~ Do not turn the engine off.
~ Drive immediately to an authorized Audi dealer
to have the malfunction corrected .
If there is a malfunction in the e lectronic ignition
l ock, the ignition cannot be turned off . Drive im­
mediately to an authorized service facility to have
the cause of the ma lfunction corrected.
On vehicles with Convenience key*, the engine
should not be switched off using the Start/Stop
button because the engine cannot be started
again after the ignition has been switched off.
Yellow symbols
Fig. 24 Display: Ye llow warn ing symbo l
N M
9 a: a, a,
When a ye llow warning symbol appears, one
warning tone so unds . A driver message appears
as we ll to exp la in the malf unction in more detail.
The driver warning goes out after about S sec­
onds, but it can be brought up at any time by press ing t he
ISETI button again.
Check the function d isp layed as soon as possible.
The yellow symbol w ill not go out aga in until the
reason for the malfunction has been corrected.
If several priority 2 malfunctions are present, the
symbols appear in succession and remain for
about 2 seconds.
Elect rom echan ica l steering, Dy­
namic steering*
¢page 195
Worn brake pads
¢page32
Battery voltage
¢page33
Driver information system
Defective light bulb
¢ page 32
Fog lights
¢page 32
Rear fog lights
¢page 32
Check engine oil leve l
¢page 33
Engine oil sensor malf unc tion
¢page 33
Engine temperature*
¢page 214
Low fuel level
¢page 33
Refill Ad Blue*
¢page 218
AdBlue malfunction *
¢page 218
Windshield washer fluid level
low
¢page 33
Convenience key*
Key not in veh icle
¢ page 32
Light/rain sensor defective
¢page 32
Dynamic headlight range con­
trol defective
¢ page 34
Battery in remote control key
¢page 37
Electromechanical parking
brake
¢page 91
Engine speed lim itation*
¢ page 33, ¢page 100
Diesel particulate filter* clog­
ged
¢ page 34
Adaptive light defective*
¢page 34
Steering malfunction
¢page 34
31

Driver inform ation system
Ignition lock malfunction
<=>page 34
Adapt ive dampers*
c:> page 34
W indshield wiper defective
c:>page34
Tire pressure monitoring sys­
tem*
Loss of t i re pressure
c:>page253
Tire pressure monitoring sys ­
tem* System not avai lab le
c:>page253
Automatic t ransmission ma l­
function
c:> page 12 7
H ybr id drive*
<=> page 100
The speed warnings warning threshold J IIIIJ
and warning thresho ld 2 llH are also yellow
symbo ls in some models . The warning is al­
ways shown as a small symbo l in the upper
area of the d isplay
c:> page 94.
-?e Key not in vehicle
Applies to veh icles: w ith Convenience key
II Is the key in the vehicle ?
This reminder appears along with the II symbol
if the master key is removed from the vehicle
with the eng ine running. It is intended to remind
you (e .g. when changing drivers) not to continue
the journey without the master key .
If the master key is no longer in the vehicle, you
cannot switch off the ignit ion after stopping the
e ngine and you a lso cannot start the engine
aga in . You also cannot lock the veh icle from the
outsid e.
l ) - : USA models only
32
@ Light/rain sensor defective
£1 Automati c he adlight s/ auto mati c wi per s
defective
If the symbol illum inates, the light sensor has
failed. For safety reasons the low beams are
tu rned on permanently with the sw itch in
AUTO .
However, you can contin ue to turn the lights on
and off using the light sw itch. In the case of a de­
f ect in the rain sensor, the windshie ld wiper lever
functions are still available. Have the light/rain
sensor checked as soon as possib le by an author­
i zed Audi dealer.
(0) Worn brake pads
E+J Brake pad s!
If the warning light i lluminates, immediate ly
contact your author ized Audi dealer or qualified
workshop to have all brake pads inspected. On
USA mode ls the warning light
E+J comes on to­
gether w ith the warning light
1111 . Both sets of
brake pads on an axle must always be replaced at
t h e same time.
.&_ WARNING
Driving w ith bad bra kes can cause a collision
and serious personal injury.
