and then pull the belt out once more. ( P. 66)
■Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for the
first collision, but will not activate for the second or subsequent collisions.
■Seat belt extender
Pre-collision seat belts (front sea ts of vehicles with pre-collision
system)
If your seat belts cann ot be fastened securely
because they are not long enough, a person-
alized seat belt extender is available from
your Lexus dealer free of charge.

119
Operation of
each component
3
LS600hL_U(OM50E41U) 3-1. Key information
Keys .................................................. 120
3-2. Opening, closing and locking the doors and
trunk
Smart access system with push-button start...................... 125
Wireless remote control ............ 141
Doors ................................................145
Trunk ..................................................149
3-3. Adjusting the seats Front seats ...................................... 156
Power rear seat .............................162
Driving position memory .......... 172
Rear seat position memory......................................... 177
Head restraints .............................179
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................. 182
Inside rear view mirror.............. 183
Outside rear view mirrors .......................................... 185
3-5. Opening, closing the windows and moon roof
Power windows ............................ 189
Moon roof ...................................... 192

1723-3. Adjusting the seats
LS600hL_U(OM50E41U)
Your preferred driving position (the position of the driver's seat, steering
wheel, outside rear view mirrors and height of seat belt shoulder anchor)
can be recorded and recalled by pressing a switch.
Three different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the power switch to ON mode.
Adjust the driver’s seat, steering wheel, outside rear view mirrors and
seat belt shoulder anchor height to the desired positions.
Press the “SET” switch, then
within 3 seconds press switch
“1”, “2” or “3” until the buzzer
sounds.
If the selected switch has already
been preset, the previously
recorded position will be overwrit-
ten.
To record the position of the front pa ssenger’s seat, adjust the front pas-
senger’s seat to the desired posi tion and perform step using the
switches on the front passenger’s side.
Driving position memory
This feature automatically adjusts the front seats, steering wheel, out-
side rear view mirrors and height of seat belt shoulder anchor to suit
your preferences.
Driving position memory
1
2
3
4
4

1733-3. Adjusting the seats
3
Operation of each component
LS600hL_U(OM50E41U)
■Recall procedureCheck that the shift lever is in P.
Turn the power switch to ON mode.
Press one of the switches for
the driving position you want
to recall until the buzzer
sounds.
■When you want to stop the position recall operation part-way through
Perform any of the following operations:
●Press the “SET” switch.
●Press switch “1”, “2” or “3”.
●Operate any of the seat adju stment switches (only cancels seat position recall).
●Operate the tilt and telescopic steering co ntrol switch (only cancels steering wheel
position recall).
●Operate the seat belt shoulder anchor he ight adjusting switch (only cancels height
of seat belt shoulder anchor recall).
■Front passenger's seat position recall limitations (4-seat models)
When retractable table or ottoman is used, rearward memories cannot be recalled.
■Operating the driving position memory after turning the power switch off
Driver's seat:
Recorded driving positions (except the steering wheel position) can be recalled up
to 180 seconds after the driver’s door is opened and up to 60 seconds after it is
closed again.
Front passenger's seat:
Recorded seat positions can be recalled up to 180 seconds after the front passen-
ger's door is opened.
■In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is operated in
the same direction, the recorded position ma y be slightly different when it is recalled.
1
2
3

1743-3. Adjusting the seats
LS600hL_U(OM50E41U)
Each electronic key (including a card key) can be registered to recall your
preferred driving position.
■Registering procedure
Record your driving position to switch “1”, “2” or “3” before performing
the following:
Using the wireless remote control
Turn the power switch off and close the driver's door.
While pressing the desired
switch (“1”, “2” or “3”), press on the wireless remote
control until the buzzer
sounds.
To prevent unintended triggering of the alarm, open and close a door
once after a driving position has be en recorded. (If a door is not
opened within 30 seconds after is pr essed, the doors will be locked
again and the alarm will automatically be set.)
In case that the alarm is triggere d, immediately stop the alarm.
( P. 9 0 )
Memory recall function (driver's side only)
1
2
