Seats, restraints63
Suitable are restraint systems that
comply with valid UN ECE
regulations. Check local laws and
regulations for mandatory use of child restraint systems.
Ensure that the child restraint system to be installed is compatible with the
vehicle type.
Ensure that the mounting location of
the child restraint system within the
vehicle is correct, see following
tables.
Allow children to enter and exit the
vehicle only on the side facing away
from the traffic.
When the child restraint system is not
in use, secure the seat with a seat belt or remove it from the vehicle.
Notice
Do not affix anything on the child restraint systems and do not cover
them with any other materials.
A child restraint system which has
been subjected to stress in an
accident must be replaced.

64Seats, restraintsChild restraint installation locationsPermissible options for fitting a child restraint system
Weight and age class 1)
On front passenger
seatOn outboard
seats in the
second rowOn centre seat
in the second
rowOn the seats
in the third
rowGroup 0: up to 10 kg or approx. 10 months
Group 0+: up to 13 kg or approx. 2 yearsXU, +UXGroup I: 9 to 18 kg or approx. 8 months to 4 yearsXU, +, ++UUFGroup II: 15 to 25 kg or approx. 3 to 7 years
Group III: 22 to 36 kg or approx. 6 to 12 yearsXUUUF
1)
We recommend the use of each system until the child reaches the upper weight limit.U=Universal suitability in conjunction with three-point seat belt.UF=Can be used universally for forward-facing child restraint systems in combination with a three-point seat belt.+=Vehicle seat available with ISOFIX attachments. When attaching using ISOFIX, only the ISOFIX child restraint
systems permitted for the vehicle may be used.++=Vehicle seat available with ISOFIX attachments. When attaching using ISOFIX and Top-tether , universally permitted
ISOFIX child restraint systems may be used.X=No child restraint system permitted in this weight class.

Seats, restraints65
Permissible options for fitting an ISOFIX child restraint system
Weight classSize classFixtureOn front
passenger seatOn outboard
seats in the
second rowOn centre
seat in the
second rowOn the
seats in the third rowGroup 0: up to 10 kgEISO/R1XILXXGroup 0+: up to 13 kgEISO/R1XILXXDISO/R2XILXXCISO/R3XILXXGroup I: 9 to 18 kgDISO/R2XILXXCISO/R3XILXXBISO/F2XIL, IUFXXB1ISO/F2XXIL, IUFXXAISO/F3XIL, IUFXXGroup II: 15 to 25 kg or approx.
3 to 7 yearsXILXXGroup III: 22 to 36 kg or approx.
6 to 12 yearsXILXX

66Seats, restraints
IL=Suitable for particular ISOFIX restraint systems of the "specific-vehicle", "restricted" or "semi-universal" categories.
The ISOFIX restraint system must be approved for the specific vehicle type.IUF=Suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this weight class.X=No ISOFIX child restraint system approved in this weight class.
ISOFIX size class and seat device
A – ISO/F3=Forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg.B – ISO/F2=Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg.B1 – ISO/F2X=Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg.C – ISO/R3=Rear-facing child restraint system for children of maximum size in the weight class up to 18 kg.D – ISO/R2=Rear-facing child restraint system for smaller children in the weight class up to 18 kg.E – ISO/R1=Rear-facing child restraint system for young children in the weight class up to 13 kg.

Seats, restraints67Isofix child restraint
systems
Fasten vehicle-approved ISOFIX
child restraint systems to the
mounting brackets. Specific vehicle
ISOFIX child restraint system
positions are marked in the table by
IL.
Top-tether child restraint
systems
Fasten Top-tether child restraint
systems to the fastening eyes of the
second row of seats. The strap must
run between the two guide rods of the
head restraint.
When using ISOFIX and Top-tether
for seat mounting, universally
permitted child restraint systems for
ISOFIX may be used.

68StorageStorageStorage compartments................68
Load compartment .......................70
Roof rack system .........................76
Loading information .....................76Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Glovebox
The glovebox features a pen holder.
The glovebox should be closed whilst driving.
Cupholders
Cupholders are located in the centre
console, in the doors and the rear side panelling.

Storage69
Additional cupholders are located in
the centre seat backrest when it is
folded down.
Sunglasses storage
Fold down and open.
Do not use for storing heavy objects.
Underseat storage
Lift at recessed edge and pull out.
Maximum load: 1.5 kg. To close, push in and engage.

70StorageRoof panelling
Press marked locations to open.
The maximum permitted load of the
two front compartments is 1 kg, and
the maximum permitted load of the
three rear compartments is 2 kg.
The compartments must be closed
whilst driving.
Load compartment
Stowage in the load
compartment
To open the cover, lift the carpeting.
Raise, rotate and lift the ring. The load
compartment contains the vehicle
tools 3 173 and the coupling ball bar.
The fuse box is on the left side behind
the cover in the load compartment
side panelling 3 170.
The tyre repair kit is on the right side
behind the cover 3 179.
Load compartment cover
Do not place any heavy or sharp-
edged objects on the load
compartment cover.
Before operating the load
compartment cover, the rear seat
belts must be fed through the side belt holders.
Opening
Remove load compartment cover
from side brackets. It rolls up
automatically.