- If the warn ing lig ht E+J and the warn ing
light
llll1l with the message Brake pad s!
comes on in the instrument cluster display,
immed iate ly contact yo ur authorized Aud i
dea le r or q ualified workshop to have all
brake pads checked or rep laced if necessary.
~l}D10$ Defective light bulb warning
S:1 -If the indicator light turns on, a bulb has
failed. The message indicates the location of the
bulb .
Im-If a front fog lamp has fai led, the indicator
li ght turns on to indicate the location on the vehi-
cle.
~

M N
co
a:
co
,...., \!) ..,.,
N ..,., ,....,
IJ-If a rea r fog lamp has failed , the indicator
light turns on to indicate the location on the vehi­
cle.
Vehi cle light s: Sy stem fault!
If the message appea rs, there is a malfunct ion in
the head lights or light switch.
Drive to your authorized Aud i dea le r immediately
to have the malfunction corrected .
A WARNING
-Light bu lbs are pressurized and could ex­
plode whi le they a re being changed causing
serious persona l injury.
-
- Wor k w ith due care when handling the high­
voltage section of gas discharge (xenon) l igh ts *. Failure to do so could result in death
o r serious injury.
@ Tips
Have the bulb replaced or the connection re­
pa ired by your authorized Audi Serv ice depart­
ment.
<:;::> Windshield washer flu id level too low
llt Plea se refill wa sher fluid
If the symbol illuminates, add windshield washe r
fluid to the washer system and also to the head­
light washer system¢
page 234 .
Bil Fuel supply too low
When the D symbol i llum inates, this means
there are about 2 .6 gallons ( 10 liters) of fue l left
in the fuel tank. Time to refuel!
¢ page 215.
If the symbo l lights up, even when the re is ample
fue l in the tank, and the text
Fuel tank sy stem
malfun ction! Contact dealer
appears in the dis­
p lay, there is a fau lt in the system . Contact an a u­
thor ized Audi dealer to have the fault rectified.
D Battery voltage
If battery power drops into the range where it
can limit the abil ity of the engine to sta rt, th is
the symbo l(•) ::ippears in the instrument cluster
Driver information s ystem
display with the following driver message Lo w
batter y: Batte ry will be charged while d riving.
While t his d river no tification is disp layed, you
have to be prepa red fo r limited star ting capabili ­
ty .
Driver message appears and goes out again
If this drive r message appears after the ign ition
is tur ned on or while d riving a nd it goes ou t again
after a wh ile, the ba ttery has been adequa tely re ­
charged .
Driver message appears and does not go out
again
If this drive r notific ation appea rs after the ign i­
t ion is tu rned on or while dr iv ing and does not go
out again, the battery's state of charge is no t in
the optimal range. Start ing capability is restrict­
ed. Have the battery checked at an authorized
Audi dealer or other qualified workshop as soon as possible.
~ Check engine oil
II Add oil, ma x x qt (l) . You may cont . driv .
When the Ill symbol and dr iver message appear,
add the amount of oil appear ing in the disp lay at
the next opportunity ¢
page 225.
'l:7;,.. Engine oil sensor defective
• Oil le vel! Sen sor defective
If the symbol illuminates, contact yo ur author­
ized Audi dealer and have the oil sensor inspect­
ed . Until you have this done, check the oil level
each time you ref uel just to be on the safe s ide
¢ page 225.
!? Engine speed limitation
Applies to vehicles: with engine speed limitation
II! Do not ex ce ed max . engine speed of XXXX
rpm
T he II! symbol illuminates when there is a n en­
gine co ntro l malfunction . The indicato r light ~
i n t he i nstr ument cluster also illum inates. The
engine speed is limited to the speed displayed in .,,.
33

Opening and closing
Unlocking and locking the vehicle with the
remote control
Fig. 29 Remote co n trol: fun ctio n but ton s
Either the driver's door only or the entire veh icle
will unlock when the un lock button @ is pressed
once, depend ing on the sett ings in the radio or
MMI*
Central locking menu c::> page 39.
• Press button @(@ ) to unlock the vehicle
¢fig. 29.
• Press button CT) (@ ) to lock the vehicle c::> &_ in
General description on page 39.
