LEd dAYtIME runnInG LAMPS
Rear foglamps (amber, 2nd rotation  of   the   ring   forwards).
Front
  foglamps   (green,   1st
rotation

  of   the   ring   forwards).
Front and rear foglamps
Rotate ring B forwards to switch on
and

rearwards   to   switch   off.
The
  status
is


confirmed   by   the   warning   lamps   in
the


instrument   panel.
They

operate   with   the   sidelamps   and
dipped


beam   headlamps. Do   not   forget   to   switch   them   off
when

  they   are   no   longer   needed.
Operation   of   the   automatic   illumination
of

  headlamps   switches   off   the   rear
foglamps,

  but   the   front   foglamps
remain

  on.
To switch off the front and rear
foglamps,   turn   the   ring   rearwards   twice
in


succession.
Automatic illumination of headlamps
In foggy weather or in snow,
the   sunshine   sensor   may   detect
sufficient

  light.
As
  a   consequence,
the


lighting   will   not   come   on
automatically

.
If
  necessary,   you   must   switch
on

  the   dipped   beam   headlamps
manually

.
d

o not cover the sunshine sensor
located on the windscreen, behind
the

mirror.   It   is   used   for   the   automatic
illu

mination   of   headlamps   and   for   the
automatic

  rain   sensitive   wipers.
Activation
Turn the ring to the A
ut
O
  position.
The activation of this function is
accompanied

  by   a   message   in   the
screen.
d

eactivation
Turn
  the   ring   forwards   or   rearwards.
The deactivation of this function is
accompanied

  by   a   message   in   the
screen.
The


function   is   deactivated   temporarily
when

  you   use   the   manual   lighting
control

  stalk. The
  sidelamps
and

  dipped   beam
headlamps

  switch
on

  automatically   if
the light is poor

, or
during operation of the windscreen
wipers.
They
  switch   off   as   soon   as   the
light

  becomes   bright   enough   or   the
windscreen

  wipers   stop.
This
  function   is   not   compatible   with   the
daytime

  running   lamps.
o

n starting the vehicle, in daylight the
LED

daytime

running

lamps

come

on

automatically

.
If

the

sidelamps

and

headlamps

are

switched


on

manually

or

automatically,

the


daytime

running

lamps

go

off.
Programming
For countries where exterior lighting by
day   is   not   a   legal   requirement,   you   can
activate or deactivate the function via
the

  configuration   menu.
If the user does not operate any
equipment

for

30

minutes,

the

Economy


mode

engages

to

avoid

discharging


the

battery.

Electrical

functions are put on standby and the
battery


warning

lamp

flashes.
Sidelamp

operation

is

not

affected

by

Economy


mode.
In clear weather or in rain, both day
and

night,

rear

foglamps

dazzle

and

their


use

is

prohibited.
Refer to chapter 8, "Battery
section".
Steering mounted controls
EaSE oF USE and CoMFoRT
4

54
Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
If the sunshine sensor
does not function correctly,
the  lighting   comes   on
accompanied

  by   the   service
warning

  lamp,   an   audible
signal


and   a   message   in   the   screen.
Contact a CITR
o Ë n dealer or a
qualified
  workshop.
Guide-me-home lighting
Keeping the dipped beam headlamps on   temporarily   with   the   ignition   off,
makes

  the   driver's   exit   easier   when   the
light

  is   poor.
HEAdLAMP BEAM
depending on the load in your vehicle,
the   beam   setting   must   be   adjusted.
0 -

No
  load.
1 -

Partial
  load.
2 -

A
verage   load.
3 -

Maximum
  authorised   load.
Manual operation
-
 With

the

ignition

off,

"flash"

the
 headlamps

within

one

minute

after

switching


off

the

ignition.
The

guide-me-home

lighting

switches

of

f

automatically

after

a

set

time.
Automatic operation
Refer to chapter 10, "Screen
menu

map"

section. Initial setting is position 0.
a

ctivate the function via the
vehicle

configuration

menu. Programming
The

system

is

activated

or

deactivated

in


the

vehicle

configuration

menu.
The

system

is

activated

by

default.
Switching off
The

system

does

not

operate:
-

below a certain angle of rotation of
the steering wheel,
-


above


25

mph

(40

km/h),
-

when


reverse

gear

is

engaged.
Switching on
This

function

starts:
-

when the corresponding direction
indicator is switched on,
or
-


from


a

certain

angle

of

rotation

of

the


steering

wheel.
With

dipped

or

main

beam

headlamps,

this


function

makes

use

of

the

beam

from


a

front

foglamp

to

illuminate

the

inside of a bend, when the vehicle
speed


is

below

25

mph

(approximately

40


km/h)

(urban

driving,

winding

road,

intersections,


parking

manouevres...).
cornering lighting
travelling abroad
If using your vehicle in a country
that drives on the other side of the
road,
  the   headlamps   must   be   adjusted
to


avoid   dazzling   on-coming   drivers.
Contact a CITR
o Ë n dealer or a
qualified
  workshop.
Steering mounted controls

56
Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
Screenwash and headlamp wash
Pull the stalk towards you, the wash-
wipe   is   accompanied   by   a   timed   sweep
of

  the   wipers.
The
  headlamp   wash   is   linked   with   the
wash-wipe, it is triggered if the dipped
headlamps

  are   on.
Turn
  the   ring   past   the   first
position:

  the   rear   screenwash
then the rear wiper operates
for

  a   fixed   time.
In winter, in the event of a
considerable
  amount   of   snow
or ice, switch on the heated
rear

  screen.   Once   the   screen   is
clear

,   remove   the   snow   or   ice   which
has

  accumulated   on   the   rear   wiper
blade.


