2014 MERCEDES-BENZ S-Class 360 camera

1, 2, 3 ...
115 V socket ...................................... 329
12 V socket see Sockets
360° camera
Cleaning .........................................3 58
Function/notes ............................. 230
4ETS
see ETS/4ETS (Electronic
Traction System)
4MATIC (permanent four-wheel
drive) .................................................. 218A
ABS (Anti-lock Braking System) Display message ............................ 266
Function/notes ................................ 71
Important safety notes ....................71
Warning lamp ................................. 304
Accident
Automatic measures after an
accident ........................................... 57
Activating/deactivating cooling
with air dehumidification .................156
Activating/deactivating Night
View Assist Plus
With spotlight function ................... 238
Active Blind Spot Assist
Activating/deactivating (on-
board computer) ............................ 261
Display message ............................ 290
Function/informatio n.................... 240
Active Body Control (ABC)
Display message ............................ 288
Function/notes ............................. 214
Active Lane Keeping Assist
Activating/deactivating (on-
board computer) ............................ 262
Display message ............................ 289
Function/informatio n.................... 243
Active multicontour seat ..................125
Active Parking Assist Detecting parking spaces ..............222
Display message ............................ 290
Exiting a parking space ..................224
Function/notes ............................. 221Important safety notes
..................221
Parking .......................................... 223
ADAPTIVE BRAKE ................................. 78
Adaptive Brake Assist Function/notes ................................ 75
Adaptive Damping System (ADS) ..... 217
Adaptive Highbeam Assist Display message ............................ 283
Function/notes ............................. 141
Switching on/off ........................... 142
Adaptive Highbeam Assist PLUS
Display messages ..........................283
Function/notes ............................. 143
Switching on/off ........................... 144
Additional speedometer ...................263
Additives (engine oil) ........................426
Air bags Belt bags .......................................... 63
Cushion air bag s.............................. 51
Display message ............................ 279
Front air bag (driver, front
passenger) ....................................... 48
Important safety notes ....................46
Knee bag .......................................... 49
PASSENGER AIR BAG OFF
indicator lamp .................................. 51
Safety guidelines ............................. 45
Side impact air bag ..........................49
Window curtain air bag ....................50
Air-conditioning system
see Climate control
AIRMATIC
Display message ............................ 287
Function/notes ............................. 216
Air vents
Glove box ...................................... .167
Important safety notes ..................166
Rear ............................................... 167
Setting ........................................... 166
Setting the center air vents ...........166
Setting the side air vents ...............167
Alarm
ATA (Anti-Theft Alarm system) .........81
Switching off (ATA) ..........................81
Switching the function on/off
(ATA) ................................................ 81
Alarm system
see ATA (Anti-Theft Alarm system) 4
Index

Brake fluid
Display message ............................ 272
Notes ............................................. 426
Brake force distribution,
electronic
see EBD (electronic brake force
distribution)
Brake lamps
Display message ............................ 281
Brakes
ABS .................................................. 71
Adaptive Brake Assist ......................75
BAS .................................................. 71
BAS PLUS with Cross-Traffic Assist .72
Brake fluid (notes) .........................426
Display message ............................ 266
EBD .................................................. 78
High-performance brake system ....197
Hill start assist ............................... 175
HOLD function ............................... 212
Important safety notes ..................196
Maintenance .................................. 196
Parking brake ................................ 192
Riding tips ...................................... 196
Warning lamp ................................. 303
Breakdown
see Flat tire
see Towing away
Buttons on the steering wheel .........249 C
California Important notice for retail
customers and lessees ....................24
Calling up a malfunction
see Display messages
Camera
see 360° camera
Car
see Vehicle
Care
360° camera ................................. 358
Carpets .......................................... 361
Car wash ........................................ 354
Display ........................................... 359
Exhaust pipe .................................. 359
Exterior lights ................................ 357Gear or selector lever
....................360
Interior ........................................... 359
Matte finish ................................... 356
Night View Assist Plus ...................359
Notes ............................................. 353
Paint .............................................. 356
Plastic trim .................................... 360
Power washer ................................ 355
Rear view camera .......................... 358
Roof lining ...................................... 361
Seat belt ........................................ 361
Seat cover ..................................... 361
Sensors ......................................... 358
Steering wheel ............................... 360
Trim pieces .................................... 360
Washing by hand ........................... 355
Wheels ........................................... 356
Windows ........................................ 357
Wiper blades .................................. 357
Wooden trim .................................. 360
Car key
see SmartKey
Car wash (care) ................................. 354
CD player/CD changer (on-board
computer) .......................................... 256
Center console Overview .......................................... 37
Stowage space .............................. 317
Center console in the rear
compartment
Stowage compartment ..................319
Central locking
Locking/unlocking (SmartKey) ........85
Chauffeur mode
Display message ............................ 299
Fully reclined position ....................121
General notes ................................ 117
Installing the head restraint ...........119
Moving front-passenger seat into
the chauffeur position .................... 118
Moving the front-passenger seat
into the normal position ................. 120
Removing the head restraint .......... 119
Child-proof locks
Important safety notes ....................69
Rear doors ....................................... 696
Index

