2015 Lexus GS450h Opening, closing and locking the doors and trunk / LEXUS 2015 GS450H OWNERS MANUAL (OM30E26U)

GS450h_OM_OM30E26U_(U)
3295-1. Remote Touch screen
5
Interior features
Press the “MENU” button on the Remote Touch to display the “Menu”
screen.
The display may differ depending on the type of the system.
12.3-inch display: When an interruption sc reen is being displayed on the side dis-
play, the “Menu” screen will be shown on the main display.
“Menu” screen
For 8-inch displayFor 12.3-inch display
SwitchFunction
Select to display the air conditioning control screen. ( P. 3 3 5 )
Select to display the “LEXUS App Suite” screen.*1, 2
Select to display the “Information” screen.*1
Select to display the radio control screen.*1
Select to display the media control screen.*1
Select to display the hands-free operation screen.*1
Select to display the “Setup” screen.*1

3305-1. Remote Touch screen
GS450h_OM_OM30E26U_(U)
*1: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’SMANUAL”.
*2:If equipped
“Display”Select to adjust the contrast an d brightness of the screens, turn
the screen off, etc.
*1
Select to display the compass mode screen (8-inch display) or the
“Destination” screen (12.3-inch display).
*1
SwitchFunction

GS450h_OM_OM30E26U_(U)
3315-1. Remote Touch screen
5
Interior features
The 12.3-inch display has a display area which is 1.5 times wider than that
of the 8-inch display.
■Full screen display
The initial screen and “Menu” screen fill the entirety of the display area.
12.3-inch display operation

3325-1. Remote Touch screen
GS450h_OM_OM30E26U_(U)
■Split-screen display
Different information can be displayed on the left and right of the
screen. For example, air conditio ning system or audio screens can be
displayed and operated while the fuel consumption information screen
is being displayed. The large screen on the left of the display is called
the main display, and the small screen to the right is ca lled the side dis-
play.

GS450h_OM_OM30E26U_(U)
3335-1. Remote Touch screen
5
Interior features
For details of the functions and operation of the main display, refer to the
respective section.
■Selecting the operation screen
When selecting the side display, move the Remote Touch knob to the
right until is displayed at the boundary between the main display
and the side display, and then move it further to the right. When select-
ing the main display, move the Remote Touch knob to the left until is
displayed at the boundary between the main display and the side dis-
play, and then move it further to the left.
12.3-inch display function

3345-1. Remote Touch screen
GS450h_OM_OM30E26U_(U)
■Display the side display
Basic screens
The following functions can be displayed and operated on the side dis-
play.
Audio
*
Air conditioning system
(P. 340)
Vehicle information
( P. 116)
Interruption screens
Each of the following screens is di splayed automatically in accordance
with conditions.
•
Intuitive parking assist* (if equipped)
•Phone
*
• Destination Assist*
• Driving mode ( P. 2 8 1 )
• Lexus night view (if equipped) ( P. 313)
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
■To display on the main display
Detailed information that is not shown on the side display can be set to
display on the main display.
Select , or .
1
2
3

335
GS450h_OM_OM30E26U_(U)5-2. Using the air conditio ning system and defogger
5
Interior features
Front automatic air conditioning system
Air outlets and fan speed are automatica lly adjusted according to the
temperature setting.
Press the “MENU” button on the Remote Touch, then select to
display the air conditioning operation screen.
Vehicles with a 12.3-inch display: The air conditioning system can be
displayed and operated on the side display. ( P. 3 3 1 )
The display and button positions will di ffer depending on the type of the
system.

336
GS450h_OM_OM30E26U_(U)
5-2. Using the air conditioning system and defogger
■Operation screen and control panel
Without rear air conditioning system
