2014 VOLKSWAGEN SCIROCCO Owners Manual

Service event
For a scheduled oil change or a scheduled inspection there is an audible chime when the ignition is switched on. The wrench symbol > also appears for several seconds in the instrument cluster
display along with one of the following messages ⇒ fig. 12:

Oil change now!
Inspection now!
Oil change and inspection now!

Viewing service message
You can access the current service schedule when the ignition is switched on, the engine is not run-ning, and the vehicle is stationary:
x Press and hold the E button in the instrument cluster ⇒ Instrument overview until the word Ser-vice appears in the display.
x Release the button. The current service message appears in the display.
You can also view service information ⇒ fig. 13 in the Infotainment system by pressing the #!2 button
followed by the

Volkswagen Information System

The following list shows how the Volkswagen information system menus on the instrument cluster display are structured. The size and layout of the Volkswagen information system menu depends on the vehicle electronics and the vehicle equipment.
Driving data
▪ Travel time
▪ Conv. consumer
▪ Range
▪ Avg. consumption
▪ Consumption
▪ Speed warning
▪ Digital speed display
▪ Average speed
▪ Distance
Navigation ⇒ Booklet Radio, Navigation System
Audio ⇒ Booklet Radio, Navigation System
Telephone ⇒ Booklet Mobile Phone Package
Vehicle status
Using the instrument cluster menus

Fig. 14 On the right side of the steering column (vehicles without a multi-function steering wheel): Windshield wiper lever with controls for instrument cluster menus and displays.

Fig. 15 Right side of the multi-function steering wheel (if equipped): Controls for the menus and information displays in the instrument cluster.

take the vehicle to an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Main menu

x Vehicles with a multi-function steering wheel: Use the arrow up and down buttons (* and +) on
the right side of the steering wheel ⇒ fig. 15.
Trip memories
The display has 3 automatic memories:
x Since start
x Since refuel
x Extend. period
The currently selected memory is shown in the display.
The trip memories are in addition to the trip odometer, which is displayed in the bottom part of the
instrument cluster and controlled using the /./ button ⇒ fig. 10 (4).

Press the /+

Display Function
Travel time Driving time in hours (h) and minutes corresponding to trip memories 1, 2, and 3 (toggle).
Conv. consumer Displays any convenience equipment in the vehicle that is currently affecting fuel consumption.
Range  -- mi Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank the way you are currently driving. Takes account of the cur-rent fuel consumption, among other things. Range  -- km
Avg. consumption --.- mpg Average fuel consumption in miles per gallon (l/100 km) on trips per trip memories 1, 2, and 3 (toggle). For the since start trip memory, the value is displayed once the vehicle has been driven about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every second. Avg. consumption --.- l/100 km
Consumption --.- mpg Current fuel consumption in miles per gallon (l/100 km) while driving. When units are set to miles, dashes appear instead of a number when the engine is running and the vehicle is standing still. When units are set to kilometers, the display shows liters consumed per hour when the engine is running and the vehicle is standing still. Consumption --.- l/100 km
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h
--- mph Digital display of the current vehicle speed.
--- km/h
Average speed -- mph Average speed on trips per trip memories 1, 2, and 3 (toggle). For the since start trip memory, the value is displayed once the vehicle has been driven about 300 feet (100 m). The value displayed is updated every 5 seconds. Average speed -- km/h
Distance --- mi Distance driven in miles (km) per trip memories 1, 2, and 3 (toggle).
Distance --- km

Storing speed for the speed warning
x Select the Speed warning display.
x Press the /+

x To deactivate, press the /+
