1. Hood (P.3-17)
2. Headlight and turn signal—Operation (P.2-34)
— Bulb replacement (P.8-33)
3. Windshield wiper and washer —Operation (P.2-32) —
Maintenance (P.8-25)
4. Moonroof (P.2-54)
5. Power windows (P.2-52)
6. Recovery hook (P.6-16)
7. Fog light (P.2-40)
8. Tires —
Wheel and tires (P.8-36, P.9-9)
— Flat tire (P.6-3)
— Tire pressure monitoring system
(TPMS) (P.2-13, P.5-4)
9. Outside mirrors (P.3-25)
10. Doors —Keys (P.3-2)
— Door locks (P.3-4)
— Intelligent Key system (P.3-6)
— Remote keyless entry system
(P.3-13)
— Welcome light (P.2-57)
Illustrated table of contents0-3
EXTERIOR FRONT
Condition:

Black plate (12,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
0-6Illustrated table of contents
Y51D-V-E01-6C0E2194-048C-4AAF-8C07-A2793D31FC40
JVC0259X
1. Instrument brightness control switch(P.2-39)
2. AFS switch (if so equipped) (P.2-37)
3. Headlight, fog light and turn signal switch (P.2-34)
4. Trip computer switch (P.2-26) 5. TRIP/RESET switch for twin trip od-
ometer (P.2-7)
6. Windshield wiper and washer switch (P.2-32)
7. Shift lever (P.5-14) 8. Vehicle Dynamic Control (VDC) OFF
switch (P.5-102)
9. Rear sunshade switch (if so equipped) (P.2-56)
10. Steering heater switch (if so
equipped) (P.2-40)
11. Trunk lid release switch (P.3-18)
12. Sonar system off switch (if so
equipped) (P.5-95)
13. Warning systems switch (if so
equipped) (P.5-23, P.5-33, P.5-83)
14. IBA OFF switch (if so equipped) (P.5-87)
15. Electric tilting/telescopic steering
wheel lever (P.3-23)
16. Steering-wheel-mounted controls (left side)
—Menu control switch (models with
navigation system)/Audio tuning
switch (models without navigation
system) (P.4-82)
— BACK switch (models with naviga-
tion system) (P.4-82)
— TALK switch (P.4-109)
— Bluetooth
®Hands-Free Phone Sys-
tem (models with navigation system)
(P.4-85)
— Bluetooth
®Hands-Free Phone Sys-
COCKPIT
Condition:

Black plate (19,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
Y51D-V-E01-AE45F736-D98A-4CF8-9862-081B0785133E
Warninglight Name
Page
All-Wheel Drive (AWD) warning
light* 2-11
Anti-lock Braking System (ABS)
warning light2-11
Automatic Transmission check
warning light
2-11
Blind Spot Warning (BSW)/
Blind Spot Intervention (BSI)
system warning light (orange)*2-12
Brake warning light
2-11
Charge warning light2-12
Distance Control Assist (DCA)
system warning light (orange)* 2-12
Engine oil pressure warning
light2-13
Intelligent Cruise Control (ICC)
system warning light (orange)*2-13
Lane Departure Warning (LDW)
light (orange)*
2-13
Low tire pressure warning light 2-13
Master warning light
2-15
Preview Function warning light
(orange)* 2-15Warning
light Name Page
Seat belt warning light and
chime 2-15
Supplemental air bag warning
light
2-15
Vehicle Dynamic Control (VDC)
warning light2-16
Indicator light Name
Page
Adaptive Front lighting System
(AFS) off indicator light* 2-16
Automatic Transmission (AT)
position indicator light
2-16
Blind Spot Intervention (BSI) ON
indicator light
(green)*2-16
ECO drive indicator light
2-17
Exterior light indicator2-17
Front fog light indicator light
2-17
Front passenger air bag status
light2-17
High beam indicator light
2-17
Intelligent Brake Assist (IBA) off
indicator light*2-17
Lane Departure Warning (LDW)
light (green)*2-17Indicator
light Name Page
Malfunction Indicator Light
(MIL) 2-18
Security indicator light 2-18
Turn signal/hazard indicator
lights2-19
Vehicle Dynamic Control (VDC)
off indicator light2-19
*: if so equipped
Illustrated table of contents0-13
WARNING AND INDICATOR LIGHTS
Condition:

Black plate (73,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
2 Instruments and controls
Cockpit...
................................................................ 2-3
Instrument panel ...
................................................. 2-5
Meters and gauges ...
.............................................. 2-6
Speedometer and odometer ...
............................ 2-7
Tachometer ...
...................................................... 2-8
Engine coolant temperature gauge ...
.................. 2-8
Fuel gauge ...
...................................................... 2-9
Warning/indicator lights and
audible reminders ...
............................................. 2-10
Checking bulbs ...
.............................................. 2-10
Warning lights ...
............................................... 2-11
Indicator lights ...
.............................................. 2-16
Audible reminders ...
......................................... 2-19
Dot matrix liquid crystal display ...
........................ 2-19
Indicators for operation ...
................................. 2-22
Indicators for maintenance ...
............................ 2-25
Trip computer ...
................................................ 2-26
Security systems ...
............................................... 2-29
Vehicle Security System ...
................................ 2-29
INFINITI Vehicle Immobilizer System ...
.............. 2-30
Windshield wiper and washer switch ...
................. 2-32
Rain-sensing auto wiper system ...
.................... 2-33
Rear window and outside mirror
defroster switch ...
................................................. 2-34
Headlight and turn signal switch ...
....................... 2-34 Xenon headlights
...
......................................... 2-34
Headlight switch ...
.......................................... 2-35
Turn signal switch ...
........................................ 2-39
Fog light switch ...
........................................... 2-40
Heated steering wheel (if so equipped) ...
............. 2-40
Horn ...
................................................................. 2-41
Heated seats ...
..................................................... 2-41
Climate controlled seats (if so equipped) ...
.......... 2-42
Warning systems switch (if so equipped) ...
.......... 2-43
Intelligent Brake Assist (IBA) OFF switch (if
so equipped) ...
..................................................... 2-44
Vehicle Dynamic Control (VDC) OFF switch ...
......... 2-45
Clock ...
................................................................. 2-45
Adjusting the time ...
....................................... 2-45
Power outlet ...
..................................................... 2-46
Cigarette lighter and ashtrays ...
........................... 2-46
Front ...
............................................................ 2-46
Rear ...
............................................................. 2-47
Storage ...
............................................................. 2-47
Cup holders ...
................................................. 2-47
Sunglasses holder ...
....................................... 2-48
Glove box ...
.................................................... 2-49
Console box ...
................................................. 2-49
Card holder ...
.................................................. 2-50
Rear pocket ...
................................................. 2-50
Condition:
>

Black plate (75,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
Y51D-V-E01-83D46913-7F0C-4CB0-A756-275B43D9E03A
JVC0259X
1. Instrument brightness control switch(P.2-39)
2. AFS switch (if so equipped) (P.2-37)
3. Headlight, fog light and turn signal switch (P.2-34)
4. Trip computer switch (P.2-26) 5. TRIP/RESET switch for twin trip od-
ometer (P.2-7)
6. Windshield wiper and washer switch (P.2-32)
7. Shift lever (P.5-14) 8. Vehicle Dynamic Control (VDC) OFF
switch (P.5-102)
9. Rear sunshade switch (if so equipped) (P.2-56)
10. Steering heater switch (if so
equipped) (P.2-40)
11. Trunk lid release switch (P.3-18)
12. Sonar system off switch (if so
equipped) (P.5-95)
13. Warning systems switch (if so
equipped) (P.5-23, P.5-33, P.5-83)
14. IBA OFF switch (if so equipped) (P.5-87)
15. Electric tilting/telescopic steering
wheel lever (P.3-23)
16. Steering-wheel-mounted controls (left side)
—Menu control switch (models with
navigation system)/Audio tuning
switch (models without navigation
system) (P.4-82)
— BACK switch (models with naviga-
tion system) (P.4-82)
— TALK switch (P.4-109)
— Bluetooth
®Hands-Free Phone Sys-
tem (models with navigation system)
(P.4-85)
— Bluetooth
®Hands-Free Phone Sys-
Instruments and controls2-3
COCKPIT
Condition:

Black plate (82,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
2-10Instruments and controls
Y51D-V-E01-27260C9A-9A53-466E-ACF0-E491D66BB7DC
All-Wheel Drive (AWD) warning light*Lane Departure Warning (LDW) light (orange)
*Exterior light indicator
Anti-lock Braking System (ABS) warning
lightLow tire pressure warning lightFront fog light indicator light
Master warning lightFront passenger air bag status light
Automatic transmission check warning lightPreview Function warning light (orange)*High beam indicator light
Brake warning lightSeat belt warning light and chimeIntelligent Brake Assist (IBA) off indicator
light*
Supplemental air bag warning lightLane Departure Warning (LDW) light (green)*
Blind Spot Warning (BSW)/Blind Spot Inter-
vention (BSI) system warning light (orange)*Vehicle Dynamic Control (VDC) warning lightMalfunction Indicator Light (MIL)
Charge warning lightAdaptive Front lighting System (AFS) off
indicator light*Security indicator light
Distance Control Assist (DCA) system warn-
ing light (orange)*Automatic transmission (AT) position indi-
cator lightTurn signal/hazard indicator lights
Engine oil pressure warning lightBlind Spot Intervention (BSI) ON indicator
light (green)*Vehicle Dynamic Control (VDC) off indicator
light
Intelligent Cruise Control (ICC) system
warning light (orange)*ECO drive indicator light*: if so equipped
CHECKING BULBSY51D-V-E01-AAEEDCA0-B409-469E-9994-4005AFDC3266With all doors closed, apply the parking
brake and push the ignition switch to the
ON position without starting the engine.
The following lights will come on (if so
equipped):
,or,,,,,,
The following lights come on briefly and
then go off (if so equipped):
,or,,,,,,
,,
If any light does not come on, it may
indicate a burned-out bulb or an open
circuit in the electrical system. Have the system checked by an INFINITI retailer.
Some indicators and warnings are also
displayed on the dot matrix crystal display
between the speedometer and tachometer.
(See
“Dot matrix liquid crystal display”
(P.2-19).)
WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS
Condition:

Black plate (91,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
If the security system is malfunctioning,
this light will remain on while the ignition
switch is in the ON position. For additional
information, see“Security systems” (P.2-
29).
Turn signal/hazard indicator
lights
Y51D-V-E01-10692ED4-BF78-4A36-BB9C-69C6F64C78C4The light flashes when the turn signal
switch lever or hazard switch is turned on.
Vehicle Dynamic Control (VDC)
off indicator light
Y51D-V-E01-8CC0C384-2200-42D1-96F4-B39EB909E790The light comes on when the vehicle
dynamic control off switch is pushed to
OFF. This indicates that the vehicle dynamic
control system and traction control system
are not operating.
AUDIBLE REMINDERSY51D-V-E01-3AA97528-2B0C-424D-9825-53B4E0DF87EC
Key reminder chimeY51D-V-E01-3432BABC-6F40-4EB7-AF2E-546928B397CBA chime will sound if the driver side door is
opened while the ignition switch is pushed
to the ACC position. Make sure the ignition
switch is pushed to the OFF position, and
take the Intelligent Key with you when
leaving the vehicle.
Light reminder chimeY51D-V-E01-C5A86822-A3C4-4AAE-BD1F-AF8A1BC20396A chime will sound when the driver side
door is opened with the light switch in the
orposition and the ignition switch
in the ACC, OFF or LOCK position.
Turn the light switch off when you leave the
vehicle.
Parking brake reminder chimeY51D-V-E01-08F79576-EAC7-4A14-A43E-BBC2FF17FDE3The parking brake reminder chime will
sound if the vehicle is driven at more than
4 MPH (7 km/h) with the parking brake
applied. Stop the vehicle and release the
parking brake.
Brake pad wear warningY51D-V-E01-5BF946D6-6498-47D2-8825-4B103B685194The disc brake pads have audible wear
warnings. When a brake pad requires
replacement, it will make a high pitched
scraping sound when the vehicle is in
motion. This scraping sound will first occur
only when the brake pedal is depressed.
After more wear of the brake pad, the
sound will always be heard even if the
brake pedal is not depressed. Have the
brakes checked as soon as possible if the
warning sound is heard.
Y51D-V-E01-1CE230A5-CF30-4B3A-A402-45EE3BF84811
SIC4323
The dot matrix liquid crystal display*1is
located between the tachometer and the
speedometer, and it displays the auto-
matic transmission position indicator, the
cruise control, the Intelligent Cruise Con-
trol (ICC) system (if so equipped), the
Distance Assist (DCA) system (if so
equipped) information, the Intelligent Key
operation information and other warnings
and information.
For details about the automatic transmis-
sion position indicator, see “Indicator
lights” (P.2-16). For details about the cruise
control, see “Cruise control” (P.5-47). For
details about the ICC system, see “Intelli-
Instruments and controls2-19
DOT MATRIX LIQUID CRYSTAL DISPLAY
Condition:

Black plate (106,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
2-34Instruments and controls
.When the windshield glass is coated
with water repellent, the speed of the
rain-sensing auto wipers may be high-
er even though the amount of the
rainfall is small.
. Be sure to turn off the rain-sensing
auto wiper system when you use a car
wash.
. Using genuine wiper blades is recom-
mended for proper operation of the
rain-sensing auto wiper system. (See
“Windshield wiper blades” (P.8-25) for
wiper blade replacement.)
Y51D-V-E01-E0A2D0C4-55C8-4F18-A2DE-1F96531D49A1
SIC4330
To defog/defrost the rear window glass
and outside mirrors, start the engine and
push the switch
*1on. The indicator light
*2will come on. Push the switch again to
turn the defroster off.
It will automatically turn off in approxi-
mately 15 minutes.
CAUTION
When cleaning the inner side of the rear
window, be careful not to scratch or damage
the rear window defroster.
Y51D-V-E01-DC8AE445-0020-408E-A99C-1746C7FA278D
XENON HEADLIGHTSY51D-V-E01-0B345AA3-E59C-4CC5-A9DB-43A856EFBC9D
WARNING
HIGH VOLTAGE
. When xenon headlights are on, they
produce a high voltage. To prevent an
electric shock, never attempt to modify
or disassemble. Always have your xenon
headlights replaced at an INFINITI retai-
ler.
. Xenon headlights provide considerably
more light than conventional headlights.
If they are not correctly aimed, they
might temporarily blind an oncoming
driver or the driver ahead of you and
cause a serious accident. If headlights
are not aimed correctly, immediately
take your vehicle to an INFINITI retailer
and have the headlights adjusted cor-
rectly.
When the xenon headlight is initially
turned on, its brightness or color varies
slightly. However, the color and brightness
will soon stabilize.
.The life of xenon headlights will be
shortened by frequent on-off operation.
REAR WINDOW AND OUTSIDE MIRROR
DEFROSTER SWITCH HEADLIGHT AND TURN SIGNAL SWITCH
Condition:
