2014 HONDA ACCORD HYBRID TPMS reset

102
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
■Customization flow
Press the button.
SEL/RESETVehicle Settings
“Trip A” Reset Timing
Language SelectionAdjust Outside Temp. Display
Memory Position Link
Door Unlock Mode
Keyless Access Light Flash
4
4
4
4
TPMS Calibration
Driver Assist System Setup*
Meter Setup
Driving Position Setup *
Keyless Access Setup
SEL/RESET
SEL/RESET
SEL/RESET
SEL/RESET
“Trip B” Reset TimingFuel Efficiency Backlight
4
Head-up WarningACC Pre-Running Car Detect Beep *
ACC Display Speed Unit*
4Turn-by-Turn Display
*
SEL/RESET
Keyless Access Beep
Forward Collision Warning Distance
4
4
4
* Not available on all models
Main MenuTable of Contents

104
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
■List of customizable options
*1:Default Setting Setup Group Customizable Features Description Selectable Settings
TPMS
Calibration—Calibrates the TPMS.Cancel
/Calibrate
Driver Assist
System
Setup *
Forward Collision
Warning DistanceChanges at which distance
FCW alerts, or turns FCW
on and off.Long /Normal *1
/Short /Off
Head-up WarningTurns the heads-up warning lights on to flash or off.On *1
/Off
ACC Pre-Running Car
Detect Beep *Causes the system to beep when the system detects
a vehicle, or when the vehicle goes out of ACC range.On
*1
/Off
ACC Display Speed Unit *Changes the ACC display speed unit.mph
*1
/km/h (U.S.)
mph /km/h *1
(Canada)
Meter Setup
Language SelectionChanges the displayed language.English *1
/French /Spanish
Adjust Outside Temp.
DisplayAdjusts the temperature reading by a few degrees.-5°F ~ ±0°F *1
~ +5°F (U.S.)
-3°C ~ ±0°C *1
~ +3°C (Canada)
“Trip A” Reset TimingChanges the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A.When Refueled /IGN Off /
Manually Reset *1
“Trip B” Reset TimingChanges the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B.When Refueled
/IGN Off /
Manually Reset *1
* Not available on all models
Main MenuTable of Contents

296
uuCustomized Featuresu
Features
“Trip B” Reset Timing
Adjust Outside Temp. Display“Trip A” Reset Timing
Keyless Access Light Flash
Auto Light Sensitivity
Auto Door Lock
Auto Door Unlock
Fuel Efficiency Backlight
Forward Collision Warning Distance
Door Unlock Mode

Interior Light Dimming Time
Headlight Auto Off Timer
Memory Position Link

Language Selection


Key And Remote Unlock Mode
Keyless Lock Answer BackSecurity Relock Timer
Maintenance Reset
Default
Vehicle
Settings
Driver Assist
System Setup *
Meter
Setup
TPMS Calibration
Driving Position Setup *Keyless
Access
Setup
Lighting Setup
Door
Setup
Maintenance Info.
Keyless Access Beep

Head-up Warning
* Not available on all models
Main MenuTable of Contents

302
uuCustomized Featuresu
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
Vehicle
Settings TPMS Calibration
Cancels/Calibrates the TPMS. Cancel*1
/Calibrate
Driver
Assist
System
Setup *Forward Collision Warning
Distance
Changes at which distance FCW alerts, or turns
FCW on and off. Long
/Normal *1
/
Short /Off
Head-up Warning Turns the heads-up warning lights on to flash or off. On*1
/Off
Meter
Setup Language Selection
Changes the displayed language on the multi-
information display. English
*1
/French /
Spanish
Adjust Outside Temp.
Display Adjusts the temperature reading by a few degrees. -5°F ~ ±0°F
*1
~ +5°F
(U.S.)
-3°C ~ ±0°C *1
~ +3°C
(Canada)
“Trip A” Reset Timing Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A. With Refuel
/IGN Off /
Manually Reset *1
“Trip B” Reset Timing Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B. With Refuel
/IGN Off /
Manually Reset *1
Fuel Efficiency Backlight Turns the ambient meter feature on and off. On*1
/Off
Driving
Position
Setup *Memory Position Link
Changes the driver’s seat position to a stored setting.
On
*1
/Off
* Not available on all models
Main MenuTable of Contents

