2015 INFINITI QX50 Quick Reference Guide

2015 Infiniti QX50Quick Reference Guide
1923534_15c_Infiniti_QX50_QRG_122314.indd 212/23/14 1:04 PM

*See your Owner’s Manual for information.
Behind
steering wheel Behind
steering wheel
On
steering column
Behind
steering wheel
1 INSTRUMENT BRIGHTNESS CONTROL SWITCH*
2
VEHICLE INFORMATION DISPLAY
3 TRIP COMPUTER SWITCHES
4 LOW TIRE PRESSURE WARNING LIGHT
5
HEADLIGHT AND TURN SIGNAL CONTROL
6 WINDSHIELD WIPER AND WASHER SWITCH
7 STEERING WHEEL SWITCHES FOR
AUDIO* / BLUETOOTH® / NAVIGATION
8 INTELLIGENT CRUISE CONTROL BUTTONS
9 PUSH BUTTON IGNITION
10 WARNING SYSTEMS SWITCH*
11 INTELLIGENT BRAKE ASSIST (IBA)
OFF SWITCH*
12 DYNAMIC DRIVER ASSISTANCE SWITCH*
13 INTELLIGENT KEY PORT
14 TILT / TELESCOPIC STEERING
WHEEL SWITCH*
15 HOOD RELEASE*

16 VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH*
17 CONTROL PANEL DISPLAY SCREEN*
18 AUDIO SYSTEM
19 AUTOMATIC CLIMATE CONTROLS
20 FRONT PASSENGER AIR BAG
STATUS LIGHT*
13
4
56
789
101112
1314
1516
17
18
19
20
2
1923534_15c_Infiniti_QX50_QRG_122314.indd 312/23/14 1:04 PM

table of contents
new system features
Around View ® Monitor (AVM) (if so equipped) ........................2
Blind Spot Warning (BSW) System (if so equipped) ................... 4
Lane Departure Prevention (LDP) System (if so equipped) ..............4
essential information
Tire Pressure Monitoring System (TPMS) ............................ 5
Loose Fuel Cap ................................................. 5
Fuel-filler Door ................................................. 6
Front Armrest/Center Console Storage Box .......................... 6
Clock Set/Adjustment (Type A) .................................... 6
first drive features
INFINITI Intelligent Key System ................................... 7
Liftgate Release ................................................ 8
Power Seat Adjustments ......................................... 8
Automatic Drive Positioner (if so equipped) ......................... 9
Outside Mirror Control Switch ..................................... 9
Starting/Stopping the Engine .................................... 10
Headlight Control Switch ........................................ 10
Windshield Wiper and Washer Switch ............................. 11
Automatic Climate Controls ...................................... 12
FM/AM/SiriusXM
® Satellite Radio with CD/DVD Player
(with Navigation System - if so equipped) ..........................14
USB/iPod
® Interface ............................................... 15
Conventional (Fixed Speed) Cruise Control ......................... 15
Intelligent Cruise Control (ICC) System (if so equipped) ..............16
Power Outlets ................................................. 17
system guide
Trip Computer ..................................................... 18
Bluetooth® Hands-free Phone System .............................. 18
System Operating Tips ....................................... 18
Bluetooth
® System with Navigation (if so equipped) ................. 19
Bluetooth® System without Navigation (if so equipped) .............. 21
Navigation System (if so equipped) ............................... 23
DVD Player ................................................... 24
HomeLink
® Universal Transceiver (if so equipped) ...................25
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/
2015/qx50
or snap this barcode with an
appropriate barcode reader.
Please see your Owner’s Manual for important safety information
and system operation limitations.
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety — Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice
recognition systems (section 4)” and the “Starting and driving (section 5)” of
your Owner’s Manual.
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
1923534_15c_Infiniti_QX50_QRG_122314.indd 412/23/14 1:04 PM

2
new system features
When the shift lever is in the R (REVERSE) position and the CAMERA button
1 is pressed,
the following views will display in order:
Rear view & bird’s-eye view
Press
PressPress Rear view & front-side view
Rear wide view
Around View® Monitor (AVM) (if so equipped)

With the ignition switch in the ON position, the
Around View Monitor is activated by pressing the CAMERA
button
1, located on the control panel, or by moving the
shift lever to the R (REVERSE) position. The control panel
displays various views of the position of the vehicle.

When the shift lever is in the P (PARK), N (NEUTRAL) or D
(DRIVE) position and the CAMERA button
1 is pressed,
the following views will display in order:
Start from any Control Panel screen
Press
Press
Press
Press
Front wide view Front view & bird’s-eye viewFront view & front-side view
1
1923534_15c_Infiniti_QX50_QRG_122314.indd 212/23/14 1:04 PM

3
new system features
2
3
The colored guide lines on the display screen indicate vehicle width and\
approximate
distances to objects with reference to the vehicle body line.
• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft \
(3 m).

