Page 1 of 76
KIA Navigation System
QUICK REFERENCE GUIDE3WEND09
, @ 4 - @ ( 2 3 ( $ 0 7 & 3 J O E E ß
y
Page 2 of 76
LOOKING FOR MORE INFORMATION?This Quick Reference Guide does not replace your System
Owner's Manual.
If you require additional information or are unsure of a specific
issue, refer to the System User's Manual for additional information.
iPod ®
iPod ®
is a registered trademark of Apple Inc.
Bluetooth ®
Wireless Technology
The
Bluetooth® Wireless Technology word mark and logos are registered
trademarks owned by
Bluetooth® Wireless Technology SIG, Inc. and any
use of such marks by KIA is under license.
A
Bluetooth® Wireless Technology enabled cell phone is required to use
Bluetooth® Wireless Technology.
HD Radio™ Technology
HD Radio Technology manufactured under license from iBiquity Digital
Corporation. U.S. and Foreign Patents.
HD Radio™ and the HD, HD Radio, and “Arc” logos are proprietary trade-
marks of iBiquity Digital Corp.
All Map Database cannot be copied without permission.
Warning: This is protected by U.S. copyright laws. All rights not expressly granted are
reserved.
You may not otherwise reproduce, modify, and distribute the content without M&Soft,
Inc's prior written consent.
Please ensure that this information is accurately stated and approved for use in this context.
SiriusXM service requires a subscription, sold separately, after 3-month trial
included with vehicle purchase. If you decide to continue your SiriusXM ser-
vice at the end of your trial subscription, the plan you choose will automatically
renew and bill at then-current rates until you call Sirius XM at 1-866-635-2349 to
cancel. See our Customer Agreement for complete terms at www.siriusxm.com.
Programming subject to change. Sirius satellite service is available only to those
at least 18 and older in the 48 contiguous USA, D.C., and PR (with coverage
limitations). Traffic information not available in all markets. See siriusxm.com/traf-
fic for details. Sirius, XM and all related marks and logos are trademarks of Sirius
XM Radio Inc.
WARNING
Driving while distracted can result in a loss of vehicle control that may lead to
an accident, se
vere personal injury, and death. The driver’s primary responsi-
bility is in the safe and legal operation of a vehicle, and use of any handheld
devices, other equipment, or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle or which are not
permissible by law should never be used during operation of the vehicle.”
Infinity is a trademark of Harman International Industries, Inc.
At launch, the Apple iPhone ®
will be the only UVO eServices compatible device.
iPhone ®
is a registered trademark of Apple Inc. Apple iOS6 compatibility expected
early 2013. Additional compatible devices expected late 2013.
App Store is a service mark of Apple Inc. No charge for the UVO eServices app.
App runs on your smartphone cellular data service. Normal data rates will apply.
HD Radio™ and the HD Radio™ logo are proprietary trademarks of iBiquity
Digital Corporation.
24-hour Roadside Assistance is a service plan provided by Kia Motors America,
Inc. Certain limitations apply. Coverage details are available in the Kia Warranty
and Consumer Information Manual. For access to Enhanced Roadside
Assistance, a connected mobile phone via Bluetooth within the cellular service
coverage area is required.
Vehicle Diagnostics do not take the place of regularly scheduled maintenance.
Feature checks powertrain, chassis, and airbag systems only. For factory-recom-
mended maintenance schedule, see the Maintenance Feature of UVO eServices
or the Owner’s Manual.
911 Connect activates after an airbag deployment. Feature requires a connected
mobile phone via Bluetooth. Dependant on cellular service coverage.
The rear-camera display is not a substitute for proper and safe backing-up proce-
dures. The rear-camera display may not display every object behind the vehicle.
Always drive safely and use caution when backing up. , @ 4 - @ ( 2 3 ( $ 0 7 & 3 J O E E ß
y
Page 3 of 76
LOOKING FOR MORE INFORMATION?This Quick Reference Guide does not replace your System
Owner's Manual.
If you require additional information or are unsure of a specific
issue, refer to the System User's Manual for additional information.
iPod ®
iPod ®
is a registered trademark of Apple Inc.
Bluetooth ®
Wireless Technology
The
Bluetooth® Wireless Technology word mark and logos are registered
trademarks owned by
Bluetooth® Wireless Technology SIG, Inc. and any
use of such marks by KIA is under license.
A
Bluetooth® Wireless Technology enabled cell phone is required to use
Bluetooth® Wireless Technology.
HD Radio™ Technology
HD Radio Technology manufactured under license from iBiquity Digital
Corporation. U.S. and Foreign Patents.
HD Radio™ and the HD, HD Radio, and “Arc” logos are proprietary trade-
marks of iBiquity Digital Corp.
All Map Database cannot be copied without permission.
Warning: This is protected by U.S. copyright laws. All rights not expressly granted are
reserved.
