2015 INFINITI Q40 Quick Reference Guide

2015 Infiniti Q40Quick Reference Guide
1811809_15b_Infiniti_Q40_QRG_091014.indd 39/10/14 3:41 PM

*See your Owner’s Manual for information.
1 ADAPTIVE FRONT LIGHTING SYSTEM
(AFS) SWITCH*
2 INSTRUMENT BRIGHTNESS
CONTROL SWITCHES*
3 HEADLIGHT AND TURN SIGNAL SWITCH
4 TRIP RESET SWITCH*
5 VEHICLE INFORMATION DISPLAY
6 WINDSHIELD WIPER AND
WASHER SWITCH
7 STEERING WHEEL SWITCHES
FOR AUDIO* / BLUETOOTH®
8 CRUISE CONTROL
9 PUSH BUTTON IGNITION SWITCH
10 VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH*
11 TRUNK LID RELEASE SWITCH
12 INTELLIGENT KEY PORT
13 PARKING BRAKE
14 CONTROL PANEL DISPLAY
15 AUDIO SYSTEM
16 CLIMATE-CONTROL SYSTEM
17 PASSENGER AIRBAG INDICATOR LIGHT
18 HEATED SEAT SWITCHES*
Behind
steering wheel
Behind
steering wheel Behind
steering wheel
Behind
steering wheel
12
3
456
789
14
15
16
17
1818
1011
1213
1811809_15b_Infiniti_Q40_QRG_091014.indd 49/10/14 3:41 PM

table of contents
essential information
Tire Pressure Monitoring System (TPMS) ............................2
Loose Fuel Cap.................................................2


Fuel-filler Door

.................................................
3


Accessing the Front Cup Holders (if so equipped).....................3
Clock Set/Adjustment

...........................................
4


NavTraffic and NavWeather.......................................4
first drive features
INFINITI Intelligent Key System...................................5
Trunk Lid Release...............................................6

Seat Adjustments...............................................6


Outside Mirror Control Switch.....................................7
Starting/Stopping the Engine

.....................................
7

Headlight Control Switch.........................................8


Windshield Wiper and Washer Switch

..............................
9

Climate Controls................................................9





FM/AM/SiriusXM
® Satellite Radio with CD/DVD (if so equipped) Player..11
USB (Universal Serial Bus) Connection Port/iPod® Interface...........12
Cruise Control.................................................12
system guide
Trip Computer.................................................13


Bluetooth
® Hands-free Phone System .............................14



System Operating Tips
.......................................
14


Bluetooth
® System with Navigation (if so equipped) .................15


Bluetooth® System without Navigation (if so equipped) ..............17
Navigation System (if so equipped)
...............................
18
DVD Player (if so equipped)......................................19


HomeLink
® Universal Transceiver.................................19
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
Please see your Owner’s Manual for important safety information
and system operation limitations.
•
A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•
Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the

“Safety — Seats, seat belts and
supplemental restraint system (section 1)”, the “Monitor, climat\
e, audio,
phone and voice recognition systems (section 4)” and the “Starting and
driving (section 5)” of your Owner’s Manual.
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2015/q40 or snap this barcode with an appropriate barcode reader.
1811809_15b_Infiniti_Q40_QRG_091014.indd 59/10/14 3:41 PM

2
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear
in the vehicle information display

1 when the
fuel-filler cap is not tightened correctly.
To tighten, turn the cap clockwise until a single
click is heard.
The warning message will extinguish when the
vehicle detects the fuel-filler cap is properly
tightened and the reset button
2 is pressed. If the cap is not properly tightened, the Malfunction
Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and
the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Tire Pressure Monitoring System (TPMS)
A CHECK TIRE PRESSURE warning message will ap-
pear in the vehicle information display
1 and the
low tire pressure warning light 2 will illuminate
when one or more tires are low in pressure and air
is needed.



•


The tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.
After tire pressures are adjusted, drive the vehicle at
speeds above 16 mph (25 km/h). The CHECK TIRE PRESSURE warning
message and low tire pressure warning light will extinguish.
When the low tire pressure warning light flashes for 1 minute and then r\
emains on, the
TPMS is not functioning properly. Have the system checked by an INFINITI\
retailer.
Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and
the outside temperature. Low outside temperature can lower the temperatu\
re of the air
inside the tire, which can cause a lower tire inflation pressure. This m\
ay cause the low tire
pressure warning light to illuminate. If the warning light illuminates, \
check the tire pres-
sure in your tires.