Y
ou   can   then   operate   the   rear
windscreen

  wiper.
To top up the levels, refer to the
"Levels"
  section   of   chapter   7.
Special position of the
windscreen wipers
In the minute following switching off of the ignition, any action on the
stalk
  positions   the   wipers   against   the
windscreen

  uprights.
This action enables you to position
the
  wiper   blades   for   winter   parking,
cleaning

  or   replacement.
Refer to the "Changing a windscreen
wiper
  blade"   section   of   chapter   8.
To
  park   the   wipers   in   their   normal
position after this has been done,
switch

  on   the   ignition   and   move   the
stalk. T

urn   the   ring   to   the   first
position.
rear wiperrear screenwash
Steering mounted controls

Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
 65
Good practice
For maximum cooling or heating of the passenger  compartment,   it   is   possible
to exceed the value 15 by turning until
LO

  is   displayed   or   the   value   27   by
turning

  until   HI   is   displayed.
o

n entering the vehicle, the inside
temperature
  may   be   much   colder
(or
  warmer)   than   is   comfortable.
There

is no advantage in changing the value
displayed

  in   order   to   quickly   reach   the
level

  of   comfort   required.
The
  system
will

  use   its   maximum   performance   to
reach

  the   comfort   value   set.
dIGItAL AIr c O nd I t IO n I n G WI t H SEPA r At E SE tt I n GS
Automatic operation
AutO comfort programme
This   is   the   normal   air   conditioning
system

  operating   mode.
d
river or passenger side comfort
value
The value indicated in the screen
corresponds   to   a   level   of   comfort   and
not

  a   temperature   in   degrees   Celsius
or

  Fahrenheit.
Turn this control to the left
or to the right to decrease or
increase   the   value.
A
setting
around the value 21 provides
optimum

  comfort.   However,
depending

  on   your   requirements,   a
setting

  between   18   and   24   is   usual.
d

o not cover the sunshine sensor
located
  on   the   dashboard.
Press this button, the A
ut
O

symbol
  is   displayed.
In accordance with the
comfort
  value   selected,
the

  system   controls   the
distribution,

  the   flow   and   the   intake
of

  air   to   guarantee   comfort   and   a
sufficient

  circulation   of   air   in   the
passenger

  compartment.   No   further
action

  on   your   part   is   required.
When the engine is cold, to prevent an
excessive diffusion of cold air, the air diffuser
will  reach   its   optimum   level   gradually.
For
  your   comfort,   the   settings   are   stored
 when the ignition is switched of

f and are
reinstated
  the   next   time   the   vehicle   is
 started.
The

  automatic   function   will   no   longer   be
 maintained

  if   you   change   a   setting   manually
 (AUT

O   is   cleared).
FOr tHE drIVEr And PASSEnGEr
Ventilation
EASE OF uSE and cOMFOrt
4

Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
66
Manual operation
You can, according to your
requirements,  make   a   different   selection from

  that   offered   by   the   system   by
 changing

  a   setting.
The
  other   functions
 will

  still   be   controlled   automatically.
 Pressing the

A ut
O
button restores fully
automatic
  operation.
Air distribution
Pressing this button several
times
  in   succession   directs
the

  air   flow   towards:
-

the windscreen,
-


the windscreen and footwells,
-


the footwells,
-


the side vents, central vents and
footwells,
-


the
  side   vents   and   central   vents.Air flow
Press the small fan button to
reduce
  the   flow   or   the   large
fan button to increase the
flow.
On
  the   display,   the   blades   of   the   fan   fill
when

  the   flow   is   increased.
Switching the air
conditioning On / Off
Press this button, the A/
c
symbol
  is   displayed   and   the
air

  conditioning   is   activated.
d
eactivating the system
Press
  the   air   flow   small fan
button
  until   the   fan   symbol
disappears

  from   the   display.
This action deactivates all of the
system's
  functions,   with   the   exception
of the air recirculation and rear screen
demisting

  (if   fitted   on   your   vehicle).
Y

our   comfort   setting   is   no   longer
maintained

  and   is   switched   off.Intake of exterior air / r
ecirculation of interior air
Press this button to
recirculate
  the   interior   air.
The

  recirculation   symbol   is
displayed.
Pressing the

large fan
button or the A
ut
O
button
reactivates
  the   system   with
the values set before it was
deactivated.Recirculation prevents exterior odours


and
  smoke   from   entering   the   passenger
 compartment.


