Page 297 of 338

Fuses 9-26 Vehicle care and maintenance
9
Engine compartment fuse location table * - Front of the vehicle
No.
Sym- bol
Electrical system
Capac-ity
1 Front fog lights 15 A 2 Engine 7.5 AEngine compartment fuse location
*
Behind the fuse block cover
*
3 Automatic transaxle 20 A 4 Horn 10 A 5 Alternator 7.5 A 6 Headlight washer 20 A 7 Air conditioning 10 A8 ETV 15 A 9 Security horn 20 A 10 Wiper deicer 15 A 11 — — — 12 Power gate 30 A 13
Daytime running
lights
10 A
14
Headlight
(high beam) (left)
10 A
15
Headlight
(high beam) (right)
10 A
16
Headlight (low/high beam) (left)
Dis- charge
20 A
No.
Sym- bol
Electrical system
Capac-ity
17
Headlight (low/high beam) (right)
Dis- charge
20 A
18
Headlight (low beam) (left)
Halogen 10 A
19
Headlight (low beam) (right)
Halogen 10 A
20 I/C SPRAY 10 A 21 Ignition coil 10 A 22 ENG/POWER 20 A 23 Fuel pump 20 A24 Starter 30 A
*
25 — — — 26
Anti-lock
braking system
40 A
*
27
Anti-lock braking
system
30 A
*
28
Air conditioning condenser fan motor
30 A
*
No.
Sym- bol
Electrical system
Capac-ity
BK0200800US.bo
ok 26 ページ 2013年2月14日 木曜日 午後2時28分
Page 298 of 338

Fuses
Vehicle care and maintenance 9-27
9
* - Fusible link Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications. The table above shows the main equip- ment corresponding to each fuse.
There are no 7.5 A, 25 A or 30 A spare fuses. If a fuse of one of
these capacities blows,
replace it temporarily by borrowing one of the fuses indicated below.7.5 A: 10 A spare fuse 25 A: 20 A spare fuse 30 A: 30 A audio amplifier fuseReplace the borrowed fuse with a fuse that has the correct capacity as soon as possible.
N00901100052 N00954900027
1. Before replacing a fuse, always turn off the electrical item connected to the fuse and turn the ignition switch to the“LOCK” position.
2. There is a fuse puller (A) in the engine compartment fuse block. 3. Clamp it on the fuse you wish to remove, and pull the fuse straight out from the fuse block.
29 Radiator fan motor 40 A
*
30 IOD IOD 30 A 31 Audio amplifier 30 A 32 Diesel 30 A 33 — Spare fuse 10 A 34 — Spare fuse 15 A35 — Spare fuse 20 ANo.
Sym- bol
Electrical system
Capac-ity
Identification of fuse Capacity
Color
7.5 A Brown10 A Red15 A Blue20 A Yellow25 A Natural (White) 30 A
Green (fuse type)/ Pink (fusible link type)
40 A Green
Fuse replacement
BK0200800US.bo
ok 27 ページ 2013年2月14日 木曜日 午後2時28分
Page 299 of 338

