2015 HONDA CIVIC COUPE Quick Guide

42 || 43
VEHICLE CONTROLS
VEHICLE CONTROLS
Climate Control System*
The automatic climate control system can maintain your preferred interio\
r
temperature by selecting the proper mix of heated or cooled air and fan \
speed. Use
the buttons on the dashboard to control the system.
Seat Heaters*
Quickly warm the front seats when the vehicle is on.
Press the seat heater switch in the front console to
the LO or HI position. An indicator appears for the
selected setting. Return the switch to the middle
position to turn off.
AUTO button: Press, then
use the temperature
control dial to set your
preferred temperature.
Temperature
control dial
A/C
buttonFan control
dial
Recirculation button:
Recirculation mode
(indicator on):
Recirculates air from the
vehicle’s interior.
Fresh Air mode (indicator
off): Maintains outside
ventilation. Rear defogger/
heated door
mirrors button*
Windshield
defroster
button ON/OFF
button
Mode button:
Change airfl ow
location.
Heat-induced burns are possible when using seat heaters.
Persons with a diminished ability to sense temperature (e.g., persons w\
ith
diabetes, lower-limb nerve damage, or paralysis) or with sensitive skin should
not use the seat heaters.
WARNING
*if equipped
Customized Features*
Use the Vehicle Menu in the i-MID to customize certain features, such as the
display, the trip computer, and door locking/unlocking. Use the steering wheel
controls to make and enter selections when the vehicle is stopped.
Changing Settings Using the Touchscreen*
Select items on the touchscreen to make and enter selections.
1. Select SETTINGS.
2. Select an option (Clock/Info, Audio, Bluetooth, Phone, Camera, System, \
or
Navi*).
3.

Select a setting option, and make your preferred changes.
4. Press BACK to exit the menus.
MENU
SOURCE Button
Press to go to the next
display.
SOURCE Button
Press to set your selection.
MENU Button
Press to go to Vehicle Menu. + Button
Press to scroll upwards.
Button
Press to go back to the
previous display.
- Button
Press to scroll downwards.
*if equipped

44 || 45
AUDIO AND CONNECTIVITY
VEHICLE CONTROLS
Setting the Clock
Adjust the time using the steps described for your vehicle type.
Using the CLOCK Knob
Use this method for vehicles with one display.
1. Press the CLOCK knob to enter the clock screen.
2. T

urn the knob to adjust the hour value.
Press the knob to set.
3. Turn the knob to adjust the minute value. Press the knob to set.
Using the Settings Menu
Use this method for vehicles with display audio. Touch items to make selections.
1. Select Settings.
2. Select

Clock/Info.
3. Select Clock Adjustment.
4. Adjust the hour and minute values.
5. Select OK when complete.
On vehicles with navigation, the time is automatically set using GPS sig\
nals.
Clock knob
AUDIO AND CONNECTIVITY
Learn how to operate the vehicle’s audio system.
Basic Audio Operation
Connect audio devices and operate buttons and displays for the audio sys\
tem.
USB/ HDMI Port* 1. Open the port cover in the front console.
2. Connect a USB fl

ash drive or iPod/iPhone
® cable
connector to the USB port, or an HDMI cable to the
HDMI port.
An additional USB cable is located in the center
console.
iPod and iPhone are trademarks of Apple, Inc.
Additional cables and accessories sold separately.
Auxiliary Input Jack*
Connect standard audio devices with a 1/8-inch
(3.5 mm) stereo miniplug.
1. Open the AUX cover in the front console.
2. Insert the miniplug attached to the audio device
into the jack. The audio system switches to
AUX mode. Use the device to control the audio.
State or local laws may prohibit the operation of
handheld electronic devices while operating a vehicle.
Accessory Power Socket
Open the socket cover in the front console to use
power when the vehicle is on.
Do not insert an automotive type cigarette lighter element. This can ove\
rheat the
power socket.
NOTICE
*if equipped

