When trouble arises
493
5-2. Steps to take in an emergency
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning light goes off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
Indicates that a door or the
trunk is not fully closed. Check that all doors and the
trunk are closed.
Low fuel level warning
light Indicates remaining fuel is
approximately 2.6 gal. (9.7
L, 2.1 Imp. gal.) or less. Refuel the vehicle.
Driver’s/front passen-
ger’s seat belt reminder
light (warning buzzer)
*2
Warns the driver/front pas-
senger to fasten his/her
seat belt. Fasten the seat belt.
Master warning light A buzzer sounds and the
warning light comes on
and flashes to indicate that
the master warning system
has detected a malfunc-
tion. P. 500

494 5-2. Steps to take in an emergency
*1: Open door warning buzzer:P. 503
*2: Driver's seat belt buzzer:The driver's seat belt buzzer sounds to alert the driver that his or her seat
belt is not fastened. Once the “POWER” switch is turned to ON mode, the
buzzer sounds for 6 seconds. If the vehicle reaches a speed of 12 mph (20
km/h), the buzzer sounds once. If the seat belt is still unfastened after 30
seconds, the buzzer will sound intermittently for 10 seconds. Then, if the
seat belt is still unfastened, the buzzer will sound in a different tone for 20
more seconds.
Front passenger's seat belt buzzer:
The front passenger's seat belt buzzer sounds to alert the front passenger
that his or her seat belt is not fastened. The buzzer sounds once if the vehi-
cle reaches a speed of 12 mph (20 km/h). If the seat belt is still unfastened
after 30 seconds, the buzzer will sound intermittently for 10 seconds. Then, if
the seat belt is still unfastened, the buzzer will sound in a different tone for 20
more seconds.
(U.S.A. only) Tire pressure warning
light
When the light comes on:
Low tire inflation pressure
such as
• Natural causes (
P. 495)
• Flat tire ( P. 519) Adjust the tire inflation
pressure to the specified
level.
The light will turn off after
a few minutes. In case
the light does not turn off
even if the tire inflation
pressure is adjusted,
have the system checked
by your Toyota dealer.
When the light comes on
after blinking for 1 minute:
Malfunction in the tire
pressure warning system
(  P. 497) Have the system checked
by your Toyota dealer.
Warning lightWarning light/DetailsCorrection procedure

5
When trouble arises
509
5-2. Steps to take in an emergency
(Flashes)
Indicates that the
“POWER” switch is
turned off or turned to
ACCESSORY mode
and the driver's door
is opened while the
lights are turned on.
A buzzer also sounds. Turn the lights off.
*1: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s
Manual Supplement” for the maintenance interval applicable to your
vehicle.
*
2: For the EV drive mode operating conditions ( P. 165).
Warning messageDetailsCorrection procedure

510 5-2. Steps to take in an emergency
Have the malfunction repaired immediately.After taking the specified steps to correct the suspected problem,
check that the warning message and light go off.
Interior
buzzerExterior
buzzerWarning messageDetailsCorrection procedure
Once
(Flashes)The electronic
key is not
detected when
an attempt is
made to start
the hybrid sys-
tem.
Start the hybrid
system with the
electronic key
present.

516 5-2. Steps to take in an emergency
Power was
turned off due to
the automatic
power off func-
tion.Next time when
starting the
hybrid system,
increase the
engine speed
slightly and
maintain that
level for approx-
imately 5 min-
utes to recharge
the 12-volt-bat-
tery.
Once
The electronic
key has a low
battery.Replace the
electronic key
battery.
(
P. 458)
Interior
buzzerExterior
buzzerWarning messageDetailsCorrection
procedure

560 6-1. Specifications
Light bulbs
*: If equipped
A: H11 halogen bulbs B: HB3 halogen bulbs
C: D4S discharge bulbs D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber) F: Double end bulbs
Light bulbsBulb No.WTy p e
ExteriorHeadlights
Low beam
(halogen bulbs)*
Low beam
(discharge bulbs)*
High beam 

9005 55
35
60A
C B
Front side marker
lights 
5D
Rear side marker
lights 
5D
Front turn signal/park-
ing lights 
28/8 E
Rear turn signal lights 21 E
Stop/tail lights 21/5 D
License plate lights 5D
Back-up lights 921 16 D
Fog lights* 55 A
Interior Interior/front personal
lights

5D
Interior/rear personal
lights* 
8D
Rear interior light* 8F
Door courtesy lights 168 5 D
Vanity lights* 8D
Trunk light 194 3.8 D

606 Alphabetical index
SeatsAdjustment ........................76, 79
Adjustment precautions........... 78
Child seats/child restraint system installation .............. 135
Cleaning ................................ 413
Head restraint..........................81
Properly sitting in the seat ..... 111
Rear seat folding down ...........79
Seat heaters .......................... 383
Service reminder
indicators .............................. 180
Shift lever If the shift lever cannot
be shifted from P................. 533
Transmission ......................... 168
Shift lock system ..................... 533
Side airbags.............................. 113
Side marker lights Replacing light bulbs ............. 471
Switch.................................... 192
Wattage ................................. 560
Side mirror
Adjusting and folding ...............93
Defogger ............................... 248
Smart key system
Entry function ..........................51
Starting the hybrid system..... 157
Spare tire
Inflation pressure................... 449
Storage location .................... 519
Spark plug ................................ 555
Specifications........................... 550
Speedometer ............................ 174
Steering
Column lock release.............. 161 Steering wheel
Adjustment .............................. 90
Audio switches ...................... 254
Stop/tail lights Replacing light bulbs ............. 471
Wattage................................. 560
Storage feature ........................ 367
Storage precautions ................ 224
Stuck If your vehicle becomes stuck ................................... 547
Sun visors ................................ 376
Sunshade Roof ........................................ 99
Switch Emergency flasher switch ..... 484
Fog light switch ..................... 198
Hazard light switch ................ 484
Ignition switch ....................... 157
Light switches ....................... 192
Power door lock switch ........... 67
“POWER” switch ................... 157
Power window switch .............. 95
Window lock switch ................. 95
Wiper and washer switch ...... 200

607
Alphabetical index
Tail lights
Replacing light bulbs ............ 471
Switch ................................... 192
Wattage ................................ 560
Theft deterrent system
Alarm .................................... 108
Immobilizer system............... 106
Tire inflation pressure ............ 449
Tire information
Glossary ............................... 570
Size ...................................... 567
Tire identification number ..... 566
Uniform tire quality grading ............................... 568
Tires Chains .................................. 229
Checking .............................. 443
If you have a flat tire ............. 519
Inflation pressure .................. 449
Inflation pressure sensor ...... 444
Replacing ............................. 519
Rotating tires ........................ 443
Size ...................................... 558
Snow tires............................. 229
Spare tire .............................. 519
Tire pressure warning system........................ 443, 493
Warning light ........................ 493 Tools .........................................519
Total load capacity...................228
Towing
Dinghy towing........................234
Trailer towing.........................233
TRAC .........................................208
Traction control........................208
Transmission Hybrid transmission...............168
If the shift lever cannot be shifted from P......................533
Trip information .......................185
Trip meter .........................174, 185
Trunk Opener ....................................72
Trunk light Trunk light ...............................73
Wattage .................................560
Turn signal lights Replacing light bulbs .............471
Switch....................................170
Wattage .................................560
Vanity lights Vanity lights ...........................377
Wattage .................................560
Vanity mirrors...........................377
Vehicle data recordings ............22
Vehicle identification number ...................................550
Vehicle stability control...........208
VSC............................................208T