• Press the button c:5 (@ ) for at least one sec­
ond to open the rear lid.
• Push the red
l PAN ICI button( @) to activate the
panic function. The horn sounds and the turn
signals flash. Push the red
I PANIC I button again
to deactivate the pan ic function .
If the vehicle is unlocked and no door, the rear lid
or the hood is opened within 60 seconds, the ve­
h icle locks itself again automatically . T his feature
prevents the vehicle from being accidentally left
un locked over a long per iod of time .
It depends on the settings in the radio or in the
MMI* whether the entire veh icle is unlocked or
only ce rtain doors
¢ page 39 .
On vehicles w ith Convenience key*, the selector
lever must be in the P posi tion, otherwise the ve­
h icle cannot be locked .
A WARNING
Read and follow all WARNINGS c::> Li::. in Gener­
al description on page 39.
40
@ Tips
- In order to make sure the locking function is
working, you should a lways keep your eye
on the vehicle to make sure it is properly
locked .
- Do not use the remote contro l if you are in­
side the car, otherwise you may unintention­
ally lock the vehicle, and then you would set
off the anti -theft alarm when you try to
start the engine o r open a door. In case this
happens anyhow, push the unlock button@.
- Use the panic function on ly if you are in an
emergency situation.
Locking and unlocking with Convenience
key
Applies to vehicles: wi th Convenience key
The doors and the rear lid can be unlocked and
locked without operating the master key.
Fig. 30 Door handle: Locking th e vehicle
Unlocking vehicle
• Take hold of the door handle. The door is un-
locked automatically.
• Pull the handle to open the door .
Locking vehicle
• Move the selector lever to the P position (auto­
matic transmission), otherwise the vehicle can­
not be locked .
• Touch the sensor at the door handle¢
fig. 30 to
lock the vehicle
c::> .&. in General description on
page 39 .
Do not reach inside the door handle .
The vehicle can be locked and unlocked at any
door. It depends on the settings in the radio or in
the MMI* whether the entire vehicle is unlocked
or one of the doors
c::> page 39 . The master key .,,_

M N
co ~ co
rl I.O
"' N
"' rl
must be within a range of about 5 feet (1.5 me ­
ters) from the appropriate door or the rear lid.
It
makes no difference whether the master key is in
your jacket pocke t or in your brief case .
I f you grip the door handle while locking, this can
adversely affect the locking function.
It is not possible to re-open the door for a brief
period direc tly after closing it. This allows yo u to
ens ure that t he doors are properly locked .
WARNING .!!!!!!!!!!.. -
Read and follow a ll WARNINGS ¢ & in Gener-
al description on page 39.
@ Tips
I f your vehicle has been stand ing for an ex­
tended period, please note the fol low ing :
- The proxim ity sensors are de act ivated after
a few days to save power. Yo u then have to
pull on the door handle once to unlock the
vehicle and a second time to open the vehi­
cle.
- To prevent the battery from being dis­
charged and to preserve your veh icle's abili­
ty to start for as long as possib le, the ener­
gy management system gradually switc hes
off unnecessary convenience functions . It is
possible that you w ill not be able to unloc k
you r vehicle using these convenie nce func­
tions.
- Fo r Decla rat ion of Compliance to United
Sta tes FCC and Industry Canada regulations
¢ page 284.
Open ing and clo sing
Operating locks with the mechanical key
In the event of a failure of the power locking sys­
tem, the driver's door con locked and unlocked
with the mechanical key at the lock cylinder .
Fig . 31 Key turn s for openin g an d clos ing
To unlock the vehicle
""I nsert the mechan ica l key into the lock o f the
driver's door.
.. Turn the mechanical key to position @
¢fig. 31.
To lock th e vehicle
"" Move the selector lever to the P pos it ion ( auto­
matic t ransm ission).
.. Close a ll windows and doors properly.
.. Tur n the mechanica l key in th e lock of the driv­
er's door to the lock position
@ ¢A in Gener­
al description on page 39.
If the power locking system fails, there is emer ­
gency locking for the passenger's door and the
rear doors
¢ page 42 .
A WARNING
Read and follow all WAR NINGS ¢ & in Gener­
al description on page 39 .