46 || 47
AUDIO AND CONNECTIVITY
AUDIO AND CONNECTIVITY
Steering Wheel Controls*
You can operate certain functions of the audio
system using the steering wheel controls.
SOURCE button: Cycle through available audio
modes.
/ buttons: Change presets, tracks, albums, or
folders.
+ / - buttons: Adjust audio volume.
MENU button: On vehicles with display audio, press and hold to view options for
the current audio source. Use the other buttons to navigate through the \
options.
FM/AM/SiriusXM
® Radio
Press
or for the next or previous station.
Press and hold
or for the next or previous strong station.
CD/iPod
®/USB/Bluetooth® Audio
Press
or for the next or previous track.
Press and hold
or for the next or previous folder (CD/USB).
Pandora
®
Press for the next song.
Press and hold
or for the next or previous station.
*if equipped
Adjusting the Sound
Adjust various sound settings.
V ehicles with information display
Press the TUNE/SOUND knob to scroll through
sound modes. Rotate the knob to adjust the
setting for each mode.
V

ehicles with one display
Use the selector knob to make and enter selections.
1. Press the SETUP button.
2. Select Sound Settings.
3. Select a sound mode to change, and adjust it using the selector knob.
4. Press the Back button to exit the menu.
Vehicles with display audio
Make and enter selections using the touchscreen.
1. Select Settings.
2. Select Audio.
3. Select Sound.
4. Select the tabs to change the sound mode and adjust the setting.
5. Select OK when complete.
Tune/Sound Knob
Setup
button
Selector
knob
Button

48 || 49
AUDIO AND CONNECTIVITY
AUDIO AND CONNECTIVITY
FM/AM Radio
Play FM or AM radio stations.
Models with information display
Volume/Power
knob AM button
FM button
Tune/Sound
knob
SCAN button: Press
to sample each
strong station on the
selected band. Press
again to turn off.
Auto select button:
Press to scan both bands
and store the strongest
station in each preset.
Press again to turn off.
Seek/Skip
buttons: Find
the next or
previous
strong station.
Preset buttons (1-6): Press and
hold a preset button to store
the current station. Press
a preset button to select a
previously stored station.
Compact Disc (CD)
The audio system supports audio CDs, CD-Rs, and CD-RWs in MP3, WMA, or A\
AC
formats.
Models with information display
Do not use CDs with adhesive labels or insert a damaged CD. Inserting th\
ese types
of CDs may cause them to get stuck or damage the audio unit.
NOTICE
Volume/
Power
knob CD eject
button
CD slot Tune/Sound
knob
SCAN button:
Press once
to sample
CD tracks.
Press again
to sample the
fi rst track in
each folder.
Press and hold
to turn off.
Random (RDM)
button: Press once
to play CD tracks at
random. Press again
to play folder fi les at
random. Press and
hold to turn off.
Seek/Skip
buttons:
Change the
track. CD/AUX button:
Play a CD.
DISP button:
Display CD
text data.
Repeat (RPT)
button: Press once
to replay a track
or fi le. Press again
to replay all fi les in
the current folder.
Press and hold to
turn off.

50 || 51
AUDIO AND CONNECTIVITY
AUDIO AND CONNECTIVITY
One Display Audio Operation
Control audio operation in the intelligent Multi-Information Display (i\
-MID) using the
dashboard buttons.
Models with one display
Intelligent Multi-Information
Display (i-MID)
002300
75°F miles
Volume/selector
knob: Rotate to
adjust volume.
Use knob to
make and enter
selections. SETUP button:
Display menu
items for the
selected audio
mode.
Power button: Turn
audio on or off.
FM/AM Radio
Play FM or AM radio stations.
Models with one display
() button:
Display and
select an RDS
category.
Seek/Skip
buttons: Find the
next or previous
strong station.
Selector knob:
Press and rotate
to tune radio
frequency.
Make and enter
selections.
Preset buttons (1-6): Press and hold
a preset button to store the current
station. Press a preset button to
select a previously stored station.
FM/AM buttons:
Select a band. SCAN button:
Press to sample
each strong
station on the
selected band.
Press again to
turn off.
FM/AM radio display
002300
75°F miles

52 || 53
AUDIO AND CONNECTIVITYAUDIO AND CONNECTIVITY
Compact Disc (CD)
The audio system supports audio CDs, CD-Rs, and CD-RWs in MP3, WMA, or AAC
formats.
Models with one display
CD display
CD button: Play a CD.
CD eject buttonCD slot
Selector knob: Press and turn to select an item, then press to set your selection.
Scan button: Press once to sample CD tracks. Press again to sample the fi rst track in each folder. Press and hold to turn off.Seek/Skip buttons: Press to change tracks. Press and hold to move rapidly within a track.
() button: Skip to the previous or next folder.
Do not use CDs with adhesive labels or insert a damaged CD. Inserting these types
of CDs may cause them to get stuck or damage the audio unit.
NOTICE
iPod®
Play and operate an iPod through the vehicle’s audio system.
Models with one display
Connect your device to the USB port (see page 45).
Searching for Music
Use the selector knob to search for tracks stored on the iPod.
1. From the audio screen, press the selector knob.
2. Select a menu option.
3. Select the track you want to play.
iPod is a trademark of Apple, Inc.
iPod display
123456
Genre AAASong AAA
Artist AAA
() button: Go to the previous display, or enter a selection.
Selector knob: Press to enter the Music Search menu. Press and turn to select an item, then press to set your selection.
Seek/Skip buttons: Press to change tracks. Press and hold to move rapidly within a track.
AUX button: Play iPod.

