2014 VOLKSWAGEN JETTA HYBRID display

Driver side overview

Fig. 5 Driver side overview.
Key to ⇒ fig. 5:
(1) Instrument cluster:
– Instruments
– Display
– Warning and indicator lights
(2) Headlight switch

– Display Phone main menu or accept telephone calls -
– Audio, navigation

– While driving, the current hybrid driving power (in %) is displayed.
(3) Displays Displays. The hybrid power is displayed after the ignition is switched on, Starting and stopping the engine.
(4) Reset button for the trip odometer display (trip).
– Push the /./

x Outside temperature
x Hybrid drive information, Hybrid drive
x Open door, engine hood, or luggage compartment lid ⇒ fig. 11
x Selector lever position Shifting
x Multi-Function Indicator (MFI) and menus for different settings, Volkswagen Information System
x Service reminder display, Service reminder display
Warning and information texts
The status of various vehicle functions and components is monitored when the ignition is switched on and while driving. Malfunctions are indicated by red and yellow warning symbols with text messages in the instrument cluster display (Warning and indicator lights). In some cases, they may also be signaled acoustically. The display can vary depending on the instrument cluster model.

Type of notification Symbol color Explanation
Priority 1 warning message Red Symbol flashing or lit – sometimes with acoustic warnings.

x Extended electro-mode drive indicator E-MODE.
x Information and warnings.
x Visual display for the vehicle power sources (electric motor or combustion engine), and energy flow between these power sources, the drive wheels, and high-voltage battery.
Selector lever positions
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive D and Sport Drive S, as well as in Tiptronic® mode.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside air temperature is above freez-ing.
x If you use the outside temperature display to tell you about frost conditions, remember that roads can even ice over at temperatures above +39 °F (+4 °C). Always remember: even if the “snowflake symbol” (icy road warning) is not displayed, there could still be black ice on the road.
x Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
The instrument cluster displays and their arrangement may vary depending on the vehicle model and engine. For displays without warning and information messages, malfunctions are only signaled with indicator lights.
If there are multiple warning messages, the symbols are displayed for several seconds in order of importance. The symbols are displayed until the cause has been corrected.
Service reminder display

For information on maintenance intervals, please see the ⇒ booklet Warranty and Maintenance.
For vehicles with time- or distance driven-dependent service, only fixed service intervals are dis-played.
Service reminder
If service is due in the near future, a service reminder is displayed when the ignition is switched on.
The messages Oil change and Inspection are shown in the instrument cluster display with the number of miles (km) and days remaining until service is due.
Service event
When service is due, the message Oil change now! or Inspection now! is shown in the instrument cluster display.
Viewing service message
The current service message can be accessed when the ignition is switched on, the engine is switched off, and the vehicle is stopped:
x Select the Settings menu.
x In the Service submenu, select the Info menu item.
x OR: If the Vehicle status main menu is active, use the arrow buttons to navigate to the service reminder display.
A message appears in the instrument cluster display when service is overdue.
Resetting the oil change service reminder
If the service was not performed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility, the oil change service reminder can be reset as follows:

Switch off the ignition.
Press and hold the /./

The instrument cluster menus are controlled with buttons on the right side of the steering wheel
⇒ fig. 13.
Accessing the instrument cluster menus
x Switch on the ignition. You will see the vehicle icon or a message in the instrument cluster display.
x Push the OK button () on the right side of the multi-function steering wheel until a main menu appears in the instrument cluster display. For a list of main menus, see, Menu structure – overview, Menu structure – overview.
x Push buttons # or ∃ to move to another main menu, and push the arrow up and down buttons * and + to navigate inside the current main menu. For example, in the Settings main menu, press the arrow down button + to navigate to the MFI data submenu.
Displaying a submenu
x Press the OK button to display submenu items. For instance, after scrolling to MFI data in the Settings main menu, press the OK button to display items available under the MFI data submenu.
Selecting a setting
x Some menus are used to select settings for certain features. Push the OK button () to select a setting.
x Use the arrow up and down buttons * and + on the multi-function steering wheel to navigate through the available options.
x The selected menu item is located between the 2 horizontal lines. There may also be a triangle () on the right.
x Push the OK button to select the setting.
Returning to the main menu
x Via menu: Use the arrow down button + to select Back and then press the OK button .
x For operation with multi-function steering wheel: Press E
Main menu

Menu Function See
Assistants Turn the Adaptive Front Lighting System (AFS) on and off (if equipped).
Vehicle status
Current warning and information messages. This menu item is only displayed when warning or infor-mation messages are available. The number of available messages is shown in the display. Example: 1/1 or 2/2.
Settings Includes the Convenience and Lights & Vision submenus, as well as many settings such as time, speed warning for winter tires, language, and units.

MFI menu (Multi-Function Indicator)
