2014 TOYOTA DYNA 100/150 service indicator

v
Table of contents
1 OPERATION OF INSTRUMENTS AND CONTROLSPage
1 Overview of instruments and controls
1 .......................
2 Keys and Doors11 ......................................
3 Seats, Seat belts, Steering wheel and Mirrors23 ...............
4 Lights and Wipers61 .....................................
5 Gauges, Meters and Service reminder indicators67 .............
6 Engine (ignition) switch, Transmission and Parking brake79 ......
7 Air conditioning system83 .................................
8 Other equipment99 ......................................
2 INFORMATION BEFORE DRIVING YOUR TOYOTA 107........
3 STARTING AND DRIVING 123...............................
4 IN CASE OF AN EMERGENCY 141..........................
5 CORROSION PREVENTION AND APPEARANCE CARE 169...
6 MAINTENANCE REQUIREMENTS 175.......................
7DO−IT−YOURSELF MAINTENANCE
1 Introduction179 .........................................
2 Engine and Chassis187 ..................................
3 Electrical components199 .................................
8 SPECIFICATIONS 211......................................
9 INDEX 221................................................
Dyna100/150_EE

6OVERVIEW OF INSTRUMENTS AND CONTROLS
1. Service reminder indicators and
indicator lights
2. Speedometer
3. Trip meter reset knob4. Odometer and two trip meters
5. Fuel gauge
6. Engine coolant temperature gauge
Dyna100/150_EE
Instrument cluster overview
"Without tachometer

OVERVIEW OF INSTRUMENTS AND CONTROLS7
1. Service reminder indicators and
indicator lights
2. Speedometer
3. Tachometer4. Trip meter reset knob
5. Odometer and two trip meters
6. Fuel gauge
7. Engine coolant temperature gauge
Dyna100/150_EE
"With tachometer

OVERVIEW OF INSTRUMENTS AND CONTROLS9
Turn signal indicator lights
Engine preheating indicator light
The indicators marked with
are service reminder indicators. For
details, see “Service reminder indicators and warning buzzer” on
page 73 in Section 1−5.
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS35
The driver ’s seat belt pretensioner is
designed to be activated in response to
a severe frontal impact.
When the airbag sensor detects the shock
of a severe frontal impact, the driver ’s
seat belt is quickly drawn back in by the
retractor so that the belt snugly restrains
the driver.
Collisionsoccurring at certain speeds and
angles may cause the seat belt preten-
sioner and SRS airbag not to operate all
together.This indicator comes on when the en-
gine switch is turned to the “ON” posi-
tion. It goes off after about 6 seconds.
This means the driver ’s seat belt pre-
tensioner is operating properly.
This warning light system monitors the
airbag sensor assembly, airbag sensor,
driver ’s seat belt pretensioner assembly,
inflator, interconnecting wiring and power
sources. (For details, see “Service remind-
er indicators and warning buzzer” on page
73 in Section 1−5.)
Dyna100/150_EE
—Driver’s seat belt
pretensioner

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS37
NOTICE
Do not perform any of the following
changes without consulting any autho-
rized Toyota dealer or repairer, or
another duly qualified and equipped
professional. Such changes can inter-
fere with proper operation of the
driver ’s seat belt pretensioner in
some cases.
zInstallation of electronic devices
such as an RF−transmitter, cassette
tape player or compact disc player
zRepairs on or near the driver ’s seat
belt retractor assembly
zModification of the suspension sys-
tem
zModification of the front end struc-
ture
zAttachment of a grille guard (bull
bar, kangaroo bar, etc.), snowplow,
winches or any other equipment to
the front end
zRepairsmadeonornearthefront
end structure or console
This driver ’s seat belt pretensionersystem
has a service reminder indicator to inform
the driver of operating problems. If any of
the following conditions occurs, this
indicates a malfunction of the airbag or
pretensioner. Contact any authorized
Toyota dealer or repairer, or another duly
qualified and equipped professional, as
soon as possible to service the vehicle.
DThe light does not come on when the
engine switch is turned to the “ON”
position or remains on for more than
6 seconds or flashes.
DThe light comes on or starts flashing
while driving.
DIf the driver ’s seat belt does not retract
or cannot be pulled out due to a mal-
function or activation of the relevant
driver ’s seat belt pretensioner.
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS39
This indicator comes on when the en-
gine switch is turned to the “ON” posi-
tion. It goes off after about 6 seconds.
This means the SRS airbag is operating
properly.
This warning light system monitors the
airbag sensor assembly, airbag sensor,
driver ’s seat belt pretensioner assembly,
inflator, interconnecting wiring and power
sources. (For details, see “Service
reminder indicators and warning buzzer”
on page 73 in Section 1−5.)The SRS airbag system is designed to
activate in response to a severe frontal
impact within the shaded area between
the arrows in the illustration.
The SRS airbag will deploy in the event
of an impact that exceeds the set thresh-
old level (the level of force corresponding
to an approximately 20−30 km/h [12−18
mph] frontal collision with a fixed wall that
does not move or deform).
If the severity of the impact is below the
above threshold level, the SRS airbag
may not deploy.
However, this threshold velocity will be
considerably higher if the vehicle strikes
an object, such as a parked vehicle or
sign pole, which can move or deform on
impact, or if it is involved in an underride
collision (e.g. a collision in which the nose
of the vehicle “underrides”, or goes under,
the bed of a truck, etc.).
It is possible that in some collisions at the
lower zone of airbag sensor detection and
activation the SRS airbag and seat belt
pretensioner will not operate all together.
For the safety of all occupants, always
wear your seat belts properly.
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS43
This SRS airbag system has a service
reminder indicator to inform the driver of
operating problems. If either of the follow-
ing conditions occurs, this indicates a mal-
function of the airbag. Contact any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
as soon as possible to service the ve-
hicle.
DThe light does not come on when the
engine switch is turned to the “ON”
position or remains on for more than
6 seconds or flashes.
DThe light comes on or starts flashing
while driving.
In the following cases, contact any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
as soon as possible:
DThe SRS airbag has been inflated.
DThe front of the vehicle (shaded in the
illustration) was involved in an accident
that was not severe enough to cause
the SRS airbag to inflate.
DThe pad section of the steering wheel
(shaded in theillustration) is scratched,
cracked, or otherwise damaged.
Dyna100/150_EE
