2014 MITSUBISHI OUTLANDER tow

Engine hood
Vehicle care and maintenance 9-3
9
To reduce the possibili
ty of catalytic con-
verter damage:  Use UNLEADED GASOLINE ONLY of the type of recommended in the “Fuel selection”. Do not drive with an extremely low fuel level. Running out of gas could damage the catalytic converter. Do not try to start the engine by pushing or towing the vehicle. If the battery is weak or run down, use jumper cables toproperly start the engine.
 Do not idle the engine with any spark plug wires disconnected or removed, such aswhen performing
diagnosti
c tests.
 Do not idle the engine
for a long time if it
is idling roughly or otherwise obviouslymalfunctioning.  To prevent the catalytic converter from being damaged from unburned gas, do notrace the engine when turning off the igni- tion switch.  Stop driving the vehicle if you think the performance is noticeably low, or the engine has a malfunction such as with theignition, etc. If you are not able to stop driving immediately,
slow down and drive
for only a short time. Have your vehiclechecked at an authorized Mitsubishi Motors dealer or a repair facility of your choice as soon
as possible.
 In unusual situations involving major engine problems, a burning odor may indicate severe and abnormal catalyticconverter overheating.
If this occurs, stop
in a safe place, shut the engine off and let the vehicle cool. Once
the engine is cool,
immediately take your
vehicle to a dealer
or a repair facility of your choice for ser- vice.
N00937501559
Use the engine hood release lever (located under the instrument panel near the driver’s door) to unlock the engine hood. Pull the lever toward you to release the engine hood latch.
CAUTION Damage to the catalyti
c converter can result
if your vehicle is not
kept in proper operating
condition. If the engine
malfunctions or mis-
fires, or if your vehi
cle performance suffers,
have it serviced promptly. Running your vehicle when it is
overheated may result in
damage to the converter and vehicle.WA R N I N G Do not park or run your vehicle in areas where combustible materials such as dry grass or leaves can come
in contact with a
hot exhaust, since a fire could occur. Do not put undercoat paint on the cata- lytic converter.
Engine hood To open
WA R N I N G Never use the release lever to unlatch the engine hood while the
vehicle is in motion.
Do not drive your vehicle unless the engine hood is locked.
BK0200500US.book 3 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Replacement of light bulbs
Vehicle care and maintenance 9-33
9
N00901801131
1. When replacing the bulb on the left side of the vehicle, remo
ve the bolt (A) hold-
ing down the relay box and move the relay box toward the rear of the vehicle. (if so equipped)
2. Turn the cap (B) counterclockwise to remove it. 3. Turn the socket (C) counterclockwise to remove it, and then pull the bulb out of the socket. 4. To install the bulb, perform the removal steps in reverse.
N00900301139
Do not attempt to disass
emble or repair head-
lights, and do not attempt to replace their bulbs.
Headlights (low beam, except for vehicles equipped with high intensity discharge head- lights)/Daytime running lights

(if so equipped) * - Front of the vehicle
*- Front of the vehicle
Headlights (low beam, for vehi- cles equipped with high inten-sity discharge headlights)
WA R N I N G A high voltage is present in the power cir- cuit and in the bulbs and bulb terminals. To avoid the risk of an electric shock, con-tact an authorized
Mitsubishi Motors
dealer whenever repair or replacement is necessary.
BK0200500US.book 33 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Replacement of light bulbs 9-34 Vehicle care and maintenance
9
N00901901099
1. Turn the cap (A) counterclockwise to remove it. 2. Turn the bulb (B) counterclockwise to remove it and then while holding downthe tab (C), pull out the connector (D).
3. To install the bulb, perform the removal steps in reverse.
N00943201359
The alignment of the headlights should bechecked by an authorized Mitsubishi Motorsdealer or a repair fa
cility of your choice.
N00915501171
1. When replacing the bulb on the left side of the vehicle, move
the relay box toward
the rear of the vehicle. (if so equipped)(Refer to “Headlight (low beam, except for vehicles equipped
with high intensity
discharge headlight
s)/Daytime running
light): Step 1” on page 9-33.
2. Turn the socket (A) counterclockwise to remove it, and then pull the bulb out ofthe socket. 3. To install the bulb, perform the removal steps in reverse.
Headlights (high beam) * - Front of the vehicle * - Front of the vehicle
Headlight aim adjustment Front side-marker lights
* - Front of the vehicle
BK0200500US.book 34 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Replacement of light bulbs
Vehicle care and maintenance 9-35
9
N00917301577
When replacing the bulb on the left side of the vehicle, move the relay box toward the rear of the vehicle. (if so equipped)(Refer to “Headlight
(low beam, except for
vehicles equipped with
high intensity dis-
charge headlights)/Daytime running light):Step 1” on page 9-33.) 1. Turn the cap (A) counterclockwise to remove it.
2. Pull out the socket (B), and then pull the bulb out of the socket. 3. To install the bulb, perform the removal steps in reverse.
1. Turn the socket (A
) counterclockwise to
remove it, and then pull the bulb out ofthe socket. 2. To install the bulb, perform the removal steps in reverse.
Parking lights Except for vehicles equipped with high intensity discharge headlights *: Front of the vehicle
Vehicles equipped with high inten-sity discharge headlights *: Front of the vehicle
BK0200500US.book 35 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Replacement of light bulbs
Vehicle care and maintenance 9-37
9
3. Turn the socket counterclockwise to remove it.
4. While holding down the tab (F), pull out the bulb (G). 5. To install the bulb, perform the removal steps in reverse.
N00943701501
1. Open the liftgate.2. Remove the screws (A), and then move the light unit toward the rear of the vehi-cle to unfix the notch (B) and pins (C).
3. Turn the socket counterclockwise and remove it, and then remove the bulb fromthe socket by turning it counterclockwise while pressing in. 4. To install the bulb, perform the removal steps in reverse.
D- Front fog light E- Daytime running lightType 1 Type 2 Type 3
Rear combination lights Front fog light Daytime running light
D- Tail and stop light E- Rear turn signal light
NOTE
 The rear side-marker light uses an LED instead of the bulb. Check with an authorized Mitsubishi Motorsdealer or a repair fa
cility of your choice
when the light needs to be repaired or replaced.
BK0200500US.book 37 ページ ２０１３年２月１２日　火曜日　午前９時４６分

Replacement of light bulbs 9-38 Vehicle care and maintenance
9
N00929101064
1. Push the light unit toward the center of the vehicle body to remove it.
2. Turn the socket (A
) counterclockwise to
remove it, and then pull the bulb out of the socket. 3. To install the bulb, perform the removal steps in reverse.
N00944000360
1. When removing the light unit (A), push ittoward the left side of the vehicle body.
NOTE
 When mounting the light unit, align the notch (F) and pin (G)
on the light unit with
the clip (H) and hole (I) in the body.
Back-up lights
NOTE
 Wrap a cloth around the tip of the screw- driver to keep from scratching the lens.NOTE
 When installing the light unit, first insert the notch (B) into the hole on the body, and then push on the light unit to fit it into place.
License plate lights
BK0200500US.book 38 ページ ２０１３年２月１２日　火曜日　午前９時４６分