You may not otherwise reproduce, modify, and distribute the content without M&Soft,
Inc's prior written consent.
Please ensure that this information is accurately stated and approved for use in this context.
SiriusXM service requires a subscription, sold separately, after 3-month trial
included with vehicle purchase. If you decide to continue your SiriusXM ser-
vice at the end of your trial subscription, the plan you choose will automatically
renew and bill at then-current rates until you call Sirius XM at 1-866-635-2349 to
cancel. See our Customer Agreement for complete terms at www.siriusxm.com.
Programming subject to change. Sirius satellite service is available only to those
at least 18 and older in the 48 contiguous USA, D.C., and PR (with coverage
limitations). Traffic information not available in all markets. See siriusxm.com/traf-
fic for details. Sirius, XM and all related marks and logos are trademarks of Sirius
XM Radio Inc.
WARNING
Driving while distracted can result in a loss of vehicle control that may lead to
an accident, se
vere personal injury, and death. The driver’s primary responsi-
bility is in the safe and legal operation of a vehicle, and use of any handheld
devices, other equipment, or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle or which are not
permissible by law should never be used during operation of the vehicle.”
Infinity is a trademark of Harman International Industries, Inc.
At launch, the Apple iPhone ®
will be the only UVO eServices compatible device.
iPhone ®
is a registered trademark of Apple Inc. Apple iOS6 compatibility expected
early 2013. Additional compatible devices expected late 2013.
App Store is a service mark of Apple Inc. No charge for the UVO eServices app.
App runs on your smartphone cellular data service. Normal data rates will apply.
HD Radio™ and the HD Radio™ logo are proprietary trademarks of iBiquity
Digital Corporation.
24-hour Roadside Assistance is a service plan provided by Kia Motors America,
Inc. Certain limitations apply. Coverage details are available in the Kia Warranty
and Consumer Information Manual. For access to Enhanced Roadside
Assistance, a connected mobile phone via Bluetooth within the cellular service
coverage area is required.
Vehicle Diagnostics do not take the place of regularly scheduled maintenance.
Feature checks powertrain, chassis, and airbag systems only. For factory-recom-
mended maintenance schedule, see the Maintenance Feature of UVO eServices
or the Owner’s Manual.
911 Connect activates after an airbag deployment. Feature requires a connected
mobile phone via Bluetooth. Dependant on cellular service coverage.
The rear-camera display is not a substitute for proper and safe backing-up proce-
dures. The rear-camera display may not display every object behind the vehicle.
Always drive safely and use caution when backing up. , @ 4 - @ ( 2 3 ( $ 0 7 & 3 J O E E ß
y
Page 4 of 76
T a b l e o f C o n t e n t s
Controls and Functions 2
Sound Settings
5
Display Settings
7
FM/AM Mode
8
HD RadioTM Mode
11
SIRIUS Mode
13
CD Mode
17
MP3 CD Mode
18
USB Mode
21
iPod Mode
25
AUX Mode
27
Bluetooth ®
Audio
28
My Music Mode
29
Navigation
32
Bluetooth ®
Wireless Technology
48
Voice Recognition
60 , @ 4 - @ ( < & / > " 7 / 2 3 ( @ * 2 4 J O E E
Page 5 of 76
C o n t r o l s a n d F u n c t i o n s
2
Control Panel
1
7
4
2
5
14
6
1 PWR key VOL Knob
!Ÿ When power is off, press to turn power on.
!Ÿ When power is on, press and hold (over 0.8 seconds) to turn power off.
!Ÿ When power is on, press shortly (under 0.8 seconds) to turn Audio off.
!Ÿ Turn left/right to control volume.
2 F M / A M!Ÿ
Selects FM/AM mode.
!Ÿ Each time the key is pressed, the mode is
changed in order of FM1 ª
FM2 ª
AM ª
FM1.
3 P H O N E
Takes user to phone screen.
4 S A T
Converts to SIRIUS mode
Each time the key is pressed, the mode is
changed in order of SIRIUS1 ª
SIRIUS2 ª
SIRIUS3 ª
SIRIUS1.
5 M E D I A
!Ÿ
Displays CD, MP3, USB, iPod, AUX,
Bluetooth ®
Audio Streaming, My Music modes.
!Ÿ If the media is not connected or a disc is not
inser
ted, corresponding modes will be disabled.
6
Pressed shortly. (under 0.8 seconds)
!Ÿ In FM/AM mode, plays previous/next frequency.
!Ÿ In SIRIUS mode, plays the previous/next channel.
!Ÿ In CD/MP3/USB/iPod/My Music modes, changes
the track, file or chapter.
Pressed and held. (over 0.8 seconds)
!Ÿ In FM/AM mode, continuously changes the frequency until the key is released and
plays the current frequency.
!Ÿ In SIRIUS mode, continuously changes the channel until the key is released
and plays the current channel.
