EVU00080
1-DESCRIPTION
1. Headlight
2. Front shock absorber assembly
3. Brake fluid reservoir
4. Driver seat
5. Driver seat belt
6. Shoulder bolster
7. Cargo bed
8. Tail/brake light
9. Spark arrester
10. Rear shock absorber assembly
11. Spark plug
12. Cargo bed release lever
13. Storage compartment
14. Door 15. Engine oil dipstick
16. Passenger seat belt
17. Passenger seat
18. Air filter
19. Battery
20. Fuses
21. Radiator cap
22. Coolant reservoir
23. Storage compartment
24. Fuel tank cap
25. Oil filter cartridge123
