2015 HONDA CIVIC COUPE Quick Guide

26 || 27
INSTRUMENT PANELINSTRUMENT PANEL
Washer uid level (Canadian models)*
The washer fl uid is low. Refi ll the washer fl uid (see page 125).
System message*
When a condition or malfunction indicator comes on, a message also
appears on the multi-information display. Check the display for more
information.
Vehicle Stability Assist ( VSA®) system
(Blinks) VSA is active.
Maintenance Minder™*
Scheduled maintenance for your vehicle is due.
Immobilizer
Your key or remote transmitter cannot be recognized by the vehicle. If the
indicator blinks, you may not be able to start the engine. Turn the vehicle off,
and then on again. If it continues to blink, there may be a problem with the
system. See your dealer.
On/Off Indicators
These indicators remind you when an item is on or off.
Gauges
These gauges include speed and fuel information.
Civic Si models
i-VTEC indicator
Rev indicator
Instant fuel economy gauge
Ambient meter (see page 94)
Fuel gauge
Speedometer
*if equipped
VSA off
CRUISE MAIN on
CRUISE CONTROL on
Turn signals/hazards on
Fog lights* on
High beams on
Exterior lights on
ECON mode* on
Information Display*
Consists of several displays that provide you with useful information.
Press the select/reset knob to cycle through the displays shown below.
Select/reset knob
Average fuel A, Trip meter A, Odometer
Range, Trip meter A, OdometerEngine oil life
Average fuel B, Trip meter B, Odometer
*if equipped

28 || 29
VEHICLE CONTROLS
INSTRUMENT PANEL
Intelligent Multi-Information Display ( i-MID)*
Consists of several displays that provide you with useful information.
Main Displays
Press the display button to cycle through the displays shown below.
Trip ComputerPress the select/reset knob to cycle through the displays shown below.
Select/reset knob
i-MID
button
Power monitor/
instant fuel economy* Clock/wallpaper
Blank screen
Average fuel/range/elapsed
time/average speed
(press and hold button to cycle) Audio/phone
display
123456
200
123456
123456
Genre AAASong AAA
Artist AAA
Odometer,
Outside temperature Trip A,
Outside temperature Trip B,
Outside temperature
*if equipped
VEHICLE CONTROLS
Learn about the various controls necessary for operating and driving the\
vehicle.
Using the Remote Transmitter*
Lock or unlock the doors and trunk.
Leaving the key or remote transmitter in the vehicle can result in theft\
or
accidental movement of the vehicle. Always take it with you whenever you\
leave
the vehicle unattended.
NOTICE
Unlock button: Press once
to unlock the driver’s door.
Press again to unlock all
doors.
Trunk button*: Press
and hold to unlock and
open the trunk. Lock button: Press to lock the
doors. Press again for audible
verifi cation.
Panic button: Press to sound
the alarm for 30 seconds.
Press again to cancel.
Built-in key*: Slide the release
knob on the back of the
transmitter and pull out the
built-in key.
Release knob
Built-in key
*if equipped

30 || 31
VEHICLE CONTROLS
VEHICLE CONTROLS
Smart Entry System*
When you carry the remote transmitter (for example, in a pocket or purs\
e) and it
is outside the vehicle and within range (about 32 inches or 80 cm), yo\
u can lock or
unlock the doors and trunk without handling the transmitter.
Unlocking/Locking the Doors
To unlock: Grab the driver’s door handle when the
vehicle is off to unlock the driver’s door . Grab the
front passenger’

s door handle to unlock all doors.
To lock: Press the door lock button on the front
door handle when the vehicle is off. If the remote
transmitter is inside the vehicle, the doors will not
lock.
Unlocking the Trunk Press the trunk release button to unlock and open
the trunk.
Door lock
button
Trunk release button
*if equipped *if equipped
Door Operation
Use several methods to lock or unlock the doors.
Using the Lock Tab
To unlock: When you unlock the door using the
lock tab on the driver’s door, only the driver’ s door
unlocks.
T

o lock: When you lock the door using the lock tab
on the driver’s door, all the other doors lock at the
same time.
Using the Front Door Inner Handle
When you pull either front door inner handle, the
door unlocks and opens. On vehicles with smart
entry, pulling the driver’s door inner handle unlocks
all other doors.
Using the Master Door Lock SwitchTo unlock: Press the unlock side of the switch to
unlock all doors.
To lock: Press the lock side of the switch to lock all
doors.
Childproof Door Locks*The childproof door locks prevent the rear doors
from being opened from the inside regardless of the
position of the lock tab.
Slide the lever in the rear door to the lock position,
and close the door .
Open the door using the outer door handle.
Using the Trunk Opener Pull the trunk release near the bottom of the driver’s
seat to unlock and open the trunk.
To lockLock tab
To unlock
Inner
handle
To lock
To unlock
Master door
lock switch
Unlock
Lock
Trunk
release

