2014 Lexus GS350 Do-it-yourself maintenance /

731-2. Theft deterrent system
GS350_OM_OM30D41U_(U)
1
For safety and security
■System maintenance
The vehicle has a maintenance-free type alarm system.
■Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the fol-
lowing:
●Nobody is in the vehicle.
●The windows and moon roof are closed before the alarm is set.
●No valuables or other personal items are left in the vehicle.
■Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
■Alarm-operated door lock
●When the alarm is operating, the doors ar e locked automatically to prevent intrud-
ers.
●Do not leave the key inside the vehicle when the alarm is operating, and make sure
the key is not inside the vehicle when recharging or replacing the battery.
●A person inside the vehicle opens a door,
the trunk or hood.
●The battery is recharged or replaced when
the vehicle is locked. ( P. 7 5 9 )
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation
of the system cannot be guaranteed.

741-2. Theft deterrent system
GS350_OM_OM30D41U_(U)

75
GS350_OM_OM30D41U_(U)
Instrument cluster2
2. Instrument cluster Warning lights and indicators ............................... 76
Gauges and meters ...................... 81
Multi-information display .......... 84
Head-up display ............................ 92

76
GS350_OM_OM30D41U_(U)
2. Instrument cluster
Warning lights and indicators
◆Instrument cluster
The units used on the speedometer and some indicators may differ depending on
the target region.
◆Center panel
The warning lights and indicators on the instrument cluster, center
panel and outside rear view mirrors inform the driver of the status of
the vehicle’s various systems.
For the purpose of explanation, the following illustration displays all
warning lights and indicators illuminated.

GS350_OM_OM30D41U_(U)
772. Instrument cluster
2
Instrument cluster
◆Outside rear view mirrors (vehicles with BSM)
Warning lights inform the driver of ma lfunctions in the indicated vehicle’s
systems.
Warning lights
*1
(U.S.A.)
Brake system warning light
(  P. 7 0 2 )*1
(U.S.A.)
ABS warning light
( P. 7 0 3 )
*1
(Canada)
Brake system warning light
( P. 7 0 2 )*1
(Canada)
ABS warning light
( P. 7 0 3 )
*1Charging system warning
light ( P. 7 0 3 )*1Electric power steering
system warning light
( P. 7 0 3 )
*1
(U.S.A.)
Malfunction indicator
lamp ( P. 7 0 3 )*1
Slip indicator ( P. 7 0 4 )
*1
(Canada)
Malfunction indicator
lamp ( P. 7 0 3 )*1, 2
(if equipped)
“AFS OFF” indicator
( P. 7 0 4 )
*1SRS warning light
( P. 7 0 3 )*2
(U.S.A.)
Parking brake indicator
( P. 7 0 4 )

78
GS350_OM_OM30D41U_(U)
2. Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine
is on, or after a few seconds. There may be a malfunction in a system if the lights
do not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
*2
(Canada)
Parking brake indicator
(  P. 7 0 4 )*1Seat belt reminder light
( P. 705)
*1Brake system warning light
( P. 7 0 4 )*1Master warning light
( P. 705)
*1
Open door warning light
( P. 705)*1, 2
(if equipped)
“PCS” warning light
( P. 703, 717)
*1Low fuel level warning light
( P. 705)*1Tire pressure warning light
( P. 7 0 6 )

GS350_OM_OM30D41U_(U)
792. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s vari-
ous systems.
Indicators
Turn signal indicator
(  P. 1 8 6 )
(if equipped)
Intuitive parking assist
indicator ( P. 2 4 0 )
(U.S.A.)
Headlight indicator
( P. 1 9 2 )*1
(if equipped)
“AFS OFF” indicator
( P. 1 9 4 )
(Canada)
Tail light indicator
( P. 1 9 2 ) *1, 2Slip indicator
( P. 271, 277)
Headlight high beam
indicator ( P. 1 9 3 )
*1VSC OFF indicator
( P. 2 7 7 )
(if equipped)
Front fog light indicator
( P. 1 9 7 )*1, 3
(if equipped)
“PCS” warning light
( P. 2 8 1 )
Cruise control indicator
(  P. 211, 215)
(U.S.A.)
Parking brake indicator
( P. 1 8 8 )
(if equipped)
Radar cruise control
indicator ( P. 215)
(Canada)
Parking brake indicator
( P. 1 8 8 )
Cruise control “SET”
indicator ( P. 211, 215)
*4
(if equipped)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators ( P. 288)
(if equipped)
LKA (Lane-Keeping
Assist) indicator
( P. 2 3 0 )*1“A I R B A G
ON/OFF”
indicator ( P. 4 7 )

80
GS350_OM_OM30D41U_(U)
2. Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine
is on, or after a few seconds. There may be a malfunction in a system if the lights
do not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster than
usual to indicate that the system is operating.
*4: In order to confirm operation, the BSM ou tside rear view mirror indicators illumi-
nate in the following situations:
• When the engine switch is turned to IGNITION ON mode while the BSM main switch is set to ON.
• When the BSM main switch is set to ON while the engine switch is in IGNI- TION ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators
will turn off after a few seconds.
If the BSM outside rear view mirror indicato rs do not illuminate or do not turn off,
there may be a malfunction with the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
CAUTION
■If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not come on
when you start the engine, this could mean that these systems are not available to
help protect you in an accident, which coul d result in death or serious injury. Have
the vehicle inspected by your Lexus dealer immediately if this occurs.