ETS/4ETS (Electronic Traction
System)
........................................... 76
Important safety information ...........70
Overview .......................................... 70
PRE-SAFE ®
Brake ............................ .78
STEER CONTROL ............................. 80
Driving systems
360°camera .................................. 230
Active Blind Spot Assist .................240
Active Body Control .......................214
Active Lane Keeping Assist ............243
Active Parking Assist .....................221
AIRMATIC ...................................... 216
ATTENTION ASSIST ........................234
Cruise control ................................ 199
Display message ............................ 287
DISTRONIC PLUS ........................... 201
DISTRONIC PLUS with Steering
Assist ............................................. 210
Driving Assistance package ...........240
HOLD function ............................... 212
Night View Assist Plus ...................236
PARKTRONIC ................................. 218
Rear view camera .......................... 226
Driving tips
AMG ceramic brakes .....................197
Automatic transmission .................182
Brakes ........................................... 196
Break-in period .............................. 170
DISTRONIC PLUS ........................... 208
Downhill gradient ........................... 196
Drinking and driving .......................194
Driving abroad ............................... 138
Driving in winter ............................ .198
Driving on flooded roads ................198
Driving on wet roads ......................198
Exhaust check ............................... 194
Fuel ................................................ 194
General .......................................... 193
Hydroplaning ................................. 198
Icy road surfaces ........................... 198
Limited braking efficiency on
salted road s................................... 196
Snow chains .................................. 387
Symmetrical low bea m.................. 138
The first 1000 miles (1500 km) .....170
Wet road surface ........................... 196DVD video
Operating (on-board computer) .....256 E
EASY-ENTRY feature Function/notes ............................. 129
EASY-EXIT feature
Function/notes ............................. 129
EBD (electronic brake force
distribution)
Display message ............................ 269
Function/notes ................................ 78
ECO display
Function/notes ............................. 195
On-board computer .......................251
ECO start/stop function
Automatic engine start ..................176
Automatic engine switch-off ..........175
Climate control .............................. 155
Deactivating/activating .................177
General information .......................175
Important safety notes ..................175
Introduction ................................... 175
Electronic Stability Program
see ESP ®
(Electronic Stability Program)
Emergency
Automatic measures after an
accident ........................................... 57
Emergency release
Driver's door .................................... 92
Trunk ............................................... 98
Vehicle ............................................. 92
Emergency Tensioning Devices
Function .......................................... .62
Safety guideline s............................. 45
Emissions control
Service and warranty information ....23
Engine
Check Engine warning lamp ........... 308
Display message ............................ 283
ECO start/stop function ................175
Engine number ............................... 423
Irregular running ............................ 178
Jump-starting ................................. 373
Starting problems ..........................178
Starting the engine with the
SmartKey ....................................... 174 Index
9

