2014 VOLKSWAGEN PASSAT Owner´s Manual

371
Replacing blown fuses

Fig. 215 Illustration of a blown fuse.

Fig. 216 Removing or inserting a fuse using the plastic tweezers.

x If necessary, replace the plastic tweezers in the fuse box cover.
x Replace the cover.
NOTICE
If a fuse is replaced with a fuse with higher amperage, then damage can occur at various places in the electrical system.

373
Replacing light bulbs

WARNING
Improper replacement of burned out headlights and other light bulbs can cause serious personal injury.
x Stop! Always read and heed the WARNINGS before doing any work in the engine compartment. The engine compartment of any motor vehicle is a potentially dangerous area, and work in this area can lead to serious personal injury.
x HID – High Intensity Discharge (Xenon) headlights get power from a high voltage source that can cause severe personal injury and even death if handled improperly.
x H7 bulbs and HID – High Intensity Discharge (Xenon) headlights are under high pressure and can explode if handled improperly.
x Always let a burned out light bulb cool down before replacing it.
x Never replace a light bulb unless you are familiar with all of the necessary procedures. In particular, never remove a headlight unless you know exactly how to carry out the job and have the correct tools and light bulbs.
x If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID – High Intensity Discharge (Xenon) headlights and H7 bulbs replaced by a qualified technician.
x Do not touch the glass of light bulbs with your bare hands. Fingerprints left on the bulb evaporate due to the heat when the bulb is switched on and cause the reflector to “cloud.”
x There are sharp edges on and around the headlight housing in the engine compartment and the rear light housing. Wear hand protection if you replace bulbs.
NOTICE
After replacing a headlight bulb or other light bulb, always make sure that the rubber covers or plastic caps have been properly and securely reinstalled to help prevent water from getting into the electrical connections and headlight housing and damaging the electrical system.
Indicator light

375

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Information on light bulb replacement

Replacing headlight bulbs

Fig. 217 In the engine compartment: Covers in the left headlight assembly: A Side marker light, B Low beam headlight, C High beam headlight, D Turn signal and parking light, E Daytime running light.

Fig. 218 In the wheel housing: Removing cover.

377
⇒ fig. 217 (A) (B) (C) (D) (E)
Side marker light Low beam High beam Turn signal and parking light
Daytime running lights
3.
Unscrew the fastening screw
⇒ fig. 218 (arrow) with a short screwdriver. To access the screw, turn the wheel in question inward as shown in .

Same as column (A).
4.
Remove the cover from the wheel house lining .
Same as column (A).
5. On the back of the headlight assembly, pull off the rubber cover for the bulb you are replacing.
Turn plastic
cover ⇒ fig. 217 A (E) counterclockwise and remove.
6. Left side of the vehicle: Turn plastic bulb socket counterclockwise (about 1/8 turn) to release it. Right side of the vehicle: Turn plastic bulb socket clockwise (about 1/8 turn) instead.
Turn plastic bulb socket counterclockwise (about 1/8 turn) to release it.
Press plastic tab on back of bulb socket to release it.
Same as column (A). Same as column (A).
7. Pull plastic bulb socket assembly back and out of the headlight assembly.
8. Replace the burned out light bulb with a new bulb of the same type.
9. Reinsert the bulb socket assembly into the headlight assembly.

⇒ fig. 217 (A) (B) (C) (D) (E)
Side marker light Low beam High beam Turn signal and parking light
Daytime running lights
10. Left side of the vehicle: Turn plastic bulb socket clockwise until it locks into place in the headlight assembly. Right side of the vehicle: Turn plastic bulb socket counterclockwise instead.
Turn plastic bulb socket clockwise until it locks into place in the headlight assembly.
Push bulb socket into the headlight assembly until you hear it “click” into place.
Same as column (A). Same as column (A).
11. Replace rubber cover on the back of the headlight assembly for the bulb you replaced.
Place the plastic cover A (E) in the headlight assembly housing and turn clockwise as far as it will go.
12.
Place the cover
⇒ fig. 218 in the wheel housing liner and use the screwdriver in the vehicle tool kit to tighten the fastening screw (arrow).

Same as column (A).
Please carry out each step only in the order specified:
The illustrations show the left headlight assembly from the rear. The right headlight assembly is the mirror image of the left headlight assembly.