There are some areas where the system will not show objects.
• When in the front or the rear view display, an
object below the bumper or on the ground may
not be viewed

2.
• When in the bird’s-eye view, a tall object near
the seam of the camera viewing areas

3
will not appear in the monitor.

The distance between objects viewed on the
AVM differs from the actual distance.

Objects in the bird’s-eye view will appear further
than the actual distance.
For more information, refer to the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
1923534_15c_Infiniti_QX50_QRG_122314.indd 312/23/14 1:04 PM

4
Blind Spot Warning (BSW) System (if so equipped)
The control switch is located on the left side of the
instrument panel.

The system automatically turns on when the
engine is started and the indicator light on the
switch
1 illuminates.

The BSW indicator lights
2, located next to the

outside mirrors, will activate when the BSW system
detects a vehicle in the detection zone.

If the turn signal is activated in the direction of a
detected vehicle, a chime sounds twice and the BSW
indicator light will flash.

To cancel the system, push the control switch and the
warning systems ON indicator will extinguish.
For more information, refer to the “Instruments and controls (section 2)” and
the “Starting and driving (section 5)” of your Owner’s Manual.
new system features
1
2
Lane Departure Prevention (LDP) System
(if so equipped)
This system will help you return the vehicle to the
center of the traveling lane by applying brake control
to the left or right wheels individually (for a short
period of time).
For more information, refer to the “Starting and driving (section 5)” of your
Owner’s Manual.
1923534_15c_Infiniti_QX50_QRG_122314.indd 412/23/14 1:04 PM

5
essential information
Tire Pressure Monitoring System (TPMS)
A CHECK TIRE PRESSURE warning message will
appear in the vehicle information display
1
and the low tire pressure warning light 2 will

illuminate when one or more tires are low in
pressure and air is needed.
• The tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.

After the tire pressures are adjusted, drive the vehicle
at speeds above 16 MPH (25 km/h). The CHECK TIRE
PRESSURE warning message and the low tire pressure
warning light will extinguish.

When the low tire pressure warning light flashes for 1 minute and then r\
emains on, the TPMS
is not functioning properly. Have the system checked by an INFINITI reta\
iler.

Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and
the outside temperature. Low outside temperature can lower the temperatu\
re of the air
inside the tire, which can cause a lower tire inflation pressure. This m\
ay cause the low tire
pressure warning light to illuminate. If the warning light illuminates, \
check the tire pressure
in your tires.
• Check the tire pressure (including the spare tire) often and always pr\
ior to long distance trips.

The Tire and Loading Information label contains valuable information. Pl\
ease refer to
“Technical and consumer information (section 9)”, in your Owner’\
s Manual for the location
of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the “Maintenance
and do-it-yourself (section 8)” of your Owner’s Manual.
1
2
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear in
the vehicle information display
1 when the

fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click
is heard.

The warning message will extinguish when the vehicle
detects the fuel-filler cap is properly tightened and the
reset button
2 is pressed.

If the cap is not properly tightened, the Malfunction
Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments (section 3)” of
your Owner’s Manual.
1
2
1923534_15c_Infiniti_QX50_QRG_122314.indd 512/23/14 1:04 PM

6
essential information
Front Armrest/Center Console Storage Box
To access the center console storage box, push
the button
1.
For more information, refer to the “Instruments and controls (section 2)”
of your Owner’s Manual.
1
Fuel-fi ller Door
Unlock the fuel-filler door using one of the following
operations then push and release the left side of the
door to open.


Push either door handle request switch or the liftgate
request switch while carrying the INFINITI Intelligent
Key with you.

Press the UNLOCK button on the Intelligent Key.

Push the power door lock switch to the UNLOCK position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Clock Set/Adjustment (Type A)
DIGITAL CLOCK ADJUSTMENT

To adjust the time and the appearance of the clock
on the display:
1. Press the SETTING button on the control panel.
2. Touch the “Others” key.
3. Touch the “Clock” key.

The following settings can be adjusted:
• On-screen Clock: The clock in the upper right corner of the display can be turned ON or O\
FF.
• Clock Format (24h): The clock can be set to 12 hours or 24 hours.
• Offset (hour): The time can be adjusted by increasing or decreasing per hour.
• Offset (min): The time can be adjusted by increasing or decreasing per minute.
• Daylight Savings Time: The application of daylight savings time can be turned ON or OFF.
• Time Zone: Adjust the time zone. Choose a time zone from the available list.

Press the BACK button to return to the previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
1923534_15c_Infiniti_QX50_QRG_122314.indd 612/23/14 1:04 PM
