Seats, restraints47
Use the ignition key to choose the
switch position:
* OFF=front passenger airbag is
deactivated and will not
inflate in the event of a
collision. Control indicator
* OFF illuminates
continuously in the centre
consoleV ON=front passenger airbag is
active9 Danger
Deactivate passenger airbag only
in combination with the use of a
child restraint system, subject to
the instructions and restrictions in
the tables 3 50.
Otherwise, there is a risk of fatal
injury for a person occupying a
seat with a deactivated front
passenger airbag.
If the control indicator V illuminates
for approx. 60 seconds after the
ignition is switched on, the front
passenger airbag system will inflate
in the event of a collision.
If both control indicators are
illuminated at the same time, there is
a system failure. The status of the
system is not discernible, therefore
no person is allowed to occupy the
front passenger seat. Contact a
workshop immediately.
Change status only when the vehicle
is stopped with the ignition off.
Status remains until the next change.
Control indicator for airbag
deactivation 3 88.

48Seats, restraintsChild restraintsChild restraint systems
We recommend Vauxhall child
restraint system which are tailored
specifically to the vehicle.
The following child restraints are recommended for the following
weight classes:
■ Group 0, Group 0+
Maxi Cosi Cabriofix plus Easyfix,
for children up to 13 kg
■ Group I
VAUXHALL Duo, for children from
13 kg to 18 kg in this group
When a child restraint system is being used, pay attention to the following
usage and installation instructions
and also those supplied with the child
restraint system.
Check local laws and regulations for
mandatory use of child restraint
systems. In some countries, the use
of child restraint systems is forbidden
on certain seats.9 Danger
If using a rear-facing child restraint
system on the front passenger
seat, the airbag system for the
front passenger seat must be
deactivated. This also applies to certain forward-facing child
restraint systems as indicated in
the tables 3 50.
Airbag deactivation 3 46.
Airbag label 3 41.
The rear seats are the most
convenient location to fasten a child restraint system.
Children should travel facing
rearwards in the vehicle as long as
possible. This ensures that the child's backbone, which is still very weak, is
under less strain in the event of an
accident.
Selecting the right system
Only use suitable restraint systems,
e.g. those that comply with valid
UN ECE regulations.
Ensure that the child restraint system to be installed is compatible with the
vehicle type. Refer to the tables on
the following pages, the instructions
supplied with the child restraint
system and the vehicle type list of
non-universal child restraint systems.
Ensure that the mounting location of
the child restraint system within the
vehicle is correct, see following
tables.
Allow children to enter and exit the
vehicle only on the side facing away
from the traffic.
When the child restraint system is not in use, secure the seat with a seat belt
or remove it from the vehicle.
Child restraint systems could be
fastened with ISOFIX mounting
brackets, Top-tether if available,
and/or a three-point seat belt. Refer
to the following tables.

Seats, restraints49
Notice
Do not affix anything on the child
restraint systems and do not cover
them with any other materials.
A child restraint system which has
been subjected to stress in an
accident must be replaced.

50Seats, restraintsChild restraint installation locationsPermissible options for fastening a child restraint system with a three-point seat belt
Weight and age class
On front passenger seat
On rear outboard seatsOn rear centre seat
activated airbagdeactivated airbagGroup 0: up to 10 kg
or approx. 10 monthsXU 1,2U/L 3XGroup 0+: up to 13 kg
or approx. 2 yearsXU 1,2U/L 3XGroup I: 9 to 18 kg
or approx. 8 months to 4 yearsXU 1,2U/L 3,4XGroup II: 15 to 25 kg
or approx. 3 to 7 yearsU 1,2XU/L 3,4XGroup III: 22 to 36 kg
or approx. 6 to 12 yearsU 1,2XU/L 3,4XU=universal suitability in conjunction with three-point seat beltL=suitable for particular child restraint systems of the 'specific-vehicle', 'restricted' or 'semi-universal' categories. The child
restraint system must be approved for the specific vehicle type (refer to the vehicle type list of the child restraint system)X=no child restraint system permitted in this weight class1=move seat forwards as far as necessary and adjust seat backrest inclination as far as necessary to a vertical positionto ensure that the belt runs forwards from the upper anchorage point

