2014 HONDA FIT tailgate

91
uuSecurity SystemuSecurity System Alarm
*
Controls
■Setting the security system alarm
The security system alarm automatically sets when the following conditions have
been met:
•The ignition switch is in LOCK
(0, and the key has been removed from the
ignition switch.
•The hood is closed.
•All doors and the tailgate are locked with the key or the remote transmitter.
■When the security system alarm sets
The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system alarm is set.■To cancel the security system alarm
The security system alarm is canceled when the vehicle is unlocked using the key or
remote transmitter. The security system alarm indicator goes off at the same time.
■The PANIC button on the remote
transmitter
If you press the PANIC button for
approximately one second, the following will
occur for about 30 seconds:
•The horn sounds.
•Some exterior lights flash.
■Canceling panic mode
Press any button on the remote transmitter, or turn the ignition switch to ON
(w.
■Panic Mode
*
1Security System Alarm
*
Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:•Unlocking the door with the lock tab or the master
door lock switch.
If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key or remote transmitter.
Do not attempt to alter this system or add another
device to it.
PANIC
Button* Not available on all models

108
uuAdjusting the SeatsuRear Seats
Controls
Rear Seats
Pull the lever on the right to change the angle
of the right half of the seat-back, and left for
the left half.
1.Unlatch the detachable anchor from the
anchor buckle and store the detachable
anchor in the retractor housing.
2.Pull the release lever and fold down the
seat-back.
■Adjusting the Rear Seat-BacksRelease Lever■Folding Down the Rear Seats
1Folding Down the Rear Seats
The rear seat-backs can be folded down to
accommodate bulkier items in the cargo area.
Never drive with a seat-back folded down and the
tailgate open.
2Exhaust Gas Hazard P. 61
To lock a seat-back upright, push it backwards until it
locks. When returning a seat-back to it’s original
position, push it firmly back. Also, make sure all rear
shoulder belts are positioned in front of the seat-
back, and the center shoulder belt is re-positioned in
the guide.
Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
front passenger seat weight sensor to work
improperly.
2Side Airbag Off Indicator P. 47
Anchor
Buckle
Latch Plate
Release Lever

112
uuInterior Lights/Interior Convenience ItemsuInterior Lights
Controls
The light comes on when you open the
tailgate.
■Cargo Area Light

Continued
155
uuBefore DrivinguDriving Preparation
Driving
•Store or secure all items on board properly.
uCarrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, stopping distance, and tires, and make it unsafe.
2Maximum Load Limit P. 157
•Do not pile items higher than the seat height.
uThey can block your view and may be thrown forward in the event of sudden
braking.
•Do not place anything in the front seat footwells. Make sure to secure the floor
mat
*.
uAn object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.
•If you have any animals on board, do not let them move around in the vehicle.
uThey may interfere with driving and a crash could occur.
•Securely close and lock all doors and the tailgate.2Locking/Unlocking the Doors from the Inside P. 82
•Adjust your seating position properly.
uAdjust the head restraint, too.
2Adjusting the Seats P. 103
2Adjusting the Head Restraints P. 105
•Adjust the mirrors and steering wheel properly for your driving.
uAdjust them while sitting in the proper driving position.
2Adjusting the Mirrors P. 102
2Adjusting the Steering Wheel P. 101
■Interior Checks
1Interior Checks
The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the cargo area, have the aiming
readjusted at a dealer or by a qualified technician.
* Not available on all models

uuEmergency Towingu
266Handling the Unexpected
If you cannot open the tailgate use the following procedure.
1.Use a flat-tip screwdriver and remove the
cover on the back of the tailgate.
2.To open the tailgate, push the tailgate
while pushing the lever to the unlocking
direction.■When You Cannot Open the TailgateModels without tailgate key cylinder
1When You Cannot Open the Tailgate
What to do-Following up
After taking these steps, contact a dealer to have the
vehicle checked.
When you open the tailgate from inside, make sure
there is enough space around the tailgate, and it
does not hit anyone or any object.
Cover
Lever
Lock Unlock

