2014 MAZDA MODEL 3 5-DOOR display

4–79
When Driving
Rear View Monitor
When there is a steep grade behind the vehicle
When there is a steep upgrade (downgrade) behind the vehicle, the obje\
ct displayed on the
screen appears farther (downgrade: closer) than the actual distance.
A ppear s
far ther than
actual
distanceA ppear s
closer than
actual
distance
Object at actual
position
Object at actual position
Object on scr een
A : D istance between the ve hicle and object displayed on the scr een.
B: A ctual distance between the ve hicle and object. Object on scr een
Three-dimensional object on vehicle rear
Because the distance guide lines are displayed based on a fl at surface, the distance to the
three-dimensional object displayed on the screen is different from the actual distance.
A
A
C B
C B
(A c t u a l d is t a n c e ) B > C = A
S e n s e d di s t ance on scr een A > B > C (S cr een d ispl a y )
(A c t u a l c on d it ion )
.B[EB@%$&""@&EJUJPOJOEC







4–80
When Driving
Rear View Monitor
Picture Quality Adjustment
WARNING
Always adjust the picture quality of the rear view monitor while the vehicle is stopped: Do not adjust the picture quality of the rear view monitor while driving the vehicle.
Adjusting the picture quality of the rear view monitor such as brightness, contrast, color,
and tint while driving the vehicle is dangerous as it could distract your attention from the
vehicle operation which could lead to an accident.
Picture quality adjustment can be done while the shift lever is in rever\
se (R).
There are four settings which can be adjusted including, brightness, con\
trast, tint, and color.
When adjusting, pay suffi cient attention to the vehicle surroundings.
1. Select the (
) icon on the screen to display the tabs.
2. Select the desired tab item.
3. Adjust the brightness, contrast, tint, and color using the slider.
If you need to reset, press the reset button.
4. Select the (
) icon on the screen to close the tab.
.B[EB@%$&""@&EJUJPOJOEC







5–12
Interior Features
Climate Control System
Dual-Zone Automatic Climate Control
Climate control information is displayed on the display.
A ir flow display
Tem per atur e setting display ( dr ive r )
Mode selector
display
A /C m ode display
Tem per atur e setting display ( passenger )
A ir intake selector
( r ecir culated air
position)
A ir intake selector
( outside air position)
D riv er tem per atur e contr ol dial
A UTO switch Mode selector switch
Fan contr ol switch OFF switchWindshield defr oster switch
Rear window defogger switch
P assenger tem per atur e
contr ol dial
D UA L switch
A /C switch
Control Switches
AUTO switch
By pressing the AUTO switch the
following functions will be automatically
controlled in accordance with the selected
set temperature:
 y
 Airfl ow temperature y Amount of airfl ow y Selection of airfl ow mode y Outside/Recirculated air selection y Air conditioner operation
NOTE
AUTO switch indicator light
 y When on, it indicates auto operation,
and the system will function
automatically.
 y If any of the following switches are
operated while in auto control, the
AUTO switch indicator turns off.
 y Mode selector switch y Fan control switch y Windshield defroster switch The functions for switches other than
those operated in the above continue
to operate in auto control.
OFF switch
Pressing the OFF switch shuts off the
climate control system.
.B[EB@%$&""@&EJUJPOJOEC







5–13
Interior Features
Climate Control System
Temperature control dial
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
 y When the DUAL switch is off: Turn the driver temperature control dial
to control the temperature throughout
the entire cabin.
 y When the DUAL switch is on: Turn the driver or front passenger
temperature control dial to
independently control the temperature
on each side of the cabin.
NOTE
 y The climate control system changes to
the individual operation mode ( DUAL
switch indicator light illuminated) by
turning the front passenger temperature
control dial even when the DUAL switch
is off, which allows individual control
of the set temperature for the driver and
front passenger.
 y The temperature units for the
temperature setting display can be
changed in conjunction with the
temperature units for the outside
temperature display. Refer to Outside
Temperature Display on page 4-13 .
Fan control switch
The fan has seven speeds. The selected
speed will be displayed.
Mode selector switch
The desired airfl ow mode can be selected
(page 5-4 ).
NOTE
 y  With the airfl ow mode set to the
position and the temperature control
dial set at a medium temperature,
heated air is directed to the feet and air
at a comparably lower temperature will
fl ow through the central, left and right
vents.
 y To set the air vent to , press the
windshield defroster switch.
 y  In the or position, the air
conditioner is automatically turned on
and the outside air mode is
automatically selected to defrost the
windshield. In the
or position, the
outside air mode cannot be changed to
the recirculated air mode.
A/C switch
Pressing the A/C switch while the AUTO
switch is turned on will turn off the air
conditioning (cooling/dehumidifying
functions).
The air conditioning can be turned on and
off by pressing the A/C switch while the
fan control switch is on.
NOTE
 y  The air conditioning operates when the
A/C switch is pressed even if the fan is
off.
 y The air conditioner may not function
when the outside temperature
approaches 0 °C (32 °F).
Air intake selector
Outside or recirculated air positions can be
selected. Press the switch to select outside/
recirculated air positions.
.B[EB@%$&""@&EJUJPOJOEC







