2015 INFINITI Q60 COUPE Quick Reference Guide

Quick Reference Guide2015 Infiniti Q60
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 29/15/14 1:25 PM

10
111213
15
16
17
18
19
20
212122
1
3456
2
*See your Owner’s Manual for information.
1 INSTRUMENT BRIGHTNESS CONTROL*
2 TRIP COMPUTER SWITCHES
3 HEADLIGHT AND TURN SIGNAL CONTROL
4 LOW TIRE PRESSURE WARNING LIGHT
5 VEHICLE INFORMATION DISPLAY
6 WINDSHIELD WIPER AND WASHER SWITCH
7 TRIP A/B RESET BUTTON*
8 STEERING WHEEL SWITCHES FOR
AUDIO*/BLUETOOTH®
9 CRUISE CONTROL
10 PUSH BUTTON IGNITION SWITCH
11 VEHICLE DYNAMIC CONTROL (VDC) OFF SWITCH*
12 TRUNK RELEASE SWITCH
13 REAR SONAR SYSTEM SWITCH*
14 TILT AND TELESCOPIC STEERING COLUMN*
15 INTELLIGENT KEY PORT
16 HOOD RELEASE*
17 CONTROL PANEL DISPLAY
18 AUDIO SYSTEM
19 AUTOMATIC CLIMATE CONTROLS
20 FRONT PASSENGER AIR BAG STATUS LIGHT*
21 CLIMATE CONTROLLED SEAT SWITCHES*
22 HARD TOP OPEN/CLOSE SWITCH
(CONVERTIBLE MODELS)
Behind
steering wheel Behind
steering wheel
Behind
steering wheel
89
7
Behind
steering wheel14
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 39/15/14 1:25 PM

Please see your Owner’s Manual for important safety information
and system operation limitations.
•
A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•


Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the

“Safety – Seats, seat belts and
supplemental restraint system (section 1)”, “Monitor, climate,
audio, phone and voice recognition systems (section 4)” and
“Starting and driving (section 5)” of your Owner’s Manual.
table of contents
new system features NavTraffic and NavWeather (if so equipped) .........................2
essential information Tire Pressure Monitoring System (TPMS) ............................3 Loose Fuel Cap.................................................3 Fuel-filler Door

.................................................
4 Automatic Power Windows

.......................................
4 Accessing the Front Cup Holders

..................................
4 Clock Set/Adjustment

...........................................
5
first drive features INFINITI Intelligent Key System...................................6 Trunk Lid Release...............................................7 Seat Adjustments...............................................7 Automatic Drive Positioner (if so equipped)
.........................
8 Seat Belt Guide (Convertible models)

..............................
8 Passenger Rear Seat Entry/Exit....................................8 Outside Mirror Control Switch.....................................9 Starting/Stopping the Engine

.....................................
9


Headlight Control Switch........................................10 Windshield Wiper and Washer Switch

.............................
11


Automatic Climate Controls......................................11 FM/AM/SiriusXM® Satellite Radio with CD/DVD Player (with Navigation System) (if so equipped)..........................13 USB (Universal Serial Bus) Connection Port/iPod® Interface...........14 Conventional (Fixed Speed) Cruise Control
.........................14 Intelligent Cruise Control (ICC) System (if so equipped) ..............15


Opening/Closing the Hard Top (Convertible models)

.................
16
system guide Trip Computer.................................................17 Bluetooth® Hands-free Phone System .............................17

System Operating Tips........................................17

Bluetooth
® System with Navigation (if so equipped) .................18
Bluetooth® System without Navigation (if so equipped) ..............20 Navigation System (if so equipped) ...............................21 DVD Player (if so equipped)......................................22

HomeLink
® Universal Transceiver.................................23
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2015/q60 or snap this barcode with an appropriate barcode reader.
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 49/15/14 1:25 PM

2
new system features
NavTraffic* and NavWeather* (if so equipped)
Your vehicle’s Navigation System is equipped with
NavTraffic and NavWeather capabilities.
NavTraffic enables your vehicle’s Navigation System
to display real-time traffic conditions, such as
accidents or road construction, and may provide a
detour to help avoid congestion.
NavWeather tracks nationwide weather
information, provides real-time weather reports
and automatically alerts you to severe weather
conditions around the current vehicle location.
*These features, SiriusXM® Satellite Radio, NavTraffic and
NavWeather require an active subscription. Multiple subscriptions
may be necessary to activate the various features.
For more information, refer to the “Monitor, climate audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 29/15/14 1:25 PM

3
Loose Fuel Cap
A LOOSE FUEL CAP
warning message will appear in



the vehicle information display 1 when the fuel-filler



cap is not tightened correctly.


To tighten, turn the cap clockwise until a single click



is heard.
The warning message will disappear when the vehicle



detects the fuel-filler cap is properly tightened and the




reset button 2 is pressed for about 1 second.
If the cap is not properly tightened, the Malfunction



Indicator Light may illuminate.
For more information, refer to the “Instruments and controls (section 2)”
and the “Pre-driving checks and adjustments (section 3)” of your
Owner’s Manual.
Tire Pressure Monitoring System (TPMS)
A
CHECK TIRE PRESSURE warning message will
appear in the vehicle information display
1 and
the low tire pressure warning light
2 will illuminate
when one or more tires are low in pressure and air
is needed.



