2014 KIA SOUL Features and Functions Guide

www.kia.com
Consumer - Roadside Assistance
1-800-333-4KIA (4542)
See Back Cover for Vehicle Maintenance Schedule

Always check the Owner’s Manual for complete operating information and safety warnings.FEATURES & FUNCTIONS GUIDE

GETTING TO KNOW YOUR SOUL
Congratulations on Your New Kia Purchase!Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of
comfortable and dependable driving. Kia is committed to quality, innovation, safety and — above all —
your satisfaction.
Using This Guide The information contained in this guide is a brief overview which will help you become familiar with the operation and
features of your new Kia vehicle. The flipbook format facilitates information access, while the detailed illustrations
ensure the instructions are easy to follow.
This Features & Functions Guide and the specific operational and safety information it provides is not a substitute
for your Owner’s Manual. In the interest of your safety and that of your family, and to help you avoid risks that
may result in death or serious injury, Kia reminds you to carefully read your Owner’s Manual in order to fully
familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change vehicle
specifications without notice in advance or after the fact, and assumes no liability in connection with
such changes.

Air Conditioning / Climate Control . . . . .

21
Active ECO System* . . . . . . . . . . . . . .

06
Audio System – Standard* . . . . . . . . . .

16
Audio System - UVO System* . . . . . . . . .

18
Audio System - Navigation System* . . . . .

19
Aux/USB/iPod® Port & Power Outlets . . . .

22
Bluetooth® Wireless Technology* . . . . . .

14
Cruise Control* . . . . . . . . . . . . . . . . .

13
Digital Clock* . . . . . . . . . . . . . . . . . .

20
Folding Rear Seatback. . . . . . . . . . . . .

28
ISG (Idle, Stop, Go) System* . . . . . . . . .

07
Manual Gear Shift* . . . . . . . . . . . . . . .

25
PASSENGER AIRBAG OFF Indicator . . . .

35
Tire Mobility Kit . . . . . . . . . . . . . . . . .

33
Tire Pressure Monitoring System (TPMS) . .

03
Windshield/Rear Wipers & Washers* . . . .

11
SOUL
FEATURES & FUNCTIONS GUIDE
ESSENTIAL FEATURES
VIDEOS & QR CODES
. . . . . . . . . . .

02
INSTRUMENT CLUSTER
Instrument Cluster Overview
. . . . . . . .

03
Tire Pressure Monitoring System (TPMS)
. .

03
Indicators & Warning Lights
. . . . . . . . .

04
Trip Computer / Tripmeter*
. . . . . . . . .

05
LCD Display Controls and Modes*
. . . . .

05
Active ECO System*
. . . . . . . . . . . . .

06
Fuel Efficiency
. . . . . . . . . . . . . . . . .

06
DRIVER’S PANEL
Instrument Panel Dimmer*
. . . . . . . . . .

07
Electronic Stability Control (ESC)
. . . . . .

07
ISG (Idle, Stop, Go) System*
. . . . . . . . .

07
Hill-Start Assist Control
. . . . . . . . . . .

07
Power Windows, Window Lock
& Central Door Lock
. . . . . . . . . . . . .

08
Automatic Door Lock/Unlock
. . . . . . . .

08
Power/Heated Outside Mirrors
. . . . . . .

08
Power Folding Mirrors*
. . . . . . . . . . . .

08
Hood Release Lever and Latch
. . . . . . .

09
Fuel Door Release Lever
. . . . . . . . . . .

09
Engine Start/Stop Button*
. . . . . . . . . .

09
STEERING WHEEL CONTROLS
Headlights & High Beams
. . . . . . . . . .

10
Turn Signals & Fog Lights*
. . . . . . . . . .

10
Windshield Wipers & Washers
. . . . . . . .

11
Rear Wiper & Washer*
. . . . . . . . . . . .

11
Tilt/Telescopic Steering Wheel
. . . . . . .

12
Heated Steering Wheel Button*
. . . . . . .

12
FlexSteer™ Steering Wheel Mode