280Index
Bulb Replacement..................................... 212
Brake Light, Taillight, Back-Up Light and
Rear Turn Signal Lights........................... 216
Fog Lights ................................................ 214
Headlights ............................................... 212
High-Mount Brake Light .......................... 217
Rear License Plate Light............................ 217
Bulb Specifications.................................... 268CCarbon Monoxide Gas................................ 61
Cargo Floor Box........................................ 115
Cargo Hooks.............................................. 117
Carrying Cargo.................................. 155, 157
CD Player................................................... 129
Certification Label.................................... 270
Changing Bulbs......................................... 212
Charging System Indicator................. 65, 256
Child Safety................................................. 49
Childproof Door Locks ............................... 83
Child Seat.................................................... 49
Booster Seats ............................................. 60
Child Seat for Infants ................................. 51
Child Seat for Small Children ..................... 52
Installing a Child Seat with a Lap/Shoulder
Seat Belt .................................................. 56
Larger Children .......................................... 59
Rear-facing Child Seat ............................... 51
Selecting a Child Seat ................................ 53
Childproof Door Locks................................ 83Cleaning the Exterior............................... 235
Cleaning the Interior................................ 234
Clock............................................................ 76
Clutch Fluid............................................... 210
Coat Hook................................................. 116
Compact Spare Tire.......................... 239, 269
Controls....................................................... 75
Coolant (Engine)...................................... 206
Adding to the Radiator ............................ 207
Adding to the Reserve Tank..................... 206
High Temperature Indicator ....................... 67
Low Temperature Indicator........................ 67
Overheating ............................................ 254
Creeping (Automatic Transmission)........ 164
Cruise Control........................................... 173
Indicator.................................................... 71
Cup Holders.............................................. 114
Customer Service Information................. 278
DDaytime Running Lights............................ 96
Dead Battery............................................. 251
Defrosting the Windshield and
Windows................................................. 120
Devices that Emit Radio Waves............... 271
Dimming
Headlights ................................................. 95
Rearview Mirror....................................... 102
Dipstick (Engine Oil)................................. 202
Directional Signals (Turn Signal)............... 95Door Mirrors............................................. 102
Doors.......................................................... 77
Auto Door Locking.................................... 84
Auto Door Unlocking ................................ 84
Door and Tailgate Open Indicator ....... 25, 68
Keys.......................................................... 77
Locking/Unlocking the Doors from the
Inside ...................................................... 82
Locking/Unlocking the Doors from the
Outside ................................................... 79
Lockout Prevention System ....................... 81
DOT Tire Quality Grading........................ 225
Driving...................................................... 153
Automatic Transmission .......................... 164
Braking ................................................... 181
Cruise Control ........................................ 173
Shifting Gear .......................... 165, 167, 171
Starting the Engine ................................. 161
Dust and Pollen Filter.............................. 233
EElectric Power Steering (EPS) System
Indicator ........................................... 68, 258
Electronic Stability Control (ESC)............ 176
Emergency................................................ 264
Emissions Testing (Readiness Codes)...... 273
Engine....................................................... 270
Coolant .................................................. 206
Jump Starting ......................................... 251
Oil .......................................................... 201

282Index
Heating and Cooling System.................... 118
Cooling ................................................... 120
Defrosting the Windshield and
Windows ............................................... 120
Dust and Pollen Filter ............................... 233
Heating ................................................... 119
HFL (HandsFreeLink®)............................... 140
High-Beam Indicator.................................. 70IIdentification Numbers............................ 270
Engine and Transmission.......................... 270
Vehicle Identification ............................... 270
Ignition Switch............................................ 94
Illumination Control................................... 99
Knob ......................................................... 99
Immobilizer System.................................... 90
Indicator .................................................... 70
Indicators..................................................... 64
ABS (Anti-lock Brake System) ..................... 67
Charging System ............................... 65, 256
CRUISE CONTROL .............................. 71, 174
CRUISE MAIN .................................... 71, 173
Daytime Running Lights ............................. 71
Door and Tailgate Open....................... 25, 68
EPS (Electric Power Steering) System .. 68, 258
Fog Light ................................................... 70
High Temperature...................................... 67
High-Beam ................................................ 70
Immobilizer System .................................... 70Lights On .................................................. 70
Low Fuel ................................................... 66
Low Oil Pressure ................................ 64, 256
Low Temperature ...................................... 67
Low Tire Pressure .............................. 69, 178
Maintenance Minder
TM...................... 71, 195
Malfunction Indicator Lamp............... 65, 257
Parking Brake and Brake System ........ 64, 258
Seat Belt Reminder .............................. 27, 66
Security System Alarm ............................... 71
Shift Position ............................................. 65
Side Airbag Off ................................... 47, 69
Supplemental Restraint System ............ 45, 67
TPMS ................................................ 69, 180
Transmission ............................................. 66
Turn Signal ................................................ 70
VSA® (Vehicle Stability Assist)
System ............................................ 68, 176
VSA® OFF .......................................... 68, 177
Washer Level ............................................. 71
Information.............................................. 267
Information Display................................... 73
Instrument Panel........................................ 63
Brightness Control..................................... 99
Interior Lights........................................... 111
Interior Rearview Mirror.......................... 102
JJack (Wheel Nut Wrench)................ 238, 242
Jump Starting........................................... 251
KKeyless Lockout Prevention....................... 81
Keys............................................................. 77
Lockout Prevention ................................... 81
Rear Door Won’t Open ............................. 83
Remote Transmitter .................................. 79
Types and Functions.................................. 77
Won’t Turn ............................................... 17
Kickdown (Automatic Transmission)...... 164LLATCH (Child Seats)................................... 54
Lights.................................................. 95, 212
Bulb Replacement ................................... 212
Daytime Running Lights ............................ 96
Fog Lights ................................................. 96
High-Beam Indicator ................................. 70
Interior.................................................... 111
Light Switches........................................... 95
Lights On Indicator.................................... 70
Turn Signals .............................................. 95
Load Limits............................................... 157
Locking/Unlocking..................................... 77
Auto Door Locking/Unlocking ................... 84
Childproof Door Locks .............................. 83
From Inside ............................................... 82
From Outside ............................................ 79
Keys.......................................................... 77
Lockout Prevention System ....................... 81
Using a Key............................................... 80