Vehicle remote malfunction
diagnosis
....................................... 339
Vehicle remote unlocking ..............338
Mechanical key
Function/notes ................................ 86
Inserting .......................................... 87
Locking vehicle ................................ 93
Removing ......................................... 86
Unlocking the driver's door ..............92
Media Interface
see Separate operating instructions
Memory card (audio) .........................256
Memory function In the rear compartment ................134
Seats, steering wheel, exterior
mirrors ........................................... 133
Storing settings (rear
compartment) ................................ 135
Mercedes-Benz Intelligent Drive
360°camera .................................. 230
ABS (Anti-lock Brake System) ..........71
Active Blind Spot Assist .................240
Active Lane Keeping Assist ............243
Active Parking Assist .....................221
Attention Assist ............................. 234
BAS (Brake Assist) ...........................71
BAS PLUS (Brake Assist PLUS)
with Cross-Traffic Assist ..................72
COLLISION PREVENTION ASSIST ....73
Crosswind driving assistance
(vehicles with Magic Body Control )214
Crosswind driving assistance
(vehicles without MAGIC BODY
CONTROL) ....................................... 77
Cruise control ................................ 199
DISTRONIC PLUS ........................... 201
DISTRONIC PLUS with Steering
Assist ............................................. 210
ESP ®
(Electronic Stability Program) .76
General notes ................................ 199
Magic Body Control .......................213
Night View Assist Plus ...................236
PARKTRONIC ................................. 218
PRE-SAFE ®
(anticipatory
occupant protection) .......................56
PRE-SAFE ®
Brake ............................ .78PRE-SAFE
®
PLUS (anticipatory
occupant protection PLUS) ..............56
Rear view camera .......................... 226
ROAD SURFACE SCAN ..................215
Seat belt buckle extender ................61
Message memory (on-board
computer) .......................................... 265
Messages see Display messages
see Warning and indicator lamps
Mirrors
see Exterior mirrors
see Rear-view mirror
see Vanity mirror (in the sun visor)
Mirror turn signal
Cleaning ......................................... 357
Mobile phone
Menu (on-board computer) ............257
Modifying the programming
(SmartKey) ........................................... 86
MOExtended tires .............................. 365
Mounting wheels Lowering the vehicle ......................412
Mounting a new wheel ...................411
Preparing the vehicle .....................408
Raising the vehicle .........................409
Removing a wheel ..........................411
Securing the vehicle against
rolling away ................................... 408
MP3
Operation ....................................... 256
Multicontour seat .............................. 124
Multifunction display Function/notes ............................. 250
Permanent displa y......................... 263
Multifunction steering wheel
Operating the on-board computer .249
Overview .......................................... 35 N
Navigation Menu (on-board computer) ............252
Night View Assist Plus
Activating/deactivating .................238
Cleaning ......................................... 359
Display message ............................ 291
Function/notes ............................. 236 Index
13

Parking lamps
Switching on/off ........................... 139
PARKTRONIC
Deactivating/activating .................220
Driving system ............................... 218
Function/notes ............................. 218
Important safety notes ..................218
Problem (malfunction) ...................221
Range of the sensors .....................219
Warning displa y............................. 220
PASSENGER AIR BAG OFF
Problem (malfunction) .....................55
Problems (malfunction) .................. 279
PASSENGER AIR BAG OFF indicator
lamp ...................................................... 51
Perfume atomizer Operating ...................................... .164
Perfume via l................................... 164
Problem (malfunction) ...................166
Plastic trim (cleaning instructions) .360
Power locks ......................................... 92
Power washers .................................. 355
Power windows see Side windows
PRE-SAFE ®
(anticipatory occupant
protection) Display message ............................ 272
Operation ........................................ .56
PRE-SAFE ®
Brake
Activating/deactivating .................260
Display message ............................ 273
Function/notes ................................ 78
Important safety notes ....................78
Warning lamp ................................. 311
PRE-SAFE ®
PLUS (anticipatory
occupant protection PLUS) Operation ........................................ .56
Program selector button ..................182
Protection of the environment General notes .................................. 22
Pulling away
Automatic transmission .................174
Hill start assist ............................... 175Q
Qualified specialist workshop ...........27 R
Radio Selecting a station .........................254
Radio-wave reception/
transmission in the vehicle
Declaration of conformity ................26
Reading lamp ..................................... 144
Rear compartment Activating/deactivating climate
control ........................................... 155
Setting the air distribution .............160
Setting the airflow .........................160
Setting the air vents ......................167
Setting the temperature ................159
Stowage compartment ..................318
Rear lamps
see Lights
Rear seats
Adjusting ....................................... 113
Adjusting a rear reclining seat .......113
Overview .......................................... 41
Setting the reclined position ..........113
Rear view camera
Cleaning instructions .....................358
Function/notes ............................. 226
Switching on/off ........................... 227
Rear-view mirror
Anti-glare (manual) ........................130
Dipping (automatic) .......................132
Rear window blind ............................325
Rear window defroster Problem (malfunction) ...................163
Switching on/off ........................... 162
Refrigerant (air-conditioning
system)
Important safety notes ..................428
Refueling
Fuel gauge ....................................... 33
Important safety notes ..................187
Notes for AMG vehicles .................425
Refueling proces s.......................... 188
see Fuel
Remote control
Garage door opene r....................... 341
Programming (garage door opener) 342
Replacing bulbs
General notes ................................ 146 Index
15

Dashboard
Function Page
0043
Steering wheel paddle
shifters
183
0044
Combination switch 140
0087
Horn
0085
Instrument cluster 33
0083
DIRECT SELECT lever 179
0084
Overhead control panel 39
006B
Control panel for:
00CA
Lowering the rear
seat head restraints 123
0094
Extending/retracting
the rear roller sunblind 325
0073
PASSENGER AIR BAG
OFF indicator lamp 63
Setting the brightness of
the instrument cluster
lighting and the COMAND
display 006C
Ignition lock 171
Start/Stop button
171 Function Page
006D
Climate control systems 152
006E
Adjusts the steering wheel 127
Steering wheel heating 128
006F
Cruise control lever 200
0070
Electric parking brake 192
0071
Diagnostics connection 26
0072
Opens the hood 348
0073
Light switch 138
0074
Control panel for:
Activating Steering Assist 210
Switching on Active Lane
Keeping Assist 243
Deactivating PARKTRONIC 218
Switching on 360° camera 230
Activating Night View
Assist 23632
Dashboa
rdAt a glance

