2014 YAMAHA MT-09 headlight bulb

TABLE OF CONTENTS
Checking the wheel bearings ........6-29
Battery ...........................................6-29
Replacing the fuses .......................6-31
Replacing the headlight bulb.........6-34
Tail/brake light ...............................6-36
Replacing a turn signal light bulb ............................................6-36
Replacing the license plate light
bulb ............................................6-37
Replacing an auxiliary light bulb....6-38
Supporting the motorcycle............6-39
Front wheel (for non-ABS models).................6-39
Rear wheel
(for non-ABS models).................6-41
Troubleshooting ............................6-42
Troubleshooting charts .................6-44
MOTORCYCLE CARE AND
STORAGE ..........................................7-1
Matte color caution .........................7-1
Care .................................................7-1
Storage ............................................7-3
SPECIFICATIONS ..............................8-1
CONSUMER INFORMATION ............9-1
Identification numbers .....................9-1
INDEX ...............................................10-1
U1RCELE0.book Page 2 Monday, May 12, 2014 8:51 AM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-34
6
EAU58001
Replacing the hea dlig ht bul bThis model is equipped with a halogen
bulb headlight. If the headlight bulb
burns out, replace it as follows.NOTICE
ECA10651
Take care not to damag e the follow-
in g parts:
 Hea dlig ht bul b
Do not touch the glass part of
the hea dlig ht bul b to keep it free
from oil, otherwise the transpar-
ency of the g lass, the luminosity
of the b ulb, an d the b ulb life will
b e ad versely affected . Thor-
ou ghly clean off any d irt and fin-
g erprints on the head light bul b
using a cloth moistene d with al-
cohol or thinner.
 Hea dlig ht lens
Do not affix any type of tinted
film or stickers to the head light
lens.
Do not use a hea dlig ht bul b of a
watta ge hi gher than specified .
1. Remove the headlight unit side
covers by removing the bolts on
each side. 2. Pull up the headlight unit cover to
separate it from the headlight unit.
3. Remove the grommets.1. Do not touch the glass part of the bulb.
1. Bolt
1
1
1. Bolt
2. Headlight unit side cover
1. Headlight unit cover1
1
2
21
U1RCELE0.book Page 34 Monday, May 12, 2014 8:51 AM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-35
64. Disconnect the auxiliary light cou-
pler.
5. Disconnect the headlight coupler, and then remove the headlight
unit from the vehicle. 6. Remove the headlight bulb cover.
7. Unhook the headlight bulb holder,
then remove the burnt-out bulb. 8. Place a new headlight bulb into
position, then secure it with the
bulb holder.
9. Install the headlight bulb cover.
10. Install the headlight unit as shown, and then connect the headlight
coupler.
1. Grommet
1. Auxiliary light coupler1
1
1. Headlight coupler
1. Headlight bulb cover
1
1
1. Headlight bulb holder
2. Headlight bulb
12
U1RCELE0.book Page 35 Monday, May 12, 2014 8:51 AM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-36
6
11. Connect the auxiliary light cou-
pler.
12. Align the holes in the headlight unit with the holes in the headlight
unit cover.
13. Install the grommets.
14. Place the headlight unit side cov- ers in their original position, and
then install the bolts.
15. Have a Yamaha dealer adjust the headlight beam if necessary.
EAU24182
Tail/b rake li ghtThis model is equipped with an LED-
type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU24205
Replacin g a turn sig nal light
b ul b1. Remove the turn signal light lens
by removing the screw.
2. Remove the burnt-out bulb by pushing it in and turning it coun-
terclockwise.
1. Headlight unit
2. Headlight coupler1
2
1. Turn signal light lens
2. Screw
1
2
U1RCELE0.book Page 36 Monday, May 12, 2014 8:51 AM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-38
6
EAU58021
Replacing an auxiliary li ght
b ul bThis model is equipped with two auxil-
iary lights. If an auxiliary light bulb
burns out, replace it as follows.
1. Remove the headlight unit side covers by removing the bolts on
each side.
2. Remove the auxiliary light bulbsocket (together with the bulb) by
turning it counterclockwise.
3. Remove the burnt-out bulb by pulling it out. 4. Insert a new bulb into the socket.
5. Install the socket (together with
the bulb) by turning it clockwise.
6. Place the headlight unit side cov- ers in their original position, and
then install the bolts.1. Bolt
1
1
1. Bolt
2. Headlight unit side cover
1. Auxiliary light bulb socket1
1
2
2
1
1. Auxiliary light bulb
1
U1RCELE0.book Page 38 Monday, May 12, 2014 8:51 AM