!Ÿ In CD/MP3/USB/iPod/My Music modes, rewinds or fast-forwards the track or file. , @ 4 - @ ( < & / > " 7 / 2 3 ( @ * 2 4 J O E E
Page 6 of 76
3
3
9
10
12
8
11
13
C o n t r o l s a n d F u n c t i o n s
7
Press to insert or eject disc.
8 M A P
V O I C E
Displays the map for the current position.
9 R O U T E
Displays Route menu screen.
10 D E S T
Displays the Destination setup menu.
11 S E T U P
Displays the Setup mode.
12 TUNE knob
!Ÿ In FM/AM mode, changes the frequency.
!Ÿ In SIRIUS mode, changes the channel.
!Ÿ In CD, MP3, USB, iPod, My Music modes,
changes the track, file or chapter.
13 C L O C K
Displays current time and date.
14
SD Card insert slot.
CAUTION
!Ÿ Always give your full attention to driving. Do not operate your system in such a
way that you may be distracted from driving your vehicle. , @ 4 - @ ( < & / > " 7 / 2 3 ( @ * 2 4 J O E E
Page 7 of 76
4
C o n t r o l s a n d F u n c t i o n s
Steering wheel
!Ÿ Activates voice recognition.
When pressed and held. (over 0.8 sec-
onds)
!Ÿ Ends voice recognition.
6
Pressed shortly. (under 1.2 seconds)
!Ÿ When pressed in the phone screen,
displays call history screen.
!Ÿ When pressed in the dial screen,
makes a call.
!Ÿ When pressed in the incoming call
screen, answers the call.
!Ÿ When pressed during call waiting,
switches to waiting call (Call Waiting)
Pressed and held. (over 1.2 seconds)
!Ÿ When pressed in the Bluetooth®
Handsfree phone mode, redials the
last call.
!Ÿ When pressed during a Bluetooth ®
Handsfree call, switches call back to
mobile phone (Private).
!Ÿ When pressed while calling on the
mobile phone, switches call back to
Bluetooth
® Handsfree (Operates only
when Bluetooth® Handsfree is con-
nected).
7 !Ÿ
When pressed during a call, ends the
phone call.
!Ÿ When pressed in the incoming call
screen, rejects the call.
1 V O L + V O L -
Controls the volume.
2 M U T E
Mutes the sound.
3 ' V
Pressed shortly. (under 0.8 seconds)
!Ÿ In FM/AM mode, searches broad-
cast frequencies saved to Presets.
!Ÿ In SIRIUS modes, searches broad-
cast channels saved to Presets.
!Ÿ In CD/MP3/USB/iPod/My Music modes,
changes the track, file or chapter.
Pressed and held. (over 0.8 seconds)
!Ÿ In FM/AM mode, automatically
searches broadcast frequencies
and channels.
!Ÿ In SIRIUS modes, automatically
searches broadcast channels.
!Ÿ In CD/MP3/USB/iPod/My Music modes:
rewinds or fast forwards the track of file.
4 M O D E !Ÿ
Each time this key is pressed, the mode
is changed in order of FM1
ª
FM2 ª
AM
ª SIRIUS1 ª
SIRIUS2 ª
SIRIUS3 ª
USB or iPod ª
AUX ª
Bluetooth ®
Audio
ª My Music.
!Ÿ If the media is not connected or a disc
is not inserted, corresponding modes
will be disabled.
!Ÿ Press and hold the key (over 0.8 sec-
onds) to turn the Audio system on/off.
!Ÿ When power is off, press the key to turn
power back on.
5
When pressed shortly. (under 0.8 sec-
onds) 1
2
34 56
7 , @ 4 - @ ( < & / > " 7 / 2 3 ( @ * 2 4 J O E E
Page 8 of 76
5
S o u n d S e t t i n g s
Press the S o u n d button to
display the sound setting screen.
œ UVO eServices are an optional
feature equipped in select vehicles.
Setting Balance/Fader
Press the S o u n d button Ü
Press
F a d e r / B a l a n c e Ü Set and
press
D o n e .
Use the
, " , A , buttons to
move the cursor on the control screen
to the desired position.
Press
C E N T E R to restore sound to
the center position.
Setting Bass/Mid/Treble
Press the S o u n d button Ü
Press
B a s s / M i d / T r e b l e Ü Set and
press
D o n e .
Use the
A or buttons to adjust the
Bass/Mid/Treble settings.
Setting Volume Ratio
Press the S o u n d button Ü
Press
V o l u m e R a t i o Ü Set and
press
D o n e .
These options are used to set the vol-
ume ratio by selecting from Navigation
Priority/ Audio Priority/Same Ratio.
S o u n d S e t t i n g s , @ 4 - @ ( < & / > " 7 / 2 3 ( @ * 2 4 J O E E
