2014 VOLKSWAGEN SCIROCCO Owners Manual

Function button: action
Front volume : Different volumes can be set separately for the signal chimes for the front by tapping
the - or + function keys, or by adjusting the control.
Front pitch : Different pitches can be set for the signal chimes for the front by tapping the - or + function keys, or by adjusting the control.
Rear volume : Different volumes can be set for the signal chimes for the rear by tapping the - or + function keys, or by adjusting the control.
Rear pitch : Different pitches can be set for the signal chimes for the rear by tapping the - or + function keys, or by adjusting the control.
Audio lowering : Setting the level to which the Infotainment system volume should be reduced when the PDC is active.

Audio volume reduction

Menu option Explanation
Off The volume in the Infotainment system is not reduced.
Low The volume in the Infotainment system is reduced slightly.
Medium The volume in the Infotainment system is reduced to medium.
Strong The volume in the Infotainment system is reduced to a minimum.

Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function key on Infotainment system screen (if applicable). Tap the function key again to reactivate the acoustic signals.
Switching Park Distance Control back on after it was switched off reactivates the volume. System malfunction warning signals cannot be switched off.
If you manually deactivate the display, PDC remains on and the sound is reactivated.
The mute setting is active if the PDC was switched on using the  button when the selector is in Park (P).

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious personal injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility to the front, sides, and rear.
x Maximum heating output and defrosting performance are not possible until the engine has reached operating temperature. Wait until you have good visibility before driving off.
x Always make sure you know how to properly use the climate control system as well as the rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, collisions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation for a long period of time because no fresh air will enter the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor) switched on. Press the !

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal convenience settings, and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Manual controls

Fig. 149 In the center console: Manual air conditioning controls.

Button/Knob More information: Manual air conditioning ⇒ fig. 149
= Rear window defroster: Works only when the engine is running and switches off automatically after 10 minutes or less.
3 Air recirculation mode ⇒ page 281.
A, [ Buttons for seat heating ⇒ page 88.
!

Button/Knob More information: Climatronic ⇒ fig. 150.
Fan (2)

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions, and serious personal injury.
x Never switch off the fan for a long time because no fresh air will enter the passenger compartment.
Operation via the Infotainment system

The air conditioner is most efficient when the windows and the power sunroof are closed. If the vehicle is stationary and the passenger compartment becomes very hot due to sunlight, briefly opening the windows and the power sunroof may speed up the cooling process.
Keep the air intake slots in front of the windshield free of ice, snow, and leaves so that the heating and ventilation systems can work properly.
Settings for optimum visibility
When you switch on the cooling system, both the temperature and humidity in the vehicle are reduced. This will help make passengers feel more comfortable and help keep the windows from fogging up.
For manual air conditioning
x Switch off the air recirculation ⇒ Air recirculation.
x Set the fan to the desired speed.
x Turn the temperature knob to the center position.
x Open and adjust all air vents in the instrument panel ⇒ Air vents.
x Turn the air distribution knob to the desired setting.
x Push the !