SPECIFICATIONS
8-3
8
Electrical system:Ignition system:TCI
Charging system:
AC magnetoBattery:Model:YTZ10S
Voltage, capacity:
12 V, 8.6 AhHea dlig ht:Bulb type:
Halogen bulbBul b volta ge, watta ge × quantity:Headlight:
12 V, 60.0 W/55.0 W × 1
Tail/brake light: LED
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light: 12 V, 10.0 W × 2
Auxiliary light: 12 V, 5.0 W × 2
License plate light:
12 V, 5.0 W × 1
Meter lighting: LED
Neutral indicator light: LED
High beam indicator light:
LED
Oil level warning light: LED Turn signal indicator light:
LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
ABS warning light: MT09A LED
Immobilizer system indicator light: LED
Fuses:Main fuse:50.0 A
Auxiliary fuse: 2.0 A
Headlight fuse:
15.0 A
Signaling system fuse: 7.5 A
Ignition fuse: 15.0 A
Parking lighting fuse:
7.5 A
Radiator fan motor fuse: 15.0 A
Fuel injection system fuse: 10.0 A
ABS control unit fuse:
MT09A 7.5 A
ABS motor fuse: MT09A 30.0 A
ABS solenoid fuse: MT09A 15.0 A Backup fuse:
7.5 A
Electronic throttle valve fuse: 7.5 A
U1RCELE0.book Page 3 Monday, May 12, 2014 8:51 AM

10-1
10
INDEXAABS (for ABS models) ........................... 3-17
ABS warning light (for ABS models) ....... 3-5
Air filter element .................................... 6-14
Auxiliary DC connector ......................... 3-28
Auxiliary light bulb, replacing ................ 6-38BBattery .................................................. 6-29
Brake and clutch levers, checking and lubricating ........................................... 6-26
Brake and shift pedals, checking and lubricating ........................................... 6-26
Brake fluid, changing ............................ 6-22
Brake fluid level, checking .................... 6-21
Brake lever ............................................ 3-16
Brake lever free play, checking............. 6-19
Brake light switches.............................. 6-20
Brake pedal........................................... 3-17CCables, checking and lubricating ......... 6-25
Care ........................................................ 7-1
Catalytic converter ................................ 3-20
Clutch lever ........................................... 3-16
Clutch lever free play, adjusting ........... 6-18
Coolant ................................................. 6-11
Coolant temperature warning light ......... 3-4DDimmer switch ...................................... 3-14
D-mode (drive mode) ............................ 3-13
Drive chain, cleaning and lubricating .... 6-24
Drive chain slack................................... 6-23EEngine break-in....................................... 5-4
Engine idling speed, checking .............. 6-14 Engine oil and oil filter
cartridge ............. 6-9
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-4
FFront and rear brake pads, checking ... 6-20
Front fork, adjusting ............................. 3-22
Front fork, checking ............................. 6-28
Fuel ....................................................... 3-19
Fuel consumption, tips for reducing ...... 5-4
Fuel tank breather hose and overflow
hose ................................................... 3-20
Fuel tank cap ........................................ 3-18
Fuses, replacing ................................... 6-31HHandlebar switches .............................. 3-14
Hazard switch....................................... 3-15
Headlight bulb, replacing ..................... 6-34
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-15IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-26
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-5
Indicator lights and warning lights ......... 3-3LLicense plate light bulb, replacing........ 6-37
Luggage strap holders ......................... 3-25MMain switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control system.................................................. 6-3
Matte color, caution ............................... 7-1 Model label .............................................9-1
Multi-function meter unit .........................3-6
NNeutral indicator light ..............................3-4OOil level warning light ..............................3-4PParking ....................................................5-5
Part locations ..........................................2-1
Pass switch ...........................................3-14SSafety information ...................................1-1
Seat .......................................................3-21
Shifting ....................................................5-2
Shift pedal .............................................3-16
Shock absorber assembly, adjusting ....3-24
Sidestand ..............................................3-26
Sidestand, checking and lubricating.....6-27
Spark plugs, checking ............................6-8
Specifications .........................................8-1
Start/Engine stop switch .......................3-15
Starting the engine ..................................5-1
Steering, checking ................................6-28
Storage ...................................................7-3
Storage compartment ...........................3-22
Supporting the motorcycle ...................6-39
Swingarm pivots, lubricating ................6-27TTail/brake light ......................................6-36
Throttle grip and cable, checking and
lubricating ...........................................6-25
Throttle grip free play, checking ...........6-15
Tires ......................................................6-15
Tool kit ....................................................6-2
