2014 CHRYSLER 300 SRT User Guide

OPENING THE HOOD
•Pull the hood release lever located on the
instrument panel, below the headlight switch.
• Raise the hood and locate the safety catch lever, in the middle of the hood opening.
• Push the safety catch lever to the left while lifting the hood at the same time.
WARNING!
Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it
could open when the vehicle is in motion and block your vision. Failure to follow this warning
could result in serious injury or death.
FUEL DOOR RELEASE
• The fuel door release button is located inthe driver's door map pocket.
• Push the button once and release to open the fuel door.
MAINTAINING YOUR VEHICLE
95

Fuel Door Emergency Release
• To manually open the fuel door, remove thecover and pull the release cable located in
the trunk.
Emergency Refueling
•A funnel is provided (located in the trunk in
the spare tire area) to open the flapper door to
allow for emergency refueling with a gas can.
CAUTION!
To avoid fuel spillage and overfilling, do not “top off ” the fuel tank after filling.
WARNING!
• Never have any smoking materials lit in or near the vehicle when the fuel door is open or
the tank is being filled.
• Never add fuel when the engine is running. This is in violation of most state and federal fire
regulations and/or local bylaws, and will cause the MIL to turn on.
• A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.
You could be burned. Always place gas containers on the ground while filling.
MAINTAINING YOUR VEHICLE
96

ENGINE COMPARTMENT3.6L Engine
MAINTAINING YOUR VEHICLE
97

5.7L Engine
MAINTAINING YOUR VEHICLE
98

6.4L Engine (392 HEMI)
MAINTAINING YOUR VEHICLE
99

FLUIDS AND CAPACITIES
Non-SRT
ComponentFluid, Lubricant, or
Genuine Part Capacities
Engine Coolant – 3.6L Engine We recommend you use
MOPAR® Antifreeze/Coolant Ten Year/150,000 Mile For-
mula OAT (Organic Additive Technology). 10 Quarts (9.5 Liters) Includes
heater and coolant recoverybottle filled to MAX level.
5.7L Engine without Severe Duty II Cooling System We recommend you use
MOPAR® Antifreeze/Coolant Ten Year/150,000 Mile For-
mula OAT (Organic Additive Technology). 14.5 Quarts (13.9 Liters)
Includes heater and coolant recovery bottle filled to MAX level.
5.7L Engine with Severe Duty II Cooling System We recommend you use
MOPAR® Antifreeze/Coolant Ten Year/150,000 Mile For-
mula OAT (Organic Additive Technology). 15 Quarts (14.3 Liters) Includes
heater and coolant recoverybottle filled to MAX level.
Engine Oil with Filter – 3.6L Engine We recommend you use API
Certified SAE 5W-20 Engine
Oil, meeting the requirements of Chrysler Material Standard MS-6395 such as MOPAR®,Pennzoil®, and Shell Helix®.
Refer to your engine oil filler cap for correct SAE grade. 6 Quarts (5.6 Liters)
Engine Oil with Filter – 5.7L Engine We recommend you use API
Certified SAE 5W-20 Engine
Oil, meeting the requirements of Chrysler Material Standard MS-6395 such as MOPAR®,Pennzoil®, and Shell Helix®.
Refer to your engine oil filler cap for correct SAE grade. 7 Quarts (6.6 Liters)
Engine Oil Filter We recommend you use
MOPAR® brand Engine Oil Filters. —
Spark Plug – 3.6L Engine We recommend you use
MOPAR® Spark Plugs
(Gap 0.043 in [1.1 mm]). —
Spark Plug – 5.7L Engine We recommend you use
MOPAR® Spark Plugs
(Gap 0.043 in [1.1 mm]). —
MAINTAINING YOUR VEHICLE
100

ComponentFluid, Lubricant, or
Genuine Part Capacities
Automatic Transmission – 8 Speed Transmission Use only MOPAR® ZF 8&9
Speed ATF™ Automatic Trans- mission Fluid or equivalent.
Failure to use the correct fluid
may affect the function or per- formance of your transmission. —
Automatic Transmission – 5 Speed Transmission Use only ATF+4® Automatic
Transmission Fluid. Failure to use ATF+4® fluid may affect
the function or performance of your transmission. We recom-
mend MOPAR® ATF+4® fluid. —
Transfer Case We recommend you use
MOPAR® BorgWarner 44–40 Transfer Case. —
Axle Front We recommend you use API
GL-5 SAE 75W90 Synthetic Gear Lubricant. —
Axle Rear We recommend you use API
GL-5 SAE 75W140 Synthetic Gear Lubricant. —
Brake Master Cylinder We recommend you use
MOPAR® DOT 3 and
SAE J1703. If DOT 3 is not available, then DOT 4 is acceptable. —
Power Steering Reservoir We recommend you use
MOPAR® Hydraulic Fluid or
equivalent meeting MS-11655, such as Fuchs EG ZH 3044 or Pentosin CHF 11s. —
Fuel Selection – 3.6L Engine 87 Octane19 Gallons (72 Liters)
(Approximate)
Fuel Selection – 5.7L Engine 87 Octane Acceptable.
89 Octane Recommended. 19 Gallons (72 Liters)
(Approximate)
MAINTAINING YOUR VEHICLE
101

SRT
ComponentFluid, Lubricant, or
Genuine Part Capacities
Engine Coolant – 6.4L Engine We recommend you use
MOPAR® Antifreeze/Coolant Ten Year/150,000 Mile For-
mula OAT (Organic Additive Technology). 15.2 Quarts (14.4 Liters)
Includes heater and coolant recovery bottle filled to MAX level.
Engine Oil With Filter – 6.4L Engine For best performance and
maximum protection under all types of operating conditions,
the manufacturer only recom-
mends full synthetic engine oils that meet the American Petro-
leum Institute (API) categories of SN. The manufacturer rec-ommends the use of Pennzoil Ultra™ 0W-40 or equivalent
MOPAR® engine oil meeting the requirements of ChryslerMaterial Standard MS-12633 for use in all operating tem- peratures. 7 Quarts (6.6 Liters)
Engine Oil Filter We recommend you use
MOPAR® brand Engine Oil Filters. —
Spark Plugs – 6.4L Engine We recommend you use
MOPAR® Spark Plugs
(Gap 0.043 in [1.1 mm]). —
Automatic Transmission Use only ATF+4® Automatic
Transmission Fluid. Failure to use ATF+4® fluid may affect
the function or performance of your transmission. We recom-
mend MOPAR® ATF+4® fluid. —
Axle Rear We recommend you use
MOPAR® Synthetic Gear Lubricant SAE 75W–90
(API GL-5) (with MOPAR® Friction Modifier – Hypoid Gear Additive). —
Power Steering Reservoir We recommend you use
MOPAR® Power Steering
Fluid + 4, MOPAR® or ATF+4® Automatic Transmission Fluid. —
Fuel Selection – 6.4L Engine Premium Unleaded 91 Octane
Only or higher. 19 Gallons (72 Liters)
(Approximate)
MAINTAINING YOUR VEHICLE
102