•


The tire pressures should be checked when

the tires are cold. The tires are considered cold
after the vehicle has been parked for 3 hours
or more or driven less than 1 mi (1.6 km) at
moderate speeds.
After tire pressures are adjusted, drive the vehicle
at speeds above 16 MPH (25 km/h). The CHECK
TIRE PRESSURE warning message and low tire
pressure warning light will extinguish.
When the low tire pressure warning light flashes for 1 minute and then r\
emains on, the TPMS
is not functioning properly. Have the system checked by an INFINITI reta\
iler.
Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and the
outside temperature. Low outside temperature can lower the temperature o\
f the air inside
the tire, which can cause a lower tire inflation pressure. This may caus\
e the low tire pressure
warning light to illuminate. If the warning light illuminates, check the\
tire pressure in your tires.



•

Check the tire pressure (including the spare tire) often and always pr\
ior to long distance trips.
The Tire and Loading Information label contains valuable information. Pl\
ease refer to
“Technical and consumer information (section 9)”, in your Owner’\
s Manual for the location of
the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and
the“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
1
2
2
1
essential information
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 39/15/14 1:25 PM

4
essential information
Accessing the Front Cup Holders
To open the cup holders, push the lid 1 down
and release.
The flap 2 will fold down when inserting a
large container.
For more information, refer to the “Instruments and controls (section 2)” of
your Owner’s Manual.
Automatic Power Windows
Your power windows have an automatic adjusting
function to ensure windows close completely to
help seal against wind noise and weather leaks.
When the front doors are being opened, the windows
automatically lower slightly to avoid contact
between the windows and the side roof panels.
If your vehicle’s battery is discharged or
disconnected, your power window automatic
function will not operate.
Refer to your Owner’s Manual for information to
initialize your power window system.
If the power window functions do not operate
properly after initializing the system, have your
vehicle checked by an INFINITI retailer.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
Fuel-filler Door
The fuel-filler door is located on the passenger’s side of
the vehicle.
Unlock the fuel-filler door using one of the following
operations then push and release the left side of

the door to open.
•


Push the door handle request switch while
carrying the INFINITI Intelligent Key with you.
•


Press the UNLOCK button on the Intelligent Key.
•


Push the power door lock switch to the UNLOCK position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1
2
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 49/15/14 1:25 PM

5
Clock Set/Adjustment
DIGITAL CLOCK ADJUSTMENT
To adjust the time and the appearance
of the clock on the display:



1.

Press the
SETTING button on the control panel.



2.

Touch the
Others key.



3.

Touch the
Clock key.
The following settings can be adjusted:
•

On-screen Clock:
The clock in the upper right corner
of the display can be turned ON or OFF.
•


Clock Format (24h):
The clock can be set to 12 hours or 24 hours.
•


Offset (hour):
The time can be adjusted by increasing or decreasing per hour.
•


Offset (min):
The time can be adjusted by increasing or decreasing per minute.
•


Daylight Savings Time:
The application of daylight savings time can be turned ON or OFF.
•


Time Zone:
Adjust the time zone. Choose a time zone from the available list.
Press the BACK button to return to the previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 59/15/14 1:25 PM

6
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock or
unlock the vehicle, open the trunk and start the engine.
It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle request
switch
1 once or press the button 2 on the key fob.
To unlock the vehicle, perform one of the following procedures:



•

Push either door handle request switch

1 once; the
corresponding door will unlock. Push the door handle
request switch
1 again within 1 minute; all other doors
will unlock, or



•


Press the button 3 on the key fob to unlock the driver’s

side door. Press the
button again; all other doors will unlock.
To release the trunk lid, press the HOLD button 4 for more than
1 second. Lift the trunk lid to access the trunk.
To retract the hard top (Convertible models), push and hold the
door handle request switch

1 until the hard top is fully open.
The Intelligent Key can also be used to activate the panic alarm by pres\
sing and holding
the
button 5 for more than 1 second. Once activated, the panic alarm and headlights
will stay on for a period of time.
INFINITI INTELLIGENT KEY BATTERY DISCHARGE
If the battery in the Intelligent Key is almost
discharged, the guide light
6 of the Intelligent
Key port blinks and the Intelligent Key battery
discharge indicator
7 is displayed in the vehicle
information display.
To start the engine under these circumstances,
insert the Intelligent Key into the key port with the
buttons facing upward and the key ring end toward
you until it latches into place. Then push the
ignition switch to start the engine.
To remove the Intelligent Key from the port, push
the ignition switch to turn the engine off and then
pull the Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent Key battery. If\
you see the low
battery indicator

7, replace the battery in the Intelligent Key.
Do not insert the mechanical key or any other objects into the key port \
because it will
damage the key port.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and
the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
1
first drive features
2
3
4
5
6
7
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 69/15/14 1:26 PM
