2014 HONDA RIDGELINE headlight bulb

µµTheheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items on the
pickup bed or pull a trailer,
readjustment may be required.
Adjustmentsshouldbedonebyyour
dealer or other qualif ied technician.
Your vehicle has halogen headlight
bulbs. When replacing a bulb,
handle it by its base, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
The timing belt should be replaced
at the intervals shown in the
Maintenance Minder schedule.
Replace the timing belt every 60,000
miles (100,000 km) if you regularly
drive your vehicle in any of the
f ollowing conditions:
In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C).
Frequently towing a trailer.
CONT INUED
Headlight A iming Replacing a Headlight Bulb
Timing Belt
T iming Belt, L ights
333
TM
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
12/08/09 16:43:02 31SJC670_340
Maint enance

Remove the electrical connector
f rom the bulb by pulling the
connector straight back.
Remove the rubber weather seal
by pulling on the tab.
Unclip the end of the hold-down
wire f rom its slot. Pivot it out of
the way, and remove the bulb.Install the new bulb into the hole,
making sure the tabs are in their
slots. Pivot the hold-down wire
back in place, and clip the end into
the slot.
Install the rubber weather seal
over the back of the headlight
assembly. Make sure it is right
side up.
Push the electrical connector onto
the new bulb. Make sure it is
connected securely. Turn on the
headlights to test the new bulb.
1.
2.
3. 4.
5.
6.
Lights
334
WEATHER SEALCONNECTOR HOLD-DOWN WIRE
BULB
12/08/09 16:43:09 31SJC670_341
Maint enance

Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.Turn on the lights to make sure
the new bulb is working.
Put the inner f ender cover in place.
Install and lock each holding clip
bypushingonthecenter. Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
To change the passenger’s side
bulb, start the engine, turn the
steering wheel all the way to the
lef t, and turn of f the engine. To
change the driver’s side bulb, turn
the steering wheel to the right.
Use a f lat-tip screwdriver to
remove the two holding clips f rom
the inner f ender, and pull the inner
f ender cover back. 5.
6.
1.
2. 3.
4.7.
Replacing a Front T urn Signal/
Hazard/Parking L ight Bulb
Lights
335
HOLDING CLIPS
BULB SOCKET
12/08/09 16:43:18 31SJC670_342
Maint enance

Bulb Replacement..........................
Back-up Lights .337
..............................
Brake Lights .337
.................................
Bed Lights .340
.........
Daytime Running Lights . 336
.................................
Fog Lights .336
Front Turn Signal/Parking/ .......................
Hazard Lights .335
.................................
Headlights .333
.........
High-mount Brake Light . 338
.................
License Plate Lights . 339
Rear Bulbs (Brake/Taillights, Turn Signal/Hazard Lights, ................
Back-up Lights) . 337
............................
Specif ications .387
......................
Bulbs, Halogen .333, 336
...................
Capacities Chart . 386, 387
.............
Carbon Monoxide Hazard . 55
.........................
Cargo Hooks .118, 137
.............................
Carrying Cargo .257
.............
CAUTION, Explanation of . iv
.........................................
CD Care .198
..........................
CD Changer .181, 189 CD Player/Changer Error
...................................
Messages .202
.......................................
CD Player .175
........................
Certif ication Label .384
....................................
Chains, tire .351
Change Oil ........................................
How to .325
......................................
When to .311
....................
Changing a Flat Tire .359
...
Charging System Indicator . 63, 372
............
Checklist, Bef ore Driving . 267
................
Childproof Door Locks . 104
.....................................
Child Saf ety .34
..............................
Booster Seats .52
...................................
Child Seats .41
.....
Important Saf ety Reminders . 34
..........................................
Inf ants .39
..........................
Larger Children .51
.........................................
LATCH .43
......................
Risks with Airbags .35
.............................
Small Children .40
....................................
Tether .43, 48
.........
Where Should a Child Sit? . 35
.......................................
Child Seats .41
.........................................
LATCH .43
..........
Tether Anchorage Points . 48...............
Climate Control System . 152
..............................................
Clock .207
....................................
Coat Hooks .138
.....................
Code, Audio System .205
..................
CO in the Exhaust . 55, 395
......................
Compact Spare Tire .358
.................
Console Compartment . 136
.................
Consumer Inf ormation . 402
.............
Controls, Instruments and . 59
Coolant ........................................
Adding .327
....................................
Checking .251
.........................
Proper Solution .327
...................
Temperature Gauge . 76
..............................
Courtesy Light .143
Crankcase Emissions Control ........................................
System .395
Cruise Control .......................................
Indicator .67
...................................
Operation .210
...................................
Cup Holders .137
.........................
Customer Service .402
...............
DANGER, Explanation of . iv
C
D
II
12/08/09 16:52:41 31SJC670_415
IndexA B C D E F G H I J K L M N O P Q R S T U V W X Y Z