32 || 33
VEHICLE CONTROLS
VEHICLE CONTROLS
Power Window Operation
The power windows can be opened and closed when the vehicle is on by usi\
ng the
switches on the doors. The switches on the driver’s side can be used to open and
close all the windows.
Automatic Operation*
To open: Push the switch down fi rmly .
T
o close: Pull the switch up fi rmly.
The window opens or closes completely. To
stop the window at any time, push or pull the
switch again briefl y.
Manual Operation To open: Push the switch down lightly.
To close: Pull the switch up lightly

.
Release the switch when the windows reach the desired position.
Power Window Lock Push in the power window lock button so only the driver’s window can be
operated. The driver can operate all other windows using the specifi c switches.
OFF
Power window
lock button
Driver’s
window
switch
Front passenger’s
window switch ON
Indicator
Closing a power window on someone’s hands or fi ngers can cause serious
injury.
Make sure your passengers are away from the windows before closing them.\
WARNING
*if equipped
Power Moonroof Operation*
The moonroof can be opened and closed when the vehicle is on by using th\
e switch
on the ceiling.
Automatic Operation
To open: Push the switch back fi rmly to the
second detent, then release.
T o close:

Push the switch forward fi rmly to the
second detent, then release.
The moonroof opens or closes completely. To
stop the moonroof at any time, push the switch
briefl y.
Manual Operation
To open: Push and hold the switch back to the fi rst detent until the desired position
is reached.
T o close:

Push and hold the switch forward to the fi rst detent until the desired
position is reached.
Moonroof Tilt
To tilt: Push the center of the switch.
To close: Push the switch forward fi

rmly, then release.
CloseOpen
Tilt
Opening the moonroof in below freezing temperatures or when it is covere\
d with
snow or ice can damage the moonroof panel or motor.
NOTICE
Closing the moonroof on someone’s hands or fi ngers can cause serious
injury.
Make sure your passengers are away from the moonroof before closing it.
WARNING
*if equipped

34 || 35
VEHICLE CONTROLS
VEHICLE CONTROLS
Interior and Exterior Lights
Operate interior and exterior lights when the vehicle is on or off.
Brightness Control
Adjust instrument panel brightness when the
vehicle is on.
To brighten: T urn the knob to the right.
T

o dim: Turn the knob to the left.
A beep sounds when the brightness reaches
minimum or maximum.
Interior Lights Change the interior light settings using the switch
on the ceiling.
ON position: Interior lights remain on.
Door -activated position: Interior lights come on
when any of the doors are opened, the driver’ s door
is unlocked, or the vehicle is turned off.
OFF position:

Interior lights remain off.
Map lights*: Press the front map lights to turn on or off.
Exterior Lights Rotate the switches on the headlight lever to operate the exterior light\
s.
OFF: All exterior lights are off.
: Turn on exterior lights except headlights.
AUTO: T urn on the automatic lighting feature*.
Headlights turn on or off depending on ambient
brightness when the vehicle is on. Headlights
automatically come on after the wipers are
engaged for a certain time.
:

Turn on all exterior lights including headlights.
: Turn fog lights* on or off.
Control knob
Off
Door-activated
position
Map lights
High beams
Low beams Flashing the high beams Fog
lights*
One-Touch Turn Signal
Use this quick and convenient method to signal a lane change.
Lightly push the turn signal lever up or down for a
three-blink sequence.
For a continuous signal, push the lever up or down
until it locks into place.
Wiper Operation
The windshield wipers and washers can be used when the vehicle is on. Mo\
ve the
wiper lever up or down to the desired position.
Headlight-Wiper Integration*
When the headlights are in the AUTO position,
they automatically turn on when the front
wipers operate several times within a certain
interval. The headlights turn off shortly after
the wipers are turned off, or if there is enough
ambient light.
Intermittent WipersWhen you move the lever to the INT position,
the wipers operate based on the wiper delay.
Adjust the wiper delay using the adjustment
ring*.
Left turn Right turn
Do not use the wipers when the windshield is dry. The windshield will get
scratched, or the rubber blades will get damaged.
In cold weather, the blades may freeze to the windshield, becoming stuck.
Operating the wipers in this condition may damage the wipers. Use the de\
froster
to warm the windshield, or manually clear the windshield of ice and snow\

before turning on the wipers.
NOTICE
*if equipped
Intermittent time
adjustment ring*
Pull to
use
washer.
MIST
OFF
INT: Low speed intermittent
LO: Low speed wipe
HI: High speed wipe
1
1
2
2
3
3
4
4
5
5
*if equipped