(D Tips
-After the ignition is switched on, the power
locking system sw itch and the unlocking
butto n for the rear lid~ in the door are en­
abled.
41

Lights and Vi sion
Lights and Vision
Exterior Lighting
Switching the lights on and off
Fig. 46 Inst rume nt pane l: ligh t sw itc h
Sw itch ing on AUTO -Automati c headlight
controls
• Turn the light switch to AUTO ¢ fig . 46 .
Sw itch ing on the side m arker lights
• Turn the light switch to ;o o: .
Switching on low beams
• Turn the light swit ch to io.
Switch ing off the lights
• Turn the ligh t sw itch to 0 .
The low beams only illuminate with the ignition
t urned on.
With the side marker lights or headlights switch­
ed on , the symbol next to the light switch illumi­
nates
~oo :.
AU TO - Automatic headlight control
W ith the swi tch i n the AUTO position, the low
beams are switched o n automatically depend ing
on the ambient light, fo r example in a tunnel, at
dusk and when it is raining or sno win g . When th e
low beams are switched on, the
oe> o: symbol comes
on . The low beams rema in switched on regard­
less of the amb ient light when you turn on the
fog lights .
When you turn
off the ignition, the low beams
are automatically switched
off .
52 With automatic headlight cont
ro l, you also have
t he high-b eam function available . However , if you
have not switched high beams back to low beams
while dr iving with automatic headlight control ,
on ly the low beams come on the next time you
turn o n automatic headlight control. In order to
r etu rn to high beams again, you f irs t h ave to pull
the high beam lever back to the no rma l posit ion
and t hen push the lever forwa rd .
Light sensor malfunction
In the event o f a light sensor malfunction, the
driver is notified in the instrument cluster dis ­
play:
El Automatic headlights / automatic wipers
defective
For safety reasons, the low beams are turned on
permanently with the switch in
AUTO . However,
you can continue to turn the lights o n and
off us­
i ng the light switch. Have the light sensor
checked as soon as possib le at an authorized Audi
dealer or other qualified wo rkshop.
_&, WARNING
- Automatic headlights are only intended to
as sis t the driver. T hey do no t re lieve the
driver of his re sponsibili ty to c heck th e
headligh ts and to turn them o n manually
according to the c urrent light and visibility
conditions . For e xamp le, fog cannot be de­
tected by the light sensors. So always switch
on t he headlights
io unde r these weather
conditions and whe n driving in the dark .
- Cras hes can happen when you cannot see
the road ahead and when you cannot be
seen by ot her motorists. Always turn on the
headl ights so that you ca n se e ahead a nd so
that others can se e yo ur car fro m the back.
- Please obey all laws when usi ng the lighting
sys tems described her e.
(D Tips
- The light sensor for headlight control is lo ­
cated in the rear v iew mirror mount . You
should therefore not app ly any st ickers to
the windsh ield in this area in o rder to pre­
vent malfunctions or fail ures.

M N
co ~ co
rl I.O
"' N
"' rl
-Some exterior lighting functions can be ad ­
j u sted
¢page 53.
-W hen yo u remove your key from the ignition
while the vehicle 's lights are turned on, a
buzzer sounds as Long as the driver 's doo r is
open.
- In coo l or damp weather, t he inside of the
headlig hts, turn signals and tail lights can
fog over d ue to the temperature difference
between the inside and outs ide. They will
clea r sho rtly after sw itching them on. This
does not affect t he service life of the light­
ing .
- In the event of a light sensor malfunct ion,
the driver is not ified in the instr ument clus­
te r d is play ¢
pag e 32.
Fog lights
Fig . 4 7 Fog lig ht sw itch
" To turn on the fog lights }D, press button (D
¢fig. 47.
"To turn on the rear fog lights 0$. p ress button
@ .
Fog lights
The s ide marker lights or Low beams must be
switched on. When the fog lights are swi tched
on, the g re e n check light at the edge of the
sw itch comes on.
If automat ic driving light control AUTO is activat­
ed, the low beams are switched on whe n the fog
lights a re turned on .
Rear fog light s
Low beams or side marker lights with fog lights
must be turned on.
Lights and Vis ion
W hen the rear fog ligh ts are turned on, the yel ­
low check light at the edge of the s witch comes
o n.
(D Note
The rear fog lights sho uld only be turned on in
accorda nce with traffic regulation, as the
li g hts are bright fo r fo llow ing traff ic .
Adjusting exterior lighting
The functions are selected in the radio or in the
MMI* .
"Sele ct: !CARI func tion button> Exterior light­
ing.
Or
.. Select:
~,c- A- R~ I function button > Car systems *
contro l button > Vehicle settings > Exterior
lighting .
Coming home (Lights when leaving car) ,
Leav ing home (Lights when unlocking car )
The coming home function ill uminates the area
outside the vehicle when you turn the ignit io n off
and open t he d river 's doo r. Depending on vehicle
equipment, the function ca n be sw itched on an d
off or the le ngth of time the lights remain on"
can be ad justed .
The leaving home i llum inates the area outside
t h e ve hicle w hen you un lock the vehicle. T his
func tion can be switched on and off .
The Comi ng home and Leaving home funct ions
o nly operate w hen it is dark and t he lig ht sw itch
is i n the
AUTO position .
Auto headlights
When the light sw itch is in the AU TO ¢ page 52
pos ition, the switch-on point of the lights can be
c h anged in the automat ic dr iving light funct ion.
Daytime running lights
USA models: Y ou can swit ch the d aytime r unning
lig hts
On and Off .
Canada models:
Th e f unc tion cann ot be tur ned
off .
It is acti vat ed a utom aticall y each t ime t he ig-
ni tion is switched on. .,,_
53

M N
co ~ co
rl I.O
"' N
"' rl
Windshield wipers
Switching the windshield wipers on
Fig. S6 Windshie ld wiper lever
Fig. S7 Rear w ipe r act uation
Move the windshield wiper lever to the corre­
spond ing pos ition:
@ -Windshield wiper off
(D-Interval mode. The windshield w iper auto­
matical ly activates when you drive 2 mph (4 km/
h). The higher the sensitivity of the rain sensor is
set (switch @ to the right), the earlier the wind­
shield w ipers react to moisture on the wind­
shield. In some models, you can switch rain sen­
sor mode off and switch intermittent mode on in
the MMI* . Select:
!CARI function button> Car
systems*
contro l button > Driver assist > Rain
sensor.
In i nterm ittent mode, you can adjust the
interval time using the@ switch .
@-Slow wiping
®-Fast wiping
©-Single wipe
® -Clean the windshield . To eliminate water
d roplets , the w indshield wiper performs one af­
terwipe operat ion after several seconds while
dr iving . You can switch this function off by mov-
Lights and Vision
ing the lever to position® within 10 seconds of
the afterwipe operation. The afterwipe function is reactivated the next t ime the ignition is switch ­
ed on.
T he rear wiper automat ica lly switches on when
the reverse gear is engaged and the front wind­ shield wipers are on and in operation.
Cleaning the headlights*. The headlight washer
system * operates only when the headlights are
on . If you move the lever to position ®, the
headlights are washed in interva ls .
@ -Wipe the rear window. The rear wipe r moves
about every 4 seconds.
(!) -Clean the rear window . Th e number of wiping
operations depends on how long the lever is held
in position 7.
_&. WARNING
-
- The rain sensor is only intended to assist the
driver . The driver is still responsible for
manually switching the wipers on according
to the visibility condit ions.
- The windshield may not be treated with wa­
ter-repelling windshield coating agents. Un­
favorable conditions, such as wetness, dark­ ness, low sun, can result in increased glare.
W iper blade chatter is also possible .
- Properly funct ion ing windshield wiper
blades are requ ired for a clear view and safe
driving.
(D Note
- In the case of frost, check whether the windshield wiper blades are frozen to the
windshield . Switching on the w indshield
wipers can damage the wiper blades!
- Prior to using a car wash, the windshield
w iper system must be sw itched off (lever in
position 0). This helps to prevent un inten­
tional switching on and damage to the
w indshield wiper system.
(D Tips
-The windshie ld wipers are switched off
when the ignit ion is turned off. Activate the
w indshield wipers after the ignition is ..,
57