Filters.........................
Dust and Pollen .342
...............................................
Oil .326
.............
Flashers, Hazard Warning . 99
...................
Flat Tire, Changing a . 359
.....................................
Floor Mats .342
Fluids ..........
Automatic Transmission . 329
..........................................
Brake .331
..........................
Power Steering .332
.......................
Rear Differential .386
...................
Transf er Assembly . 387
..................
Windshield Washer . 328
FM Stereo Radio ...................................
Reception .165
.................
Folding the Rear Seats . 125
........................................
Fog Lights .97
..........................
Four-way Flashers .99
..............................
Front Seat .119, 121
............................
Adjusting .119, 121
.....................................
Airbags .9, 25
.......................................
Heaters .126
.................................................
Fuel .244
......................
Fill Door and Cap .246
...........................................
Gauge .76
................
Octane Requirement . 244...............................
Oxygenated .245
........................
Reserve Indicator .68
........................
Tank, Filling the .246
...............................
Fuel Economy .252
Actual Mileage and EPA Fuel Economy Estimates .......................
Comparison .252
......
Calculating Fuel Economy . 254
.............
Fuel Economy Factors . 253
........
Improving Fuel Economy . 253
.....................
Fuses, Checking the .376
...............
Gas Mileage, Improving . 252
Gasoline ...............
Fuel Reserve Indicator . 68
...........................................
Gauge .76
................
Octane Requirement . 244
........................
Tank, Filling the .246
................
Gas Station Procedures . 246
Gauges ...
Engine Coolant Temperature . 76
...............................................
Fuel .76
...............................
Speedometer .76
.................................
Tachometer .76 GAWR (Gross Axle Weight
.......................................
Rating) .292
GCWR (Gross Combined .................
Weight Rating) . 292, 386
............
Gearshif t Lever Positions . 270
......................................
Glove Box .138
GVWR (Gross Vehicle .................
Weight Rating) . 292, 386
....
Halogen Headlight Bulbs . 333,336
...........................
HandsFreeLink
. 217
..............................
HFL Buttons .217
..............
Hazard Warning Flashers . 99G H
IV
12/08/09 16:52:50 31SJC670_417
IndexA B C D E F G H I J K L M N O P Q R S T U V W X Y Z

CONT INUED
.................................
Headlights .94, 95
........................................
Aiming .333
..............
Automatic Lighting Off . 96
.................................
Control Dial .95
............
Daytime Running Lights . 97
..................
High Beam Indicator . 67
.....
High Beams, Turning on . 94, 95
............
Low Beams, Turning on . 95
.........................
Reminder Chime .96
Replacing Halogen ..............................
Bulbs .333, 336
..................................
Turning On .95
............................
Head Restraints .122
.............................
Heated Mirrors .134
...............................
Heaters, Seats .126
.............
Heating and Cooling . 146, 152
.................
High-Low Beam Switch . 94
HomeLink
Universal ................................
Transceiver .213
.......................
Hood, Opening the .250
..............................................
Horn .4,93
...
Identif ication Number, Vehicle . 384Ignition
............................................
Keys .100
.........................................
Switch .102
............
Timing Control System . 396
......................
Immobilizer System .101
.........
Important Safety Precautions . 6
...............................
In-Bed Trunk
. 116
..................
Emergency Opener . 117
............................
Open Indicator .75
.........
Indicators, Instrument Panel . 61
...............
ABS (Anti-lock Brake) . 66
.......................
A/T Temperature .69
....................
Back Window Open . 75
.............................
Bed Lights On .74
Brake (Parking and Brake ....................................
System) .65
........................
Charging System .63
.............................
Cruise Control .67
.................................
Cruise Main .67
...................................
Door Open .75
DRL (Daytime Running ......................................
Lights) .67
...................................
High Beam .67
....................
In-Bed Trunk Open .75
........
Key (Immobilizer System) . 66
Lights On ...................................... 69......................................
Low Fuel .68
........................
Low Oil Pressure .63
......................
Low Tire Pressure .72
...............
Maintenance Minder . 71
Malf unction Indicator Lamp .......................................
(MIL) .63
...........................
Side Airbag Of f .64
.......................................
Seat Belt .62
..........................
Security System .68
...............................................
SRS .64
..............................
Tailgate Open .75
.......................
TPMS System .72, 73
Turn Signal and Hazard ...................................
Warning .66
......................................
VSA OFF .71
.................................
VSA System .70
..........................................
VTM-4 .70
..............................
Washer Level .67
..................
Individual Map Lights . 143
...............................
Inf ant Restraint .39
......................................
Inf ant Seats .39
...................
Inf lation, Proper Tire . 346
INDEXI
V
TM
12/08/09 16:52:55 31SJC670_418
IndexA B C D E F G H I J K L M N O P Q R S T U V W X Y Z
