When Driving
Instrument Cluster and Display
Current fuel economy mode
This mode displays the current fuel
economy by calculating the amount of fuel
consumption and the distance traveled.
Current fuel economy will be calculated
and displayed every 2 seconds.
When you've slowed to about 5 km/h (3
mph), - - - L/100 km (- - - mpg) will be
displayed.
Average vehicle speed mode
This mode displays the average vehicle
speed by calculating the distance and the
time traveled since connecting the battery
or resetting the data.
Average vehicle speed will be calculated
and displayed every 10 seconds.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - km/h
(- - - mph) will be displayed for about
1 minute before the vehicle speed is
recalculated and displayed.
.B[EB@%$&""@&EJUJPOJOEC







4–16
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifi cations.
War ning/I ndicator lights will appear in any of the highlighted ar eas
Type A
Type B
C enter of D ashboar d ( W ith Tac hom eter)
( W ithou t Tac hom eter)
Instrum ent C lust er
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–17
When Driving
Instrument Cluster and Display
Warning Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Warning Lights Page
Master Warning Light *1 7-24
Brake System Warning Light *1*2 7-24
ABS Warning Light *1 7-24
Charging System Warning Light *1 7-24
Engine Oil Warning Light *1 7-24
Check Engine Light *1 7-24
(Red) High Engine Coolant Temperature Warning Light
*1
7-24
* Automatic Transaxle Warning Light *1 7-24
Power Steering Malfunction Indicator Light *1 7-24
Air Bag/Front Seat Belt Pretensioner System Warning Light *1 7-24
Low Fuel Warning Light 7-24
Check Fuel Cap Warning Light *1 7-24
Seat Belt Warning Light 7-24
Door-Ajar Warning Light 7-24
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–18
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light
7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–19
When Driving
Instrument Cluster and Display
Indicator Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Indicator Lights Page
* BSM OFF Indicator Light 4-71
(Green) KEY Indicator Light
3-9
Wrench Indicator Light *1 4-20
TCS/DSC Indicator Light *1 4-51 ,
4-52
DSC OFF Indicator Light *1 4-53
(Blue) Low Engine Coolant Temperature Indicator Light
4-20
* Shift Position Indication 4-25
Headlight High-Beam Indicator Light 4-36 ,
4-36
Turn Signal/Hazard Warning Indicator Lights 4-38 ,
4-45
Security Indicator Light *1 3-42
(Amber)
* Cruise Main Indicator Light 4-58
(Green)
* Cruise Set Indicator Light 4-58
.B[EB@%$&""@&EJUJPOJOEC







4–20
When Driving
Instrument Cluster and Display
Signal Indicator Lights Page
Lights-On Indicator Light 4-33
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
Wrench Indicator Light
When the ignition is switched ON, the
wrench indicator light is illuminated and
then turns off after a few seconds.
The wrench indicator light is illuminated
when the preset maintenance period
arrives. Verify the content and perform
maintenance.
Refer to Maintenance Monitor on page
6-20 .
Low Engine Coolant Temperature Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.
If the low engine coolant temperature
indicator light remains illuminated after
the engine has been suffi ciently warmed
up, the temperature sensor could have
a malfunction. Consult an Authorized
Mazda Dealer.
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–22
When Driving
Transaxle
NOTE
 y(For vehicles with type B instrument
cluster*1 ) If the engine speed is about to exceed
the permissible engine speed, the buzzer
sounds.
 Refer to Over Rev. Buzzer on page 7-36 .
*1 To determine which instrument cluster is equipped on your Mazda,
Refer to Meters and Gauges on page
4-9 .
 y If shifting to R is diffi cult, shift back into
neutral, release the clutch pedal, and try
again.
Gear Shift Indication *
The gear shift indication supports you to
obtain optimum fuel economy and smooth
driving. It displays the selected gear
position in the instrument cluster as well
as notifi es the driver to change to the most
suitable gear position corresponding to the
actual driving condition.
Selected gear position Suitable gear position
Indication Condition
Numeral The selected gear position is
displayed.
and numeral Shift up or down to the indicated
gear position is recommended.
CAUTION
Do not rely solely on the shift-up/
shift-down recommendations by
indications. The actual driving
situation might require shift operations
diff erent from indication. To avoid the
risk of accidents, the road and traffi
c
conditions have to be judged correctly
by the driver before shifting.
NOTE
The gear shift indicator turns off when the
following operations are performed.
 y  The vehicle is stopped. y The vehicle is put in neutral. y The vehicle is driven in reverse. y The clutch is not fully engaged when
accelerating from a stop.
 y The clutch pedal remains depressed for
2 seconds or longer while driving.
Recommendations for Shifting (for Vehicles without Gear Shift
Indication)
Upshifting
For normal acceleration, Mazda
recommends these shift points:
Gear Vehicle speed
1 to 2 24 km/h (15 mph)
2 to 3 42 km/h (26 mph)
3 to 4 60 km/h (37 mph)
4 to 5 75 km/h (46 mph)
5 to 6 79 km/h (49 mph)
.B[EB@%$&""@&EJUJPOJOEC







4–25
When Driving
Transaxle
Shift Position Indication
This indicates the selected shift position.
Gear position indication
In manual shift mode, the “M” of the shift
position indication illuminates and the
numeral for the selected gear is displayed.
Warning Light
The warning light turns on when the
system has a malfunction.
Refer to Warning Lights on page 4-17 .
Transaxle Ranges
 y The shift position indicator light in the
instrument cluster illuminates. Refer to
Warning/Indicator Lights on page 4-16 .
 y  The selector lever must be in P or N to
operate the starter.
P (Park)
P locks the transaxle and prevents the front
wheels from rotating.
WARNING
Always set the selector lever to P and set
the parking brake: Only setting the selector lever to the
P position without using the parking
brake to hold the vehicle is dangerous.
If P fails to hold, the vehicle could move
and cause an accident.
CAUTION