313
uuCustomized Featuresu
Continued
Features
“Trip A” Reset Timing
“Trip B” Reset Timing
Fuel Efficiency Backlight

Language Selection
Adjust Outside Temp. Display




Forward Collision Warning Distance
ACC Pre-Running Car Detect Beep*
ACC Display Speed Unit*

Turn by Turn Display
Default
Memory Position Link
Door Unlock Mode
Keyless Access Light Flash
Interior Light Dimming Time
Headlight Auto Off Timer
Auto light Sensitivity
Key And Remote Unlock Mode
Keyless Lock Answer Back
Security Relock Timer
Auto Door Lock
Auto Door Unlock

Maintenance Reset
TPMS Calibration
Vehicle
Settings
Meter Setup
Driver Assist
System Setup
Driving Position Setup *
Keyless
Access
Setup
Lighting Setup
Door
Setup
Maintenance Info.
Keyless Access Beep
Head-up Warning
* Not available on all models
Main MenuTable of Contents

320
uuCustomized Featuresu
Features
*1:Default Setting
*2:Refer to the Navigation System Manual for complete details.Setup
Group Customizable Features Description Selectable Settings
Vehicle
Settings TPMS Calibration
Cancels/Calibrates the TPMS. Cancel*1
/Calibrate
Driver
Assist
System
Setup *Forward Collision Warning
Distance
Changes at which distance FCW alerts, or turns
FCW on and off. Long
/Normal *1
/
Short /Off
Head-up Warning Turns the heads-up warning lights on to flash or off. On*1
/Off
ACC Pre-Running Car
Detect Beep * Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of ACC range.
On
*1
/Off
ACC Display Speed Unit *
Changes the speed unit for ACC on the multi-
information display. mph
*1
/km/h (U.S.)
miles /km *1
(Canada)
Meter
Setup Language Selection
Changes the displayed language on the multi-
information display. English
*1
/French /
Spanish
Adjust Outside Temp.
Display Adjusts the temperature reading by a few degrees.
-5°F ~ ±0°F
*1
~ +5°F (U.S.)
-3°C ~ ±0°C*1 ~ +3°C (Canada)
“Trip A” Reset TimingChanges the setting of how to reset trip meter A, average
fuel economy A, average speed A, and elapsed time A.With Refuel /IGN Off /
Manually Reset *1
“Trip B” Reset Timing
Changes the setting of how to reset trip meter B, average
fuel economy B, average speed B, and elapsed time B.With Refuel /IGN Off /
Manually Reset *1
Fuel Efficiency Backlight Turns the ambient meter feature on and off. On*1
/Off
Turn by Turn Display *2
Selects whether the turn-by-turn display comes
on during the route guidance. On
*1
/Off
* Not available on all models
Main MenuTable of Contents

uuWhen DrivinguTire Pressure Monitoring System (TPMS)
448
Driving
You can calibrate the system from the
customized features on the multi-information
display.1. Press the / button to select Vehicle
Settings , then press the SEL/RESET button.
uTPMS Calibration appears on the display.
2. Press the SEL/RESET button.
uThe display switches to the
customization setup screen, where you
can select Cancel or Calibrate .
3. Press the / button and select
Calibrate , then press the SEL/RESET button.
uCalibration Started screen appears,
then the display returns to the customization menu screen.
• If the Calibration Failed to Start message
appears, repeat steps 2-3.
• The calibration process finishes automatically.
1TPMS Calibration •The calibration process requires approximately 30
minutes of cumulative driving at speeds between
30-60 mph (48-97 km/h).
• During this period, if the power mode is set to ON
and the vehicle is not moved within 45 seconds,
you may notice the low tire pressure indicator
comes on briefly. This is normal and indicates that
the calibration process is not yet complete.
You can calibrate the system using the audio/information screen. 2 Customized Features P. 293
If the snow chains are installed, remove them before
calibrating the TPMS.
If the low tire pressure/TPMS indicator comes on even
when the properly inflated specified regular tires are
installed, have your vehicle checked by a dealer.
We recommend that the tires be replaced with the
same brand, model, and size as the originals. Ask a
dealer for details.
4
4
Main MenuTable of Contents