•

Check the tire pressure (including the spare tire) often and always pr\
ior to long

distance trips.
The Tire and Loading Information label contains valuable information. Pl\
ease refer to the
“Technical and consumer information (section 9)” in your Owner’\
s Manual for the location
of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the “Maintenance
and do-it-yourself (section 8)” of your Owner’s Manual.
essential information
1
1
2
2
1811809_15b_Infiniti_Q40_QRG_091014.indd 29/10/14 3:41 PM

3
Accessing the Front Cup Holders (if so equipped)
To open the cup holders, push the lid 1 down
and release.




The flap 2 will fold down when inserting a
large container.
For more information, refer to the “Instruments and controls (section 2)” of
your Owner’s Manual.
1
2
Fuel-filler Door
The fuel-filler door is located on the right, rear side
of the vehicle.
Unlock the fuel-filler door using one of the following
operations then push and release the right side of
the door to open.
•


Push the door handle request switch while
carrying the INFINITI Intelligent Key with you.
•


Press the UNLOCK button on the Intelligent Key.
•


Push the power door lock switch to the UNLOCK position.
For more information, refer to the “Pre-driving checks and adjustments (section 3 )” of your Owner’s Manual.
1811809_15b_Infiniti_Q40_QRG_091014.indd 39/10/14 3:41 PM

4
NavTraffic* and NavWeather* (if so equipped)
Your vehicle’s Navigation System is equipped with
NavTraffic and NavWeather capabilities.
NavTraffic enables your vehicle’s Navigation System
to display real-time traffic conditions, such as
accidents or road construction, and may provide a
detour to help avoid congestion.
NavWeather tracks nationwide weather
information, provides real-time weather reports
and automatically alerts you to severe weather
conditions around your current vehicle location.
*These features, SiriusXM® Satellite Radio, NavTraffic and NavWeather
require an active subscription. Multiple subscriptions may be necessary \
to
activate the various features.
For more information, refer to the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
Clock Set/Adjustment
DIGITAL CLOCK ADJUSTMENT
To adjust the time and the appearance
of the clock on the display:
1.


Press the

SETTING button on the control panel.
2.


Touch the

Others key.
3.


Touch the

Clock key.
The following settings can be adjusted:
•


On-screen Clock:
The clock in the upper right corner of the display can be turned ON or O\
FF.
•


Clock Format (24h):
The clock can be set to 12 hours or 24 hours.
•


Offset (hour):
The time can be adjusted by increasing or decreasing per hour.
•


Offset (min):
The time can be adjusted by increasing or decreasing per minute.
•


Daylight Savings Time:
The application of daylight savings time can be turned ON or OFF.
•


Time Zone:
Adjust the time zone. Choose a time zone from the available list.
Press the BACK button to return to the previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
essential information
1811809_15b_Infiniti_Q40_QRG_091014.indd 49/10/14 3:41 PM

5
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock or
unlock the vehicle, open the trunk and start the engine.


It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).



The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.



To lock the vehicle, push either door handle request switch 1 once
or press the
button
2 on the key fob.



To unlock the vehicle, perform one of the following procedures:



•

Push either door handle request switch 1 once; the corresponding
door will unlock. Push the door handle request switch 1 again
within 1 minute; all other doors will unlock, or
•


Press the button
3 on the key fob to unlock the driver’s side
door. Press the
button again; all other doors will unlock.
To release the trunk lid, press the button
4 for more than
1 second. Lift the trunk lid to access the trunk.
The Intelligent Key can also be used to activate the panic alarm by
pressing and holding the
button
5 for more than 1 second. Once
activated, the panic alarm and headlights will stay on for 25 seconds.
INFINITI INTELLIGENT KEY BATTERY DISCHARGE
If the battery in the Intelligent Key is almost discharged,
the guide lights
6 of the Intelligent Key port blink and
the Intelligent Key battery discharge indicator 7 is
displayed in the vehicle information display.
To start the engine under these circumstances, insert
the Intelligent Key into the key port with the buttons
facing upward and the key ring end toward you until
it latches into place. Then push the ignition switch to
start the engine.
To remove the Intelligent Key from the port, push the ignition switch to\

turn the engine off and then pull the Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent Key battery.
If you see the low battery indicator
7, replace the battery in the
Intelligent Key.
Do not insert the mechanical key or any other objects into the intellige\
nt key port. Inserting any
object other than the Intelligent Key will damage the Intelligent Key po\
rt.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and the
“ Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
first drive features
2
3
4
5
6
7
1
1811809_15b_Infiniti_Q40_QRG_091014.indd 59/10/14 3:42 PM

6
first drive features
Seat Adjustments
POWER SEAT ADJUSTMENTS
To slide the seat forward or backward, push the switch

1 forward or backward.
To recline the seatback, push the switch
2
forward or backward.
SEAT LIFTER
To adjust the angle of the front portion or height of the
seat, push the front or rear end of the switch
1 up or down.
MANUAL LUMBAR SUPPORT (driver’s seat only)
To adjust the seat lumbar support, move the lever 3
forward or backward.
For more information, refer to the “Safety —— Seats, seat belts and supplemental restraint system (section 1)”
of your Owner’s Manual.
Trunk Lid Release
Use one of the following methods to open the trunk:
Push the trunk open request switch
1 for more than
1 second while carrying the INFINITI Intelligent Key
with you.

Press the trunk buttonHOLD on the Intelligent Key for
more than 1 second.





From inside the vehicle, push down on the trunk lid
release switch
2 on the instrument panel.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
1
1
2
2
3
1811809_15b_Infiniti_Q40_QRG_091014.indd 69/10/14 3:42 PM