Replacement of light bulbs 9-28 Vehicle care and maintenance
9
4. Use the fuse location diagrams and the matching tables, to check the fuse that is related to the problem. If the fuse is not blown, something else must be causingthe problem. Contact an authorized Mit- subishi Motors dealer or a repair facility of your choice to have the problemchecked. 5. Insert a new fuse of the same capacity securely into the appropriate slot.
N00942900219
Before replacing a bulb, be sure the light isoff. Do not touch the glass part of the newbulb with your bare fi
ngers; the oil from your
skin will stay on the glass and dim or destroy the bulb when it gets hot.
N00943000099
The bulb should only be replaced with a newbulb with the same ra
ting and type. The type
and rating are listed on the base of the bulb.
N00950300616
B- Fuse is OKC- Blown fuseCAUTION Never use a fuse with a capacity greater than the one listed or any substitute, such as wire, foil etc. This would cause the circuit wiringto heat up and could cause a fire.
If the replacement fuse blows again after a short time, have the electrical system checked by an authorized Mitsubishi Motors dealer or a repair faci
lity of your choice to
find and correct the cause.
Replacement of light bulbs
CAUTION Bulbs are extremely hot immediately after being turned off. When replacing a bulb, wait for it to coolsufficiently before touching it. You could otherwise be burned.NOTE
If you are unsure of how to carry out the work as required, it is recommended that these procedures be carried out by an autho-rized Mitsubishi Motors dealer or a repair facility of your choice. Be careful not to scratch the vehicle body when removing a light and lens.CAUTION
When it rains, or when the vehicle has been washed, the inside of the lens sometimes becomes temporarily foggy. This is the same phenomenon as when window glass mists up on a humid day, and does not indicate a func-tional problem. When the light is switched on, the heat will remove the fog. However, if water gathersinside the light, please have it checked by an authorized Mitsubishi Motors dealer or a repair facility of your choice.
Bulb capacity Outside
NOTE
Front
BK0200800US.bo
ok 28 ページ 2013年2月14日 木曜日 午後2時28分
Page 300 of 338
![MITSUBISHI LANCER EVOLUTION 2014 10.G Owners Manual Replacement of light bulbs
Vehicle care and maintenance 9-29
9
[Except for vehicles with high intensity dis- charge headlights]
[For vehicles with high intensity discharge headlights][For vehicles w MITSUBISHI LANCER EVOLUTION 2014 10.G Owners Manual Replacement of light bulbs
Vehicle care and maintenance 9-29
9
[Except for vehicles with high intensity dis- charge headlights]
[For vehicles with high intensity discharge headlights][For vehicles w](/manual-img/19/7475/w960_7475-299.png)
Replacement of light bulbs
Vehicle care and maintenance 9-29
9
[Except for vehicles with high intensity dis- charge headlights]
[For vehicles with high intensity discharge headlights][For vehicles with high intensity discharge headlights]
Description
Wattage
ANSI Trade No. or Bulb type
1- Front turn
signal light
21 W WY21W
2- Headlight,
high beam
60 W
9005 HB3
3-
Headlight, low beam
51 W
9006 HB4
4- Front fog
light
55 W H11
5- Front side-
marker and parking light
5 W WY5W
6- Side turn sig-
nal light
5 W —
Description
Wattage or Can-
dle power
ANSI Trade No. or Bulb type
1- Front turn
signal light
21 W WY21W
2-
Daytime run- ning light
27 W 32 cp
1156
3-
Headlight, low/high beam (Dis- charge bulb)
35 W —
4- Front fog
light
55 W H11
5- Front side-
marker and parking light
5 W WY5W
6- Side turn sig-
nal light
5 W —
WA R N I N G Check with an authorized Mitsubishi Motors dealer or a repair facility of your choice when it is necessary to repair a dis- charge headlight or to replace the bulb. The power circuit, bulb and electrodesgenerate high voltages that may cause a severe electrical shock.NOTE
It is not possible to re
pair or replace only the
bulb for the side turn signal light. Check with an authorized Mitsubishi Motors dealer or a repair facility of your choicewhen the light needs to be repaired or replaced.Rear
SC00001000-7.f
m 29 ページ 2013年2月19日 火曜日 午前8時29分
Page 301 of 338
Replacement of light bulbs 9-30 Vehicle care and maintenance
9
N00950400558
N00901800105
1. When replacing the bulb on the driver’s side, remove the bo
lt (A) holding down
the relay box and move the relay boxtoward the rear of the vehicle.
Description
Wattage
ANSI Trade No. or Bulb type
7- High-
mounted stop light
——
8-
License plate light
5 W W5W
9- Back-up light 21 W W21W 10- Tail light 5 W W5W 11-
Tail and stop light
21/5 W W21/5W
12- Rear turn sig-
nal light
21 W W21W
13- Rear side-
marker light
5 W W5W
NOTE
The high-mounted stop light uses LEDs rather than bulbs. For repair and replace- ment, contact an authorized Mitsubishi Motors dealer or a repair facility of yourchoice.
Inside
Description
Wattage
1- Trunk area light 5 W2- Dome light (rear) (if so
equipped)
8 W
3- Dome light (front)/Reading
light
8 W
Headlights (low beam, except for vehicles with high intensity discharge headlights) * - Front of the vehicle
SC00001000-7.f
m 30 ページ 2013年2月19日 火曜日 午前8時29分
Page 302 of 338