Seats, restraints51
2=move seat height adjustment upwards as far as necessary and adjust seat backrest inclination as far as necessary toa vertical position to ensure that the belt is tight on the buckle side3=move the respective front seat ahead of the child restraint system forwards as far as necessary4=adjust the respective backrest to the rearmost position 3 67, adjust the respective headrest as necessary or remove
if required 3 34
Permissible options for fitting an ISOFIX child restraint system
Weight classSize classFixture
On front passenger seat 5On rear outboard
seatsOn rear
centre seatactivated airbagdeactivated airbagGroup 0: up to 10 kg
or approx. 10 monthsEISO/R1XILIL 3XGroup 0+: up to 13 kg
or approx. 2 yearsEISO/R1XILIL 3XDISO/R2XILIL3XCISO/R3XILIL3XGroup I: 9 to 18 kg
or approx. 8 months to 4 yearsDISO/R2XILIL 3,4XCISO/R3XILIL 3,4XBISO/F2XIL/IUFIL, IUF 3,4XB1ISO/F2XXIL/IUFIL, IUF3,4XAISO/F3XIL/IUFIL, IUF 3,4X

52Seats, restraints
Weight classSize classFixture
On front passenger seat5
On rear outboard
seatsOn rear
centre seatactivated airbagdeactivated airbagGroup II: 15 to 25 kg
or approx. 3 to 7 yearsIL 1,2XIL3,4XGroup III: 22 to 36 kg
or approx. 6 to 12 yearsIL 1,2XIL 3,4XIL=suitable for particular ISOFIX restraint systems of the "specific-vehicle", "restricted" or "semi-universal" categories.
(ISOFIX/Top-tether fastening points optional for the front passenger seat but not available for Corsa VXR). The
ISOFIX restraint system must be approved for the specific vehicle type (refer to the vehicle type list of the child
restraint system)IUF=suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this weight class
(ISOFIX/Top-tether fastening points optional for the front passenger seat (not available for Corsa VXR)X=no ISOFIX child restraint system approved in this weight class1=move seat forwards as far as necessary and adjust seat backrest inclination as far as necessary to a vertical position to ensure that the belt runs forwards from the upper anchorage point2=move seat height adjustment upwards as far as necessary and adjust seat backrest inclination as far as necessary
to a vertical position to ensure that the belt is tight on the buckle side3=move the respective front seat ahead of the child restraint system forwards as far as necessary4=adjust the respective backrest to the rearmost position 3 67 , adjust the respective headrest as necessary or remove
if required 3 345=ISOFIX/Top-tether fastening points optional for the front passenger seat (not available for Corsa VXR)

Seats, restraints53
ISOFIX size class and seat deviceA – ISO/F3=forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kgB – ISO/F2=forward-facing child restraint system for smaller children in the weight class 9 to 18 kgB1 – ISO/F2X=forward-facing child restraint system for smaller children in the weight class 9 to 18 kgC – ISO/R3=rear-facing child restraint system for children of maximum size in the weight class up to 18 kgD – ISO/R2=rear-facing child restraint system for smaller children in the weight class up to 18 kgE – ISO/R1=rear-facing child restraint system for young children in the weight class up to 13 kg

54Seats, restraintsISOFIX child restraint
systems Fasten vehicle-approved ISOFIX
child restraint systems to the ISOFIX
mounting brackets. Specific vehicle
ISOFIX child restraint system
positions are marked in the table by
IL.
The vehicle is equipped with guides in the backrests to support the
installation of the child restraint
system.
ISOFIX child restraint systems
on rear seatsISOFIX mounting brackets on the
rear seats are indicated by the
ISOFIX logo on the backrest.
Open the flaps of the guides before mounting a child restraint system.After removing the child restraint
system, close the flaps.
ISOFIX child restraint systems
on front passenger seat
Place the child restraint system in the
centre of the seat and push
backwards. Make sure that the child
restraint system is engaged properly.
Top-tether fastening eyes
In addition to the ISOFIX mounting,
fasten the Top-tether strap to the
Top-tether fastening eyes.
ISOFIX child restraint systems of
universal category positions are
marked in the table by IUF.
Top-tether fastening eye on rear seats
The vehicle has two fastening eyes
on the backside of the rear seats.
Top-tether fastening eyes are marked
with the symbol : for a child seat.