54 || 55
AUDIO AND CONNECTIVITYAUDIO AND CONNECTIVITY
USB Flash Drive
Play and operate a USB fl ash drive through the vehicle’s audio system.
Models with one display
Connect your device to the USB port (see page 45).
Searching for Music
Use the selector knob to search for tracks stored on the USB fl ash drive.
1. From the audio screen, press the selector knob.
2. Select a folder.
3. Select the track you want to play.
() button: Go to the next folder or beginning of the previous folder.Selector knob: Press to enter the folder list. Press and turn to select an item, then press to set your selection.
Seek/Skip buttons: Press to change tracks. Press and hold to move rapidly within a track.
SCAN button: Press once to sample tracks. Press again to sample the fi rst track in each folder. Press and hold to turn off.
AUX button: Play a connected USB drive.
USB display
00230075°Fmiles
Genre AAA1’23’’File AAA
Artist AAA
123 456
122:Folder CCC
123:Folder AAA
121:Folder BBB
Bluetooth® Audio
Play streaming or stored audio from your compatible phone through the vehicle’s
audio system. Visit handsfreelink.com (U.S.) or handsfreelink.ca (Canada) to check
phone compatibility. Standard data rates apply.
Models with one display
Connect your phone to Bluetooth® HandsFreeLink (®see page 68).
Notes:
• Make sure the volume on your phone is properly adjusted.
• You may need to enable additional settings on your phone for playback.
• The resume/pause function and remote audio controls are not supported on all phones.
Selector knob: Press to display the device name.
AUX button: Play Bluetooth® Audio.
Seek/Skip buttons: Press to change tracks.
Bluetooth Audio display
123456
Genre AAAFile AAA
Artist AAA
State or local laws may prohibit the operation ofhandheld electronic devices while operating a vehicle. Only launch streaming audio on your phone when it is safe to do so.

56 || 57
AUDIO AND CONNECTIVITYAUDIO AND CONNECTIVITY
Pandora®
Play and operate Pandora from your phone through the vehicle’s audio system. Visit
handsfreelink.com to check phone compatibility. Standard data rates apply.
Available in the U.S. only.
Models with one display
Connect your phone when the vehicle is stopped.
For iPhone:
• Connect via Bluetooth® HandsFreeLink (®see page 68) or USB port (see page 45).
• A pop-up may appear on your phone requesting you to allow access for Pandorato be launched.
• If you cannot operate Pandora through the audio system, it may be streaming through Bluetooth® Audio. Make sure Pandora is selected on the audio system.
• If Pandora still does not operate, try rebooting the phone and reconnecting thecable if necessary.
For Android or BlackBerry:
• Connect via Bluetooth® HandsFreeLink (®see page 68).
State or local laws may prohibit the operation ofhandheld electronic devices while operating a vehicle. Only launch streaming audio on your phone when it is safe to do so.
Selector knob: Press to enter Pandora menu. Press and turn to select an item, then press to set your selection.
AUX button: Play Pandora.
Skip button: Go to the next song.
Pandora display
button: Go to the next or previous station.
Touchscreen Operation
Use simple gestures—including touching, swiping, and scrolling—to operate certain
audio functions.
Some items may be grayed out during driving to reduce the potential for distraction.
You can select them when the vehicle is stopped or use voice commands*.
Wearing gloves may limit or prevent touchscreen response.
Models with touchscreen
Power button: Turn audio on or off.HOME(screen shown)
MENU: Display menu items for the selected screen.
BACK: Go back to the previous screen.
button: Change screen brightness.
Settings: Choose Audio for options.
HondaLink™: View apps when your phone is connected through HondaLink**.
Audio: Display current audio information.Volume
*if equipped
**HondaLink can be accessed only if the app is installed on your smartphone, and the phone is connected to the system (see page 58).
