EVU01010TroubleshootingAlthough Yamaha vehicles receive an inspec-
tion before shipment from the factory, trouble
may occur during operation. Any problem in
the fuel, compression, or ignition systems can
cause poor starting and loss of power. The
troubleshooting chart describes a quick, easy
procedure for making checks. If your vehicle
requires any repair, take it to a Yamaha deal-
er.
The skilled technicians at a Yamaha dealer-
ship have the tools, experience, and know-
how to properly service your vehicle. Use only
genuine Yamaha parts on your vehicle. Imita-
tion parts may look like Yamaha parts, but
they are often inferior. Consequently, they
have a shorter service life and can lead to ex-
pensive repair bills.
WARNING
When checking the fuel system, do not
smoke and make sure there are no open
flames or sparks in the area, including pi-
lot lights from water heaters or furnaces.
Gasoline or gasoline vapors can ignite or
explode, causing severe injury or property
damage.
1XP7B_EE.book Page 55 Tuesday, February 4, 2014 3:40 PM
10-1
1
2
3
4
5
6
7
8
910
11
12
13
14
EBU25960
1-SPECIFICATIONS
Dimensions:Overall length:3100 mm (122.0 in)
Overall width: 1625 mm (64.0 in)
Overall height:
1925 mm (75.8 in)
Seat height: 793 mm (31.2 in)
Wheelbase: 2135 mm (84.1 in)
Ground clearance:
300 mm (11.8 in)
Minimum turning radius: 4500 mm (177 in)Weight:Curb weight:
635.0 kg (1400 lb)Noise and vibration level:Noise level (77/311/EEC):YXM700PSE 83.0 dB(A) (EUR)(FRA)(GBR)
A-weighted sound power level:
YXM700PSE 93.0 dB(A) (EUR)(FRA)(GBR)
Vibration on seat (EN1032, ISO5008): YXM700PSE Will not exceed 0.5 m/s² (EUR)(FRA)(GBR)
Vibration on handle (EN1032, ISO5008): YXM700PSE Will not exceed 2.5 m/s² (EUR)(FRA)(GBR)
Engine:Engine type:Liquid cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement:
686 cm³
Bore × stroke:
102.0 × 84.0 mm (4.02 × 3.31 in)
Compression ratio: 10.0 : 1
Starting system:
Electric starter
Lubrication system: Wet sump