Replacement of light bulbs
Vehicle care and maintenance 9-31
9
2. When replacing the bulb on the passen- ger’s side, lift up the coolant reserve tank (B). 3. Turn the bulb (C) counterclockwise, and then remove the headlight bulb with holder.
4. While pressing the tab (D), pull out the bulb (E). 5. To install the bulb, perform the removal steps in reverse.
N00901900076
1. Turn the cap (A) counterclockwise toremove it.
* - Front of the vehicle * - Front of the vehicle
CAUTIONHandle halogen light bulb with care. The gas inside a halogen light bulb is highly pressur-ized, so dropping, knocking, or scratching a halogen light bulb can cause it to shatter. Never hold the halogen light bulb with a bare hand, dirty glove, etc. The oil from your hand could cause the bulb to break the nexttime the headlights are used. If the glass surface is dirty, clean it with alcohol and let it dry completely beforeinstalling the bulb.
Headlights (high beam, except for vehicles with high intensity discharge headlights) * - Front of the vehicle
BK0200800US.bo
ok 31 ページ 2013年2月14日 木曜日 午後2時28分
Page 303 of 338

Replacement of light bulbs 9-32 Vehicle care and maintenance
9
2. Turn the bulb (B) counterclockwise to remove it. 3. While pressing the tab (C), pull out the bulb (D).
4. To install the bulb, perform the removal steps in reverse.
N00902000016
Do not attempt to disassemble or repair head- lights, and do not attempt to replace their bulbs.
N00943200121
The alignment of the headlights should be checked by an authorized Mitsubishi Motors dealer or a repair facility of your choice.
* - Front of the vehicle
CAUTIONHandle halogen light bulb with care. The gas inside a halogen light bulb is highly pressur-ized, so dropping, knocking, or scratching a halogen light bulb can cause it to shatter. Never hold the halogen light bulb with a bare hand, dirty glove, etc. The oil from your hand could cause the bulbto break the next time the headlights are used. If the glass surface is dirty, clean it withalcohol and let it dry completely before installing the bulb.
Headlights (low/high beam, for vehicles with high intensity dis- charge lights)
WA R N I N G A high voltage is present in the power cir- cuit and in the bulbs and bulb terminals.To avoid the risk of an electric shock, con- tact an authorized Mitsubishi Motors dealer or a repair facility of your choicewhenever repair or replacement is neces- sary.
Adjustment of headlight aim
BK0200800US.bo
ok 32 ページ 2013年2月14日 木曜日 午後2時28分
Page 304 of 338
Replacement of light bulbs
Vehicle care and maintenance 9-33
9
N00900300129
1. Turn the cap (A) counterclockwise to remove it.
2. Turn the socket (B) counterclockwise to remove it. 3. Turn the bulb counterclockwise while pressing it and pull it out of the socket. 4. To install the bulb, perform the removal steps in reverse.
N00917300482
1. When replacing the bulb on the driver’s side, remove the bolt (A) holding downthe relay box and move the relay box toward the rear of the vehicle.
Daytime running lights (for vehicles with high intensity dis- charge headlights) * - Front of the vehicle
*- Front of the vehicle
Front side-marker and parking lights (except for vehicles with high intensity discharge head- lights) * - Front of the vehicle
BK0200800US.bo
ok 33 ページ 2013年2月14日 木曜日 午後2時28分
