2014 HONDA FIT spark plugs replace

197
uuMaintenance Minder
TMuTo Use Maintenance Minder
TM
Continued
Maintenance
■Maintenance Service Items
1Maintenance Service Items•Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.•Inspect idle speed every 160,000 miles (256,000
km).•Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.
Maintenance Minder Message Maintenance
Minder Indicator
Sub Items Main Item
*1: If a message SERVICE does not appear more than 12 months after the display is reset, change the
engine oil every year.
*2: Canadian A/T models only
# : See information on maintenance and emissions warranty.CODE
Maintenance Main Items
A
●Replace engine oil
*1
B
●Replace engine oil and oil filter●Inspect front and rear brakes/service as necessary●Check parking brake adjustment●Inspect tie rod ends, steering gearbox, and boots●Inspect suspension components●Inspect driveshaft boots●Inspect brake hoses and lines (Including ABS/VSA)●Inspect all fluid levels and condition of fluids●Inspect exhaust system
#
●Inspect fuel lines and connections
#
●Check expiration date for TRK bottle
*2
*3: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*4: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and
from diesel-powered vehicles, replace every 15,000 miles (24,000 km).
*5: If you tow a Fit behind a motorhome, the transmission fluid must be changed every 2 years or 30,000
miles (48,000 km), whichever comes first. (For A/T only)CODE
Maintenance Sub Items
1
●Rotate tires
2
●Replace air cleaner element
*3
●Replace dust and pollen filter
*4
●Inspect drive belt
3●Replace transmission fluid
*5
4
●Replace spark plugs●Inspect valve clearance
5●Replace engine coolant

284Index
Remote Transmitter.................................... 79
Replacement
Battery..................................................... 232
Bulbs ....................................................... 212
Fuses ............................................... 260, 261
Tires ........................................................ 228
Wiper Blade Rubber ......................... 218, 220
Reporting Safety Defects......................... 272
Resetting a Trip Meter............................... 73SSafe Driving................................................. 21
Safety Check................................................ 25
Safety Labels............................................... 62
Safety Message........................................... 20
Seat Belts..................................................... 26
Adjusting the Shoulder Anchor .................. 30
Automatic Seat Belt Tensioners .................. 28
Checking ................................................... 33
Detachable Anchor .................................... 31
Fastening ................................................... 29
Installing a Child Seat with a Lap/Shoulder
Seat Belt .................................................. 56
Pregnant Women ...................................... 32
Reminder ................................................... 27
Warning Indicator ................................ 27, 66
Seats.......................................................... 103
Adjusting ................................................. 103
Front Seats .............................................. 103
Rear Seats................................................ 108Seat Under Box ....................................... 116
Security System........................................... 90
Immobilizer System Indicator ..................... 70
Security System Alarm Indicator................. 71
Select Lever................................. 13, 165, 171
Operation.......................... 13, 166, 167, 168
Releasing................................................. 253
Won’t Move ............................................ 253
Select/Reset Knob....................................... 73
Selecting a Child Seat................................. 53
Selector Knob (Audio).............................. 125
Sequential Shift Mode............................. 169
Setting the Clock........................................ 76
Shift Lever........................... 13, 165, 167, 171
Shift Position Indicator.............. 65, 166, 168
Shifting (Transmission)............. 165, 167, 171
Shoulder Anchor........................................ 30
Side Airbags................................................ 41
Cutoff System ........................................... 43
Off Indicator.............................................. 43
Side Curtain Airbags.................................. 44
Snow Tires................................................. 230
Spare Tire.......................................... 239, 269
Spark Plugs............................................... 268
Specifications............................................ 268
Specified Fuel................................... 186, 268
Speedometer.............................................. 72
SRS Airbags (Airbags)................................. 37
Starting the Engine.................................. 161
Does Not Start......................................... 250
Engine Switch Buzzer ................................ 94Jump Starting ......................................... 251
Steering Wheel........................................ 101
Adjusting ................................................ 101
Stopping................................................... 185
Summer Tires............................................ 230
Supplemental Restraint System (SRS)....... 37
Switches (Around the Steering
Wheel).............................................. 2, 3, 94
TTachometer................................................ 72
Tailgate....................................................... 88
Unable to Open ...................................... 266
Temperature
High Temperature Indicator ...................... 67
Low Temperature Indicator ....................... 67
Time (Setting)............................................. 76
Tire Pressure Monitoring System
(TPMS)..................................................... 178
Indicator ........................................... 69, 259
Tire Repair Kit.......................................... 245
Tires.......................................................... 222
Air Pressure..................................... 223, 269
Checking and Maintaining ...................... 222
Inspection ............................................... 222
Labeling .................................................. 223
Puncture (Flat Tire) .................................. 239
Regulations ............................................. 225
Rotation.................................................. 229
Spare Tire ....................................... 239, 269