Object detection
The rear view camera can detect moving and
stationary objects. If, for example, a
pedestrian or another vehicle is detected,
these objects are marked with bars. The
system is only able to detect and mark
stationary objects when your vehicle is
moving. By contrast, stationary objects will
always be detected and marked.
To ensure that you can use the function, it
must be switched on in COMAND (see the
separate operating instructions). 360° camera (surround view)
General notes The 360° camera is a system consisting of
four cameras.
The system analyzes images from the
following cameras:
R Rear view camera
R Front camera
R Two cameras in the exterior rear view
mirrors
The cameras capture the immediate
surroundings of the vehicle. The system
supports you, e.g. when parking or if vision is
restricted at an exit.
The 360° camera images can be shown in full
screen mode or in seven different split-screen
views on the COMAND display. A split-screen
view also includes a top view of the vehicle.
This view is calculated from the data supplied
by the installed cameras (virtual camera).
The six split-screen views are:
R top view and picture from the rear view
camera (130° viewing angle)
R top view and image from the front camera
(130° viewing angle without displaying the
maximum steering wheel angle)
R top view and enlarged rear view
R top view and enlarged front view R
top view and pictures from the rearward
facing mirror cameras (rear wheel view)
R top view and pictures from the forward
facing mirror cameras (front wheel view)
When the function is active and you shift the
transmission from position Dor Rto N, you
see the view which was active before the
360° view in the COMAND display. The
dynamic guidelines are hidden.
When you change between transmission
positions Dand R, you see the previously
selected front or rear view.
Important safety notes The 360°camera is only an aid and may show
a distorted view of obstacles, show them
incorrectly or not at all. The 360°camera is
not a substitute for attentive driving.
You are always responsible for safe
maneuvering and parking. When
maneuvering or parking, make sure that there
are no persons, animals or objects in the area
in which you are maneuvering.
You are always responsible for safety, and
must always pay attention to your
surroundings when parking and
maneuvering. This applies to the areas
behind, in front of and beside the vehicle. You
could otherwise endanger yourself and
others.
The 360° camera will not function or will
function in a limited manner:
R
if the doors are open
R if the exterior mirrors are folded in
R if the trunk lid is open
R in heavy rain, snow or fog
R at night or in very dark places
R if the cameras are exposed to very bright
light
R if the area is lit by fluorescent light or LED
lighting (the display may flicker)
R if the camera lenses fog up, e.g. when
driving into a heated garage in winter,
causing a rapid change in temperature 230
Driving systemsDriving and parking

R
if the camera lenses are dirty or covered
R if the vehicle components in which the
cameras are installed are damaged. In this
event, have the camera position and setting
checked at a qualified specialist workshop.
Do not use the 360° camera in this case. You
can otherwise injure others or cause damage
to objects or the vehicle.
Guide lines are always shown at road level.
The cameras in the front and in the rear area
are each protected by a flap. These flaps are
opened when the 360° camera is activated.
Observe the notes on cleaning
(Y page 358). For technical reasons, the flaps
may remain open briefly after the 360°
camera has been deactivated.
Activation conditions The 360° camera image can be displayed if:
R COMAND is switched on (see the separate
operating instructions)
R the 360° Camera 360° Camera function is activated
i If the 360° camera is activated at speeds
above 19 mph (30 km/h) a warning
message appears.
The warning message disappears if:
R the vehicle's speed falls below 19 mph
(30 km/h). The 360° camera is then
activated.
R the message is confirmed with the
0076 button. Activating the 360° camera using the
function button X
Press button 0043.
Depending on whether position Dor Ris
engaged, the following is shown:
R full screen display with the image from
the front camera
R full screen display with the image from
the rear camera
i You can also switch to the split-screen
view from the full-screen view.
Activating the 360° camera with
COMAND X
To select the 360°
360° Camera Camera from the vehicle
carousel: turn and press the controller.
Depending on whether position Dor Ris
engaged, the following is shown:
R a split screen with top view and the
image from the front camera or
R a split screen with top view and the
image from the rear view camera
Further information on the COMAND
controller can be found in the separate
operating instructions.
Activating the 360° camera using
reverse gear The 360° camera images can be
automatically displayed by engaging reverse
gear. Driving systems
231Driving and parking Z