A
void   prolonged   operation
 in

  interior   air   recirculation   mode   (risk   of
 condensation,

  odour   and   humidity).
Pressing this button again activates the
intake
  of   exterior   air.
Pressing this button again switches off
the
  air   conditioning.
The ventilation outlet, located
in the glove box, diffuses cool
air (if the air conditioning is
on) regardless of the reference
temperature
  requested   in   the
passenger

  compartment   and
regardless

  of   the   exterior   temperature.
For
  your   comfort,   do   not   deactivate   the
system

  for   long   periods.
Ventilation

Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
74
rEAr SEAtS (5 SEAt VE r SIO n) Head restraint
High position: lift and raise the head restraint.
Low
  position:   press   on   the   head
restraint

  to   lower   it.
To
  remove   the   head   restraint,   after
raising it press the tab and lift the head
restraint.
T

o install the head restraint, engage
the rods of the head restraint in the
holes
  keeping   it   in   line   with   the   seat
back.
Each


seat

can

be

removed

individually.
Each

time

a

seat

is

returned

to

the

sitting


position

or

after

removing

then

refitting


a

seat,

check

that

it

is

locked

on


the

floor

securely.
The three independent rear seats
are

fitted

with

"comma"

shape

head

restraints.
The


back

of

the

centre

seat,

folded

onto the seat cushion, has a shell
which serves as a table with cup
holder

.
Seats

Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
 93
replacing a cartridge
The scented air freshener refill consists of a cartridge B and its sealing case c .
-

Remove
  the   protective   film  d .
-

Place the head of the cartridge
B
on the button A of the scented air
freshener.
-

T
urn   it   a   quarter   of   a   turn   to   lock   it
on

  the   button   and   remove   the   case.
-

Insert the scented air freshener in
its

  location.
You can change the cartridges at any
time
  and   store   cartridges   which   have
already been started in their original
case.
The scented air freshener button

A is
independent
  of   the   cartridge.
The cartridges are supplied without the
button A.
Inserting the scented air
freshener
After fitting or changing the cartridge:
-
Put
  the   scented   air   freshener   back
in

  place   in   its   location.
-

T
urn   it   a   quarter   of   a   turn   to   the
right.
Good practice
as a safety precaution, only use the
cartridges   provided   for   this   purpose.
Do

  not   dismantle   the   cartridges.
k

eep the cartridge sealing cases
which
  are   used   as   packaging   when   the
cartridges

  are   not   in   use.
Never
  try   to   refill   the   cartridges
with fragrances other than those
recommended

  by   the   CITROËN
network.
k

eep out of reach of children and
animals.

A
void   contact   with   the   skin
and

  eyes.   If   swallowed,   consult   a
doctor

  and   show   him   the   packaging   or
product

  label.
The scented air freshener button A can
only

be

fixed

on

the

multifunction

roof

console


with

a

cartridge.
Therefore, always retain button A and
a

cartridge.
The

cartridges

are

available

from

CITROËN


dealers.
Practical information
EASE OF uSE and cOMFOrt
4

Berlingo_2_VP_en_Chap04_Ergonomie_ed02-2014
105
ELEctrIc WIndOWS
1. driver's side
2.
Passenger's side Lower the window fully

, then raise it, it
will   rise   in   steps   of   a   few   centimetres
each

  time   the   control   is   pressed.
Repeat the operation until the window
is

  fully   closed.
Continue to press the control for at
least one second after the window
closed   position   has   been   reached.
The safety anti-pinch does not operate
during   these   operations.
Safety anti-pinch
When the window rises and meets an obstacle,
  it   stops   and   partially   lowers.One-touch mode
Press or pull the control, beyond the
point  of   resistance.  The   window   opens
or closes fully when the control is
released.

  Pressing   the   control   again
stops

  the   movement   of   the   window.This
  mode   is   available
depending

  on   equipment;   it   is
identified

  by   this   symbol   on   the
control

  in   question.
Good practice
If the electric windows meet an obstacle
  during   operation,   you   must
reverse

  the   movement   of   the   window.
T

o
do

this,

press

the

control

concerned.
When the driver operates the
passenger electric window controls,
they

  must   ensure   that   no   one   is
preventing correct closing of the
windows.
The

  driver   must   ensure   that   the
passengers use the electric windows
correctly

.
Be aware of children when operating
the
  windows.
Following
  several   consecutive   closing/
opening operations of the electric
window
  control,   a   protection   system
is triggered which only allows closing
of

  the   window.
After
  closing,   wait
approximately

  40   minutes.   Once   this
time

  has   elapsed,   the   control   becomes
operational

  again.
Manual mode
Press or pull the control, without
passing  the   point   of   resistance.  The
window stops when you release the
control.
reinitialisation
Following reconnection of the battery,
or  in   the   event   of   a   malfunction,   the
safety

  anti-pinch   function   must   be
reinitialised. The electrical functions of the electric
windows
  are   deactivated:
-
approximately
  45   seconds   after   the
ignition is switched of

f,
-
after one of the front doors is
opened,

  if   the   ignition   is   off.
There

are

two

operating

modes:
Mirrors and windows
EaSE oF USE and CoMFoRT
4
