2014 VOLKSWAGEN JETTA HYBRID display

x Switch on the ignition.
x Switch on the Infotainment system, if necessary.
x Press the CAR Infotainment button.
x Tap a function key on the screen to view the information described below.

Function key Function
Driv. data Since Start Display of average fuel consumption, average speed, route, travel time, and range from the time the ignition was switched on until the time it was switched off.
Long-term Display of average fuel consumption, average speed, route, travel time, and range.
Hybrid Energy flow Shows the energy flow between the engine, high-voltage battery, and driving wheels
Zero Emission Displays the emission-free driving time as a bar graph. Each bar represents 1 minute of driving. The height of the bar indicates the proportion of emission-free driving in %.
A full bar, or 100% ⇒ fig. 129 (1), is a 1 minute interval of emission-free hybrid driving or sailing. No bar, or 0% (2), is a 1 minute interval driving only with the combustion engine. The display shows the emissions for a maximum of 30 minutes. Tapping Reset resets all values on this graph to zero.
You can always go back to the previously active menu by pressing the

Indicator lights

Fig. 130 In the instrument cluster display: Cruise control status indications.

WARNING
Rear Assist technology cannot overcome the laws of physics and the limits of the system. Careless or unintentional use of Rear Assist may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility conditions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice what is going on around you.
x Always watch for people, especially small children, animals, and objects, because the camera may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use Rear Assist only when the luggage compartment lid is completely closed.
NOTICE
x The camera shows only two-dimensional images on the screen. Due to the lack of depth of field, it may be difficult or impossible to identify protruding objects or recesses in the road, for example.
x Things like thin rods, fences, posts, and trees may not be detected by the camera and could damage the vehicle.
Operation

Fig. 133 In the luggage compartment lid: Location of the Rear Assist camera.

Fig. 134 Rear Assist display.

Changing the temperature unit on the factory-installed Radio or Radio & Navigation system display
The inside and outside temperatures can be displayed in either Fahrenheit (F) or Celsius (C).
Select Units in the instrument cluster display in the Settings main menu, Volkswagen Information System.
You can also press and hold the !

WARNING
Moving parts in the engine compartment can cause serious personal injury on contact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can cause serious personal injury. Always remember that the radiator fan is temperature-controlled and can come on suddenly even when the engine has been switched off for a while and the key has been removed from the ignition.
x If you have to perform a check or repair when the engine is running, there are more risks from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the high-voltage ignition system. Always use extreme care.
– Always make sure that jewelry, loose clothing and long hair do not get caught in rotating engine parts. Before starting any work remove your jewelry, take off your necktie, tie back and cover your hair, and do not wear clothing that can hang down and get caught in moving engine parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a check. The vehicle will start to move even if the parking brake is on.
x Never leave any objects in the engine compartment, for example cleaning rags and tools. Objects left behind can cause malfunctions, engine damage, and even fires.
WARNING
Operating fluids and some materials in the engine compartment can catch fire easily, causing burns and other serious personal injuries!
x Never smoke near the engine compartment.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the engine. These fluids can ignite on hot engine parts and cause injuries.
x If work on the fuel system or the electrical system is necessary:
– Always disconnect the 12 Volt vehicle battery. Make sure the vehicle is unlocked when you disconnect the battery, or the alarm will go off. Never touch the electrical wiring of the ignition system.
– Never work near heaters, water heaters, or other open flames.
x Always have a functional, approved fire extinguisher nearby.
NOTICE
When changing or topping off fluids, make sure that you pour the fluids into the correct reservoirs. Adding the wrong type of operating fluids will cause serious malfunctions and engine damage.
Fluid leaks and spills are harmful to the environment. Regularly check the ground underneath your vehicle for this reason. If you find spots of oil or other fluids, have your vehicle checked by your authorized Volkswagen dealer or authorized Volkswagen Service Facility. Dispose of leaked operating fluids properly.
Display

Lights up Possible cause Proper response
Icon appears in the display Engine hood not properly closed. ² Stop! Close the engine hood.
When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
If the engine hood is open or not closed properly, the vehicle icon appears in the instrument cluster
display showing the open engine hood ⇒ fig. 11, ⇒ fig. 12.
Depending on your vehicle's equipment and options, the icon may still be displayed even after the ignition is switched off as long as the key has not been taken out of the ignition. The icon in the instrument cluster display goes out about 15 seconds after the vehicle has been locked.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
Preparing to work in the engine compartment

When the hood is properly closed, you can see that it fits flush with the other body parts. The display in the instrument cluster no longer indicates that the engine hood is open, Display.
WARNING
If the hood is not closed properly, it could fly up and block your view while you are driving. This can lead to a crash and serious personal injuries.
x After closing the engine hood, check that the hood release lever is properly latched into the hood latch. The engine hood must be flush with the surrounding auto body parts.
x If you ever notice that the hood latch is not properly secured when the vehicle is moving, stop at once and close it.
x Never let anyone get in the way of the hood when closing it.
NOTICE
x Make sure the windshield wipers are switched off and the windshield wiper arms are resting on the windshield before you open the hood. Otherwise, the windshield wipers and the hood may be damaged.
x Always put the windshield wiper arms down against the windshield before driving the vehicle.
NOTICE
Before opening or closing the engine hood, make sure there is enough room to do so, for example when the vehicle is in a garage.