36 || 37
VEHICLE CONTROLS
VEHICLE CONTROLS
Adjusting the Seats
Make seat adjustments before driving to ensure the best comfort and safe\
ty.
Adjusting the Front Seats
Adjust the driver’s seat as far back as possible while
allowing you to maintain full control of the vehicle.
You should be able to sit upright and well back in the
seat, adequately press the pedals without leaning
forward, and grip the steering wheel comfortably.
The passenger’ s seat should be adjusted so that it
is as far back from the front airbag in the dashboard
as possible.
The National Highway T

raffi c Safety Administration and Transport Canada
recommend that drivers allow at least 10 inches (25 cm) between the ce\
nter of the
steering wheel and the chest.
Power Driver’s Seat*
Move back and allow suffi cient space.
Horizontal
position
adjustment
Height
adjustment Seat-back
angle
adjustment
Reclining the seat-back too far can result in serious injury or death in\
a crash.
Adjust the seat-back to an upright position, and sit well back in the se\
at.
WARNING
Sitting too close to a front airbag can result in serious injury or deat\
h if the
front airbags infl ate.
Always sit as far back from the front airbags as possible while maintain\
ing
control of the vehicle.
WARNING
*if equipped
Manual Seats*
Floor Mats*
Position the front seat fl oor mats properly, and anchor
them. If they are not properly positioned, the fl oor
mats can interfere with the front seat functions.
Do not put additional

oor mats on top of the
anchored mats.
Height adjustment
(driver’s seat only)
Horizontal position adjustment
Pull up on the bar to move the seat,
then release the bar. Seat-back angle
adjustment
Pull up the lever to
change the angle.
Sitting improperly or out of position can result in serious injury or de\
ath in a
crash.
Always sit upright, well back in the seat, with your feet on the fl oor.
WARNING
Unlock
Lock
*if equipped

38 || 39
VEHICLE CONTROLSVEHICLE CONTROLS
Adjusting the Head Restraints
Your vehicle is equipped with head restraints in all seating positions. Head
restraints are most effective for protection against whiplash and other rear-impact
crash injuries.
The center of the back of the occupant’s head
should rest against the center of the restraint. The
tops of the occupant’s ears should be level with the
center height of the restraint.
To raise the head restraint: Pull it upward.
To lower the head restraint: Push it down while
pressing the release button.
To remove the head restraint: Pull the restraint up
as far as it will go. Then push the release button,
and pull the restraint up and out.
To reinstall a head restraint: Insert the legs back
in place, then adjust the head restraint to an
appropriate height while pressing the release
button. Pull up on the restraint to make sure it is
locked in position.
In order for the head restraint system to work properly:
• Do not hang any items on the head restraints, or from the restraint legs.
• Do not place any object between an occupant and the seat-back.
• Install each restraint in its proper location.
Improperly positioning head restraints reduces their effectiveness and
increases the likelihood of serious injury in a crash.
Make sure head restraints are in place and positioned properly before driving.
WARNING
Failure to reinstall, or correctly reinstall, the head restraints can result in
severe injury during a crash.
Always replace the head restraints before driving.
WARNING
Folding Down the Rear Seats
The rear seat-back(s*) can be folded down to make room for large items in the
trunk.
1. Remove the center shoulder belt from the guide.
2. Pull the release lever in the trunk to release the
lock.
3. Fold down the seat-back. Remove the rear head
restraints if necessary (see page 38).
Push the seat-back up fi rmly until it locks into
place to return it to its original position.
Make sure all items in the trunk or items extending through the opening into
the rear seats are properly secured. Loose items can fl y forward if you have to
brake hard.
Guide
Center shoulder belt
Release lever*
Release lever
*if equipped

40 || 41
VEHICLE CONTROLS
VEHICLE CONTROLS
Adjusting the Steering Wheel
The steering wheel height and distance from your body can be adjusted so\
that you
can comfortably grip the steering wheel in an appropriate driving postur\
e.
1. Pull up the steering wheel adjustment lever.
2. Move the steering wheel up or down, and in
or out.
3. Push down the steering wheel adjustment lever to lock the steering wheel in position.
Adjusting the Mirrors
Adjust the angle of the mirrors for the best visibility when you are sit\
ting in the
correct driving position.
Rearview Mirror with Day/Night Positions
Manually adjust the position to reduce headlight
glare from vehicles behind you. Flip the tab to
switch between day and night positions.
Power Door MirrorsAdjust the power door mirrors when the vehicle is on.
L/R selector switch: Select the left or right mirror.
After adjusting the mirror, return the switch to the
center position.
Mirror position adjustment switch: Press the switch
left, right, up, or down to move the mirror

.
To adjust
To lockLever
Adjusting the steering wheel position while driving may cause you to los\
e
control of the vehicle and be seriously injured in a crash.
Adjust the steering wheel only when the vehicle is stopped.
WARNING
DownNight positionTa b
Day
position
Up
Adjustment switchSelector
switch
Air Conditioning System*
Manually control the front and rear heating and cooling in your vehicle’\
s interior
using the buttons on the dashboard.
Fan control
dial A/C
button*
MAX A/C*
button Windshield
defroster buttonTemperature
control dial
Recirculation and/or Fresh
Air button:
Recirculation mode
(indicator on): Recirculates
air from the vehicle’s
interior.
Fresh Air mode (indicator
off): Maintains outside
ventilation. Rear defogger/
heated door
mirrors button*Vent mode
buttons
*if equipped