5–21
Interior Features
Audio System
 y The CD player has been designed to
play CDs bearing the identifi cation logo
as shown below. No other discs can be
played.
 y  Use discs that have been legitimately
produced. If illegally-copied discs such
as pirated discs are used, the system may
not operate properly.
 y  Be sure never to touch the signal surface
when handling the CDs. Pick up a CD
by grasping the outer edge or the edge of
the hole and the outer edge.
 y  Do not stick paper or tape on the CD.
Avoid scratching the reverse side (the
side without a label). The disc may not
eject resulting in a malfunction.
 y  Dust, fi nger smudges, and dirt can
decrease the amount of light refl ected
from the signal surface, thus affecting
sound quality. If the CD should become
soiled, gently wipe it with a soft cloth
from the center of the CD to the edge.
 y  Do not use record sprays, antistatic
agents, or household spray cleaners.
Volatile chemicals such as benzine and
thinner can also damage the surface of
the CD and must not be used. Anything
that can damage, warp, or fog plastic
should never be used to clean CDs.
 y  The CD player ejects the CD if the CD
is inserted upside down. Also dirty and/
or defective CDs may be ejected.
 y  Do not insert cleaning discs in the CD
player.
 y  Do not insert any disc with a peel-off
seal affi xed to it.
 y  This unit may not be able to play certain
CD-R/CD-RWs made using a computer
or music CD recorder due to disc
characteristics, scratches, smudges, dirt,
etc., or due to dust or condensation on
the lens inside the unit.
 y  Storing CDs in the vehicle exposed to
direct sunlight or high temperature may
damage the CD-R/CD-RWs, and make
them unplayable.
 y  CD-R/CD-RW exceeding 700 MB
cannot be played.
 y  This unit may not be able to play certain
discs made using a computer due to the
application (writing software) setting
used. (For details, consult the store
where the application was purchased.)
 y  It is possible that certain text data, such
as titles, recorded on a CD-R/CD-RW
may not be displayed when musical data
(CD-DA) is playing.
 y  The period from when a CD-RW is
inserted to when it begins playing is
longer than a normal CD or CD-R.
 y  Completely read the instruction manual
and cautions for CD-R/CD-RWs.
 y  Do not use discs with cellophane tape
adhering, partially peeled off labels,
or adhesive material exuding from the
edges of the CD label. Also, do not use
discs with a commercially-available
CD-R label affi xed. The disc may not
eject resulting in a malfunction.
.B[EB@%$&""@&EJUJPOJOEC







5–22
Interior Features
Audio System
Operating Tips for MP3
NOTE
Supply of this product only conveys a
license for private, non-commercial
use and does not convey a license nor
imply any right to use this product in any
commercial (i.e. revenue-generating)
real time broadcasting (terrestrial,
satellite, cable and/or any other media),
broadcasting/streaming via the Internet,
intranets and/or other networks or in other
electronic content distribution systems,
such as pay-audio or audio-on-demand
applications. An independent license for
such use is required. For details, please
visit http://www.mp3licensing.com.
 y This audio system handles MP3 fi les
that have been recorded on CD-R/CD-
RW/CD-ROMs.
 y  When naming an MP3 fi le, be sure to
add an MP3 fi le extension (.mp3) after
the fi le name.
 y  The number of characters which can be
displayed is restricted.
CAUTION
This unit can only play MP3 fi les that
have an MP3 fi le extension (.mp3)
attached. Do not attach an MP3 fi le
extension to any other type fi le as it
could cause noise to be emitted or a
malfunction in the unit.
Specialized glossary
MP3
Abbreviation for “MPEG Audio Layer
3”. A technical standard for audio
compression as decided by the ISO
*1
MPEG working group. Use of MP3
allows for audio data to be compressed to
approximately a tenth of the source data
size.
*1 International Organization for Standardization
Operating Tips for WMA
WMA is short for Windows Media Audio
and is the audio compression format used
by Microsoft.
Audio data can be created and stored at a
higher compression ratio than MP3.
*
 Microsoft and Windows Media are registered trademarks of Microsoft
Corporation U.S. in the United States
and other countries.
CAUTION
This unit plays fi les with the (.wma) fi le
extension as a WMA fi le. Do not use the
WMA fi le extension for fi les other than
WMA fi les. Otherwise, it could result in
noise or a malfunction.
 y  WMA fi les written under specifi cations
other than the indicated specifi cation
may not play normally or fi les or folder
names may not display correctly.
 y  The fi le extension may not be provided
depending on the computer operating
system, version, software, or settings. In
this case, add the fi le extension “.wma”
to the end of the fi le name, and then
write it to the disc.
.B[EB@%$&""@&EJUJPOJOEC







