2014 HONDA ODYSSEY bluetooth

221

Bluetooth® HandsFreeLink®
Phone Settings
Bluetooth® HandsFreeLink®
Phone SettingsHSETTINGS button
 Phone Settings
Set HFL options and features.
HSETTINGS button  Phone Settings
 Bluetooth Device List
You can protect each of the six cell phones with a security PIN.
1.Rotate i to select the phone you
want to add a security PIN to. Press
u.
2.Rotate i to select Edit PIN. Press
u.
3.Enter a new four-digit number.
Rotate i to select OK to enter
the security PIN.

Move w to delete.
4.Re-enter the four-digit number.

The screen returns to the screen
in step 4.
■Editing a Security PIN
1Editing a Security PIN
If the phone is already security PIN protected, you
need to enter the current security PIN before
clearing the PIN or creating a new one.

222

Bluetooth® HandsFreeLink®
Phone Settings
Bluetooth® HandsFreeLink®
HSETTINGS button
 Phone Settings
 Bluetooth Device List
Edit the user name of a paired phone as follows:
1.Rotate i to select a phone you
want to edit. Press u.
2.Rotate i to select Edit Device
Name. Press u.
3.Enter a new name of the phone.

Rotate i or move r to select
OK to enter the name. Press u.

Move w to delete.
■Editing User Name

223

Bluetooth® HandsFreeLink®
Phone Settings
Bluetooth® HandsFreeLink®
HSETTINGS button
 Phone Settings
 Auto Transfer
If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.
Rotate i to select On. Press u.
HSETTINGS button
 Phone Settings
 Auto Answer
You can set HFL to automatically answer an incoming call in four seconds.
Rotate i to select On. Press u.
■Automatic Transferring■Auto Answer

224

Bluetooth® HandsFreeLink®
Phone Settings
Bluetooth® HandsFreeLink®
HSETTINGS button
 Phone Settings
 Ring Tone
You can change the ring tone setting.
Rotate i to select your desired
setting item. Press u.
The following items are available:
•Fixed: The fixed ring tone sounds from the speaker.
•Mobile Phone: The ring tone stored in the connected cell phone sounds from the
speaker.
•Off: No ring tones sound from the speaker.
■Ring Tone

225

Bluetooth® HandsFreeLink®
Phone Settings
Bluetooth® HandsFreeLink®
HSETTINGS button
 Phone Settings
 Automatic Phone Sync
Rotate i to select On or Off. Press
u.
HSETTINGS button
 Phone Settings
 Use Contact Photo
You can display a caller's picture on an incoming call screen.
Rotate i to select On. Press u.
■Automatic Phone Sync setting■Use Contact Photo
Phone settings
All Phone
Auto Transfer
Auto Answer
Ring Tone
Automatic Phone Sy
Use Contact PhotoOn
Off
Default

226

Bluetooth® HandsFreeLink®
Making a Call
Bluetooth® HandsFreeLink®
Making a CallYou can make calls by inputting any phone number, or by using the imported
phonebook, call history, speed dial entries, or redial.
1Making a Call
Any voice-tagged speed dial entry, phonebook
name, or number can be dialed by voice from
most screens. Press the d button and say ”Call“
and the voice tag name, ”Call by name“ and the
phonebook name, or ”Call“ and the phone
number.
The maximum range between your phone and
vehicles is 30 feet (10 meters).
Once a call is connected, you can hear the voice
of the person you are calling through the audio
speakers.

227

Bluetooth® HandsFreeLink®
Making a Call
Bluetooth® HandsFreeLink®
HMENU button (on Phone Settings)
 Phonebook
1.The phonebook is stored
alphabetically. Move r to Search.

You can use the keyboard on
the touch screen for an
alphabetical search.
2.Rotate i to select a number.
Press u.

Dialing starts automatically.
■Using the Phonebook
1Using the Phonebook
This function is disabled while the vehicle is
moving. However, you can call a stored voice-
tagged speed dial number, phonebook name, or
number using voice commands.
2Limitations for Manual Operation P. 205
2Setting Up Speed Dialing P. 213

228

Bluetooth® HandsFreeLink®
Making a Call
Bluetooth® HandsFreeLink®
HMENU button (on Phone Settings)
 Dial
1.Rotate i to select a number.
Press u.
2.Rotate i to select h. Press u.
HMENU button (on Phone Settings)  Redial
You can display a caller's picture on an incoming call screen.
Rotate i to select Dial. Press u.
Dialing starts automatically.
■Entering a Phone Number
1Entering a Phone Number
This function is disabled while the vehicle is
moving. However, you can call a stored voice-
tagged speed dial number, phonebook name, or
number using voice commands.
2Limitations for Manual Operation P. 205
2Setting Up Speed Dialing P. 213
■Using Redial