558
Index
Seat Belts..................................................... 36
Adjusting the Shoulder Anchor .................. 40
Automatic Seat Belt Tensioners .................. 38
Checking ................................................... 42
Fastening ................................................... 39
Installing a Child Seat with a Lap/Shoulder Seat Belt .......................................................... 63
Pregnant Women ...................................... 41
Reminder ................................................... 37
Warning Indicator ................................ 37, 75
Seat Heaters ...................................... 163, 164
Seats .......................................................... 148
Adjusting ................................................. 148
Front Seats .............................................. 148
Seat Heaters .................................... 163, 164
Security System ......................................... 126
Immobilizer System Indicator ..................... 80
Security System Alarm Indicator ................. 80
SEL/RESET Button ........................................ 95
Select Lever ................................................. 23
Operation .................................. 23, 420, 421
Releasing ................................................. 524
Won’t Move ............................................ 524
Selecting a Child Seat ................................. 60
Selector Knob (Audio) ...................... 175, 197
Shift Lever ........................................... 23, 420
Shift Lever Position Indicator ............. 75, 421
Shift Lever Positions
Transmission ............................................ 420
Shifting (Transmission) ............................. 420 Shoulder Anchor
........................................ 40
Side Airbags ................................................ 50
Side Curtain Airbags .................................. 52
Smart Entry with Push Button Start
System ..................................................... 115
Snow Tires ................................................. 501
Spark Plugs ............................................... 538
Specifications ............................................ 538
Specified Fuel ................................... 459, 538
Speedometer .............................................. 92
SRS Airbags (Airbags) ................................. 46
Steering Wheel ......................................... 145
Adjusting ................................................ 145
Stopping ................................................... 456
Summer Tires ............................................ 501
Sunglasses Holder ..................................... 162
Supplemental Restraint System (SRS) ........ 46
Switches (Around the Steering Wheel) ............................................. 2, 3, 133
SYNC Mode ............................................... 167
System Message Indicator .......................... 79
T
Temperature Outside Temperature Display ..................... 97
Temperature Sensor ........................... 97, 168
Time (Adjusting) ....................................... 110
Tire Pressure Monitoring System
(TPMS) ..................................................... 447
Indicator............................................ 78, 531 Tire Repair Kit
.......................................... 511
Tires .......................................................... 493
Air Pressure..................................... 494, 539
Checking and Maintaining ...... ................ 493
Inspection ............................................... 493
Labeling .................................................. 494
Puncture (Flat Tire) .................................. 510
Regulations ............................................. 496
Rotation.................................................. 500
Summer .................................................. 501
Tire Chains.............................................. 501
Tire Repair Kit ......................................... 511
Wear Indicators....................................... 498
Winter .................................................... 501
Towing a Trailer ....................................... 415
Towing Your Vehicle ............................... 415
Emergency .............................................. 535
TPMS (Tire Pressure Monitoring
System) .................................................... 447
Indicator ........................................... 78, 531
Transmission ..................................... 419, 420
Creeping................................................. 419
Fluid ....................................................... 481
Kickdown ............................................... 419
Operating the Shift Lever ........................ 421
Shift Lever Position Indicator ............. 75, 421
Shifting ................................................... 420
Trip Meter .................................................. 96
Main Menu