5–23
Interior Features
Audio System
Operating Tips for AAC
AAC stands for Advanced Audio Coding,
which is standardized voice compression
established by the ISO
*1 working group
(MPEG). Audio data can be created and
stored at a higher compression ratio than
MP3.
*1 International Organization for Standardization
CAUTION
This unit plays fi les with the fi le
extension (.aac/.m4a/.mp4 *2 /.wav *2 )
as an AAC fi le. Do not use the AAC fi le
extension for fi les other than AAC fi les.
Otherwise, it could result in noise or a
malfunction.
*2 Type B
 y  AAC fi les written under specifi cations
other than the indicated specifi cation
may not play normally or fi les or folder
names may not display correctly.
 y  The fi le extension may not be provided
depending on the computer operating
system, version, software, or settings. In
this case, add the fi le extension “.aac ”,
“.m4a”, “.mp4
*2 ”, or “.wav *2 ” to the end
of the fi le name, and then write it to the
memory.
 *2 Type B
Operating Tips for USB device
This unit supports playback of MP3/
WMA/AAC fi les recorded to USB device.
NOTE
 y  Music data (MP3/WMA/AAC (.aac/.
m4a/.mp4*1 /.wav *1 ) format) stored in
a USB mass-storage class compliant
device (such as USB fl ash memory) can
be played.
 y  Playback may not be possible
depending on the type and condition of
the USB fl ash memory even if the audio
fi le complies with the standard above.
 y A copyright protected WMA/AAC fi le
cannot be played in this unit.
 y The order of the music data stored in
the device may differ from the playback
order.
 y To prevent loss or damage of stored
data, we recommend that you always
back up your data.
 y If a device exceeds the maximum
electric current value of 1,000 mA,
it may not operate or recharge when
connected.
 y Do not pull out the USB device while in
the USB mode (only pull it out while in
FM/AM radio or CD mode).
 y The device will not operate if the data is
password protected.
*1 Type B
.B[EB@%$&""@&EJUJPOJOEC







5–26
Interior Features
Audio System
Power/Volume/Sound Controls
Pow er /V olum e/A udio contr ol dialMenu button
A udio display
Power ON/OFF
Switch the ignition to ACC or ON. Press
the power/volume dial to turn the audio
system on. Press the power/volume dial
again to turn the audio system off.
Volume adjustment
To adjust the volume, turn the power/
volume dial. Turn the power/volume dial
to the right to increase volume, to the left
to decrease it. Audio sound adjustment
1. Press the menu button (
) to select
the function. The selected function will
be indicated.
2. Turn the audio control dial to adjust the selected functions as follows:
Indication Setting value
Turn Left Turn
Right
ALC
(Automatic volume adjustment) Level
decrease Level
increase
BASS
(Low pitch sound) Decrease
bass Increase
bass
TREB
(Treble sound) Decrease
treble Increase
treble
FADE
(Front/back volume balance) Shift the
sound to
the front Shift the
sound to
the rear
BAL
(Left/right volume balance) Shift the
sound to
the left Shift the
sound to
the right
BEEP
(Audio operation sound) Off On
BT SETUP
* Select mode
12Hr
24Hr 12Hr
(Flashing) 24Hr
(Flashing)
* Depending on the model, this function
may not be available.
.B[EB@%$&""@&EJUJPOJOEC