283Index
Lockout Prevention System....................... 81
Low Battery Charge................................. 256
Low Fuel Indicator..................................... 66
Low Oil Pressure Indicator................. 64, 256
Lower Anchors........................................... 54
Lubricant Specifications Chart................ 269
Luggage (Maximum Load Limit)............. 157MMaintenance............................................ 191
Battery .................................................... 231
Brake/Clutch Fluid ................................... 210
Cleaning ................................................. 234
Coolant .................................................. 206
Heating and Cooling System ................... 233
Maintenance Minder
TM............................ 195
Oil .......................................................... 202
Precautions ............................................. 192
Radiator .................................................. 207
Remote Transmitter ................................ 232
Replacing Light Bulbs .............................. 212
Safety ..................................................... 193
Service Items ........................................... 197
Tires........................................................ 222
Transmission Fluid ................................... 208
Under the Hood ...................................... 199
Malfunction Indicator Lamp............. 65, 257
Manual Transmission............................... 171
Map Lights................................................ 111
Maximum Load Limit............................... 157Meters, Gauges........................................... 72
Mirrors....................................................... 102
Adjusting................................................. 102
Door........................................................ 102
Exterior.................................................... 102
Interior Rearview ..................................... 102
Modifications (and Accessories).............. 190
MP3................................................... 129, 133
NNumbers (Identification).......................... 270OOdometer.................................................... 73
Oil (Engine)............................................... 201
Adding .................................................... 203
Checking ................................................. 202
Displaying Oil Life .................................... 195
Low Oil Pressure Indicator.................. 64, 256
Recommended Engine Oil........................ 201
Viscosity .................................................. 201
Opening/Closing
Hood ....................................................... 200
Power Windows ........................................ 92
Tailgate ..................................................... 88
Overheating.............................................. 254
PPaddle Shifters (Sequential Shift
Mode)................................................ 13, 169
Panic Mode................................................. 91
Parking...................................................... 185
Parking Brake........................................... 181
Parking Brake and Brake System
Indicator............................................ 64, 258
Passenger Airbag Off Indicator................. 46
Passing Indicators....................................... 95
Precautions While Driving....................... 163
Rain ........................................................ 163
Pregnant Women....................................... 32
Puncture (Tire).................................. 239, 245RRadiator.................................................... 207
Radio (FM/AM)......................................... 127
Radio Data System (RDS)......................... 128
RDS (Radio Data System)......................... 128
Readiness Codes (Emissions Testing)....... 273
Rear Defogger/Heated Door Mirror
Button..................................................... 100
Rear Seats (Folding Down)...................... 108
Rearview Mirror....................................... 102
Refueling.................................................. 186
Fuel Gauge................................................ 72
Gasoline .......................................... 186, 268
Low Fuel Indicator ..................................... 66
Regulations............................... 179, 225, 271
