2014 HONDA RIDGELINE display

You will also see a ‘‘RELEASE
PARKING BRAKE’’ message on the
multi-information display (see
page).
When driving af ter dark, the
automatic dimming rearview mirror
always reduces the glare f rom
headlights behind you, based in
inputs f rom the mirror sensor. This
feature is always active.
However, it will turn of f when you
shif t into reverse.
90
CONT INUED
On models with navigation system
Parking Brake, Mirrors
On models without
navigation system
On models wit h navigat ion syst emMirrors
133
SENSOR
SENSOR
Driving the vehicle with the parking
brake applied can damage the rear
brakes and hubs. A beeper will sound if
the vehicle is driven with the parking
brake on.
12/09/07 18:08:00 31SJC670_140
Inst rument s and Cont rols

The heating and air conditioning
system in your vehicle provides a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to
discourage vandalism and theft
of your vehicle.
Theclimatecontrolsystemandthe
audio system have a voice control
feature. Refer to the navigation
system manual f or more inf ormation..............
Vents, Heating, and A/C . 146
...............
Climate Control System . 152
..........
Playing the AM/FM Radio . 159
............
AM/FM Radio Reception . 165
................
Playing the XM
Radio . 167
...................................
Playing CDs .174
.......................................
CD Player .175
CD Changer (Models without navigation ..................................
system) .181
CD Changer (Models with navigation ..................................
system) .189
....................
Protecting Your CDs .198
CD Player/Changer Error ...................................
Messages .202
................
Remote Audio Controls . 203
......................
Auxiliary Input Jack .205
.................
Radio Thef t Protection . 205
..........................
Setting the Clock .207
............................
Security System .208
...............................
Cruise Control .210
HomeLink
Universal ................................
Transceiver .213
........
HandsFreeLink. 217 Rearview Mirror with Rearview
.........................
Camera Display .240Bluetooth
On models with navigation system
On RTS, RTL, and Touring models
Features
145
12/09/07 16:43:06 31SJC670_152

This button turns the air
conditioningonandoff.Youwillsee
A/C ON or A/C OFF in the display.When the indicator in the button is
on, air f rom the vehicle’s interior is
sent throughout the system again.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (fresh air mode).
Thesystemshouldbeleftinfresh
air mode under almost all conditions.
Keeping the system in recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to recirculation mode
when driving through dusty or
smoky conditions,
then return to fresh air mode. The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
Turn this dial to increase or decrease
the fan speed and airflow.
Turning this dial clockwise increases
the temperature of the airflow.
Vents, Heating, and A/C
Air Conditioning (A/C) Button Recirculation Button
Fan Control Dial
T emperature Control Dial
Features
147
12/08/09 16:18:38 31SJC670_154

Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page). If it moves near the red mark,
turn of f the A/C until the gauge
reads normally.
The heater uses engine coolant to
warm the air. If the engine is cold,
it will be several minutes before
you feel warm air coming from
the system.
Select .
When you select , the system
automatically switches to the fresh
air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control dial.
Set the temperature to the
lower limit.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode. Select . Make sure the temperature is set
to the lower limit. Turn on the A/C by pressing the
button. You will see A/C ON in
the display. Set the f an to the desired speed.
The ventilation system draws in
outside air, circulates it through the
interior, then exhausts it through
vents near the back window.
1.
2.
3.
4.
5.
1.
2.
3.
1.
2.
3.
4. 76
CONT INUED
Vents, Heating, and A/C
Using the A/C
Ventilation Using the Heater
149
12/08/09 16:19:03 31SJC670_156
Features

To remove fog from the inside of
the windows:
Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C). Turn the fan on.
Press the A/C button.
Select and fresh air mode.
Adjust the temperature to your
pref erence. Set the f an to the desired speed, or
high f or f aster def rosting.
Select . The system
automatically switches to f resh air
mode and turns on the A/C. The
A/C ON indicator will not be
displayed if it was of f to start with.
Adjust the temperature so the
airflow feels warm.
To increase airf low to the
windshield, close the corner vents.
When you switch to another mode
f rom , the A/C turns of f . But
if it was on to start with, it stays on. This f unction helps to increase wiper
perf ormance when the wiper arms
sit in the parked position in snowy or
icy conditions. Your vehicle has heating wires at the
bottom of the windshield to help
heat the wiper blades and the
windshield. If the outside
temperature is near f reezing, the
heater turns on automatically when
you turn the ignition switch to the
ON (II) position. The heater turns
of f automatically when the outside
temperature is above f reezing.
If the interior is very warm, you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in f resh air mode.
1.
2.
3.
4. 1.
2.
3.
4.
Vents, Heating, and A/C
To Def og and Def rost
Dehumidif y the Interior Automatic Heated Wiper Zone
150
12/08/09 16:19:13 31SJC670_157
Features

Set the f an and temperature
controls to maximum level.
Select . The system
automatically switches to f resh air
mode and turns on the A/C.
The A/C ON indicator will not be
displayed if it was of f to start with.
Select .Turning the fan speed control dial
all the way to the left shuts the
system off.
Keep the system of f f or short
periods only.
To keep stale air and mustiness
f rom collecting, you should have
the f an running at all times.
You can adjust the direction of the
air coming from the rear vents in the
back of the center console by
moving the tab in the center of each
vent up-and-down and side-to-side.
You can also adjust the amount of
airf low by turning the dial between
the vents.
To clear the windows f aster, you can
close the dashboard corner vents by
rotating the wheel next to
(passenger’s side) or below it
(driver’s side). This will send more
warm air to the windshield def roster
vents. Once the windshield is clear,
select f resh air mode to avoid
f ogging the windows.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving. 1.
2.
3. T o Remove Exterior Frost or Ice
From the Windows
T o T urn Everything Of f
Rear Ventilation
Vents, Heating, and A/C
151
DIAL
TABS
12/08/09 16:19:26 31SJC670_158
Features

The climate control system can also
be operated by voice control.
See the navigation system manual
f or complete details.
On models with navigation system
Voice Control System
Climate Control System
152
DRIVER’S SIDE
TEMPERATURE
DISPLAY
ON/OFF BUTTON
MODE BUTTON PASSENGER’S SIDE
TEMPERATURE DISPLAY
AIR CONDITIONING BUTTON AUTO BUTTON
DRIVER’S SIDE
TEMPERATURE
CONTROL DIAL
RECIRCULATION BUTTON
WINDSHIELD
DEFROSTER BUTTON FAN CONTROL
BUTTONS
PASSENGER’S SIDE
TEMPERATURE
CONTROL DIAL
RTS, RTL, and Touring models
12/08/09 16:19:32 31SJC670_159
Features

The automatic climate control
system in your vehicle maintains the
interior temperature you select. The
system also adjusts the f an speed
and airf low levels.The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you set either side
temperature to its lower limit
( ) or its upper limit ( ),
the system runs at f ull cooling or
heating only. It does not regulate the
interior temperature.
When you press a f an control button,
the fan is taken out of AUTO mode.
The driver’s and passenger’s side
temperatures should always be set
separately. Turn the desired dial
clockwisetoincreasetheairflow
temperature of that side, and
counterclockwise to decrease it.
Press the Auto button on the front
control panel. You will see AUTO
in the system display.
Adjust the temperature for the
driver’s and passenger’s side
separately, using the desired
temperature control dial.
The passenger’s side temperature
setting does not synchronize to the
driver’s side at any time except when
the system is in the defroster mode
(see page ). 1.
2.
155
CONT INUED
Using A utomatic Climate Control
T emperat ure Cont rol
Climate Control System
153
12/08/09 16:19:41 31SJC670_160
Features