. . . . . .

12
Audio Controls
. . . . . . . . . . . . . . . .

13
Cruise Control*
. . . . . . . . . . . . . . . .

13
Bluetooth® Wireless Technology
. . . . . .

14
AUDIO SYSTEM
Standard Audio System*
. . . . . . . . . . .

16
UVO System*
. . . . . . . . . . . . . . . . .

18
Navigation System*
. . . . . . . . . . . . . . . . . . . .
19
Advanced (Mood) Lighting Speaker*
. . . .

20
CENTER PANEL
Digital Clock*
. . . . . . . . . . . . . . . . .

20
Aux/USB/iPod® Port*
. . . . . . . . . . . . .

20
Power Outlets*
. . . . . . . . . . . . . . . .

20
Automatic Climate Control*
. . . . . . . . .

21
Manual Climate Control*
. . . . . . . . . . .

23
Automatic Gear Shift
with Sportmatic® Shifting*
. . . . . . . . . .

24
Manual Gear Shift*
. . . . . . . . . . . . . .

25
SEATING
Seat Warmers / Ventilated Seats*
. . . . . .

26
6-Way Manual Adjustable Driver’s Seat
. . .

26
Power Adjustable Driver’s Seat*
. . . . . . .

27
Front Seat Headrest Adjustment
. . . . . .

27
Fold & Unfold Rear Seatback
. . . . . . . .

28
OTHER KEY FEATURES
Smart Key*
. . . . . . . . . . . . . . . . . . .

29
Remote Keyless Entry* (Folding Key)
. . . .

30
Double-Turn Lock/Unlock All*
. . . . . . . .

30
Fuel Cap / Malfunction Indicator
. . . . . .

30
Map/Room Lamps
. . . . . . . . . . . . . .

31
Sunvisor
. . . . . . . . . . . . . . . . . . . .

31
Panoramic Sunroof Operation*
. . . . . . .

32
Rear-Camera Display*
. . . . . . . . . . . .

32
Tire Mobility Kit
. . . . . . . . . . . . . . . .

33
Rear Hatch Release Button
. . . . . . . . . .

34
Child Safety Locks
. . . . . . . . . . . . . .

34
SAFETY
Occupant Detection System (ODS) /
PASSENGER AIRBAG OFF Indicator
. . . .

35
Safety Belts
. . . . . . . . . . . . . . . . . .

36
Safety Belt Retractor Inertial Locks
. . . . .

36
LEGAL DISCLAIMERS
(See Back Inside Cover Page)
MAINTENANCE
(See Back Cover)
*IF EQUIPPED
Driving while drowsy or distracted is dangerous and
should be avoided. Drivers should remain attentive
to driving and exercise caution when using vehicle
systems while driving.

SOUL
FEATURES & FUNCTIONS GUIDE
2
*IF EQUIPPED
How to snap a QR Code
1. With your mobile
device, download
a QR Code Reader
app. With many
devices, you can do
this through an app
Store or Marketplace
2. Open the QR Code
Reader app on your mobile device
3. The app will utilize your device’s camera.
Center the code in the camera viewing area:


O
With some apps, as soon as the app
recognizes the code, it will launch the
corresponding video


O
With other apps, you will have to snap or
“take a picture of ” the code. The app will
then launch the corresponding video


O
For operation specifics, refer to the
instructions that come with the QR Code
Reader app


Kia One Click
Fuel Cap Video

To view a video on your
mobile device, SNAP
this QR Code or visit the
listed website.
Refer to page 2 for more
information.
QR CODE
www.KuTechVideos.com/ps13/2014
REMINDER: When accessing videos on your mobile device, standard cellular
data rates will apply.
*IF EQUIPPED VIDEOS & QR CODES - SMART PHONES, TABLETS AND COMPUTERSKia provides a number of video resources at your disposal to assist you with becoming
familiar with the features and functions found in your Kia vehicle. You can access these
resources by snapping the QR Codes with your smartphone/tablet (mobile devices) or by
visiting the following website: www.KuTechVideos.com/ps13/2014. Continue reading for a
more in-depth look at QR codes and for instructions on how to use them.
What are QR Codes?

A QR Code is a square, 2-dimensional barcode that can be read by mobile devices loaded
with an appropriate barcode or QR Code Reader app. The app reads the barcode image and
then launches/uploads the specific information the code contains, such as URLs, text, photos,
videos, and so much more.
1.
1. If you’re having trouble scanning codes, check the following:


OThe code should be centered and focused in your mobile device’s
camera screen


OConsider moving your device closer to or farther away from the code


OThe code should be well lit, without significant shadow


OAvoid scanning from a significant angle


OConfirm that the device’s app supports 2D QR Code Scanning.
Try another QR Code app; not all apps are created equal
2. After scanning, a “connecting” message appears and then
nothing happens or there’s a “connection error” message.
These messages typically indicate that your device is having
trouble connecting to the Internet
QUICK TIPS
How to Use QR Codes
If you have a mobile device with a QR Code reader app, you can
snap the code with your phone and you’ll be provided a video
with additional information pertaining to the topic. For example,
in the Kia One Click Fuel Cap section, if you would like additional
information, just snap the code with your mobile device to view
the selected Kia Features & Functions Video.

3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED


Kia Tire Pressure
Monitoring System
Video

To view a video on your
mobile device, SNAP
this QR Code or visit the
listed website.
Refer to page 2 for more
information.
QR CODE
www.KuTechVideos.com/ps13/2014
KEY
OUTSPORT
NORMAL
COMFORTx1000 rpm
8 7
6
5
4
3
2
1
0
EF
C H
140120 100 80 60
40
20
0MPH
0 406080100120
140
160
180
200
220km/h
75,35$1*(7$9*
/NPK
03*
03+
H
A
B
D
G
C
C
F
I
E
A Ta c h o m e t e rB SpeedometerC Turn Signal IndicatorsD Gear Shift PositionE OdometerF Tr i p m e t e rG Engine TemperatureH Fuel GaugeI Exterior Temperature
REMINDER: Your vehicle’s
instrument cluster & indicator
light locations may differ
from those in the illustrations.
See your Owner’s Manual for
more details.
(Type A cluster)
Instrument Cluster Overview (Type A)
The indicator
functions as both Low Tire
Pressure Light and TPMS Malfunction Indicator.
The TPMS indicator will illuminate if one or more tires is
significantly underinflated, the vehicle has a spare tire
without TPMS or the outside temperature becomes
significantly colder.
Inflate tire(s) to specifications to turn off Low Tire
Pressure Light
using an accurate digital tire
pressure gauge. See front driver’s door jamb for PSI
specification.
The TPMS Malfunction Indicator
will illuminate after
it blinks for approximately one minute when there is a
problem with the TPMS. See dealer for service.
Tire Pressure Monitoring System (TPMS)


O


OEven with TPMS, tire pressure
should be checked manually at
least once a month. Only adjust
Tire Pressure on “cold tires”


OFor proper maintenance and
optimal fuel economy, maintain
recommended tire inflation
pressures and stay within the load
limits and weight distribution
recommended for your vehicle


OIn winter or cold weather, the
TPMS light may illuminate if the
tire pressure was adjusted to
the recommended tire inflation
pressure during warm weather
QUICK TIPS
REMINDER: Consult your dealer for service if Low Tire Pressure
Light remains illuminated after inflating your tire(s).
For more information on the function
of all indicator and warning lights,
please refer to the Owner’s Manual.
QUICK TIPS
INSTRUMENT CLUSTER

SOUL
FEATURES & FUNCTIONS GUIDE
4
*IF EQUIPPED


For more information
on the function of all
indicator and warning
lights, please refer to
the Owner’s Manual.
8 7 6 5
4
3
2
1
0
x 1000 rpm
CH
140120 100 80
60
40
20
0
MPH
20406080100120
140
160
180
200
220
E
F
REMINDER: Your vehicle’s
instrument cluster & indicator
light locations may differ
from those in the illustrations.
See your Owner’s Manual for
more details.Indicators & Warning Lights
Seat Belt Warning LightElectronic Brake Force Distribution (EBD)
System Warning LightParking Brake & Brake Fluid Warning
LightAnti-lock Braking System (ABS) Warning
LightActive ECO Indicator*Engine Oil Pressure Warning LightElectronic Power Steering Warning LightTailgate Open Warning Light
Charging System Warning LightDoor Ajar Warning LightFuel Cap / Malfunction Indicator
(Check Engine Light) Immobilizer Indicator Light* Low Tire Pressure Light / Tire Pressure
Monitoring System (TPMS) Malfunction
IndicatorEngine Coolant Temperature Warning LightElectronic Stability Control (ESC) IndicatorElectronic Stability Control (ESC) OFF
Indicator*
QUICK TIPS
High Beam IndicatorTail Light Indicator*Front Fog Light Indicator*Cruise ON/OFF Indicator*Cruise SET Indicator*Low Fuel Level Warning LightAirbag Warning LightAuto Stop (ISG System) IndicatorFuel Cap Open Warning Indicator
(In cluster type B . displays in LCD)
(Type B cluster)
INSTRUMENT CLUSTER

5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED Trip Computer / Tripmeter*The Trip Computer is a driver
information system that
displays information related to
driving — such as Odometer,
Tripmeter, Range, Average
Fuel Consumption and Driving
Time — on the display when
the ignition switch is in the ON
position.
To cycle through the LCD Display
modes, press the Mode/Select
button
A.
When in the Trip Computer
mode , press the Move/Reset
button B to cycle through the
screens. When displaying Trip A
or Trip B screens, press and hold
the Move/Reset button
B to
reset the Tripmeter to zero.
REMINDER: Appearance of Tripmeter
display may differ as equipped.
REMINDER: All stored driving
information (except Odometer and
Range) is reset if the battery is
disconnected.
LCD Display Controls and Modes* (Type B cluster only)To cycle through the LCD modes, press the Mode/Select
button
A
A
B
(LCD Display Control buttons located on Steering Wheel)Trip Computer Mode: Displays driving information for
tripmeter, fuel economy, etc.
Tu r n - by -Tu r n M o d e* : Displays the state of the
Navigation system
Master Warning / Service Modes: Informs on upcoming
service intervals , and warning messages related to
TPMS and others
User Settings Mode: Change settings of the doors,
lamps and other featuresA/V Mode*: Displays the state of the A/V System
.
Range
.
Average MPG
.
Instant MPG.
Trip A
.
Average MPH
.
Elapsed Time (E/T ).
Trip B
.
Average MPH
.
Elapsed Time (E/T )Trip Computer First Screen:
RANGE
256
mi.30
20 10
Avg.0
27.4
MPG
(Buttons located on
Steering Wheel)(Type B cluster)

A
INSTRUMENT CLUSTER

SOUL
FEATURES & FUNCTIONS GUIDE
6
*IF EQUIPPED


To view a video on your
mobile device, SNAP
this QR Code or visit the
listed website.
Refer to page 2 for more
information.
Active ECO
Indicator Video www.KuTechVideos.com/ps13/2014


Fuel Economy Video
www.KuTechVideos.com/ps13/2014

QR CODE
Active ECO System*
To help improve your fuel efficiency:


O
O
O
.%2!
O0
O
O)+ !.0!
O/,!!

O!(!.0%*#
O/)++0$(5
O
and at a moderate rate


O
O!!,
O0%.!/
O%*
