TABLE OF CONTENTS SAFETY INFORMATION ................. 1-1
Further safe-riding points ................ 1-5
DESCRIPTION .................................. 2-1
Left view .......................................... 2-1
Right view ........................................ 2-2
Controls and instrument s................. 2-3
INSTRUMENT AND CONTROL
FUNCTIONS ....................................... 3-1
Immobilizer system .... ..................... 3-1
Main switch/steering lock ................ 3-2
Indicator lights and warning lights ............................................ 3-3
Speedometer .................................. 3-5
Tachometer .................................... 3-5
Multi-function display ...................... 3-5
Anti-theft alarm (opti onal) ............. 3-12
Handlebar switches ...................... 3-12
Front brake lever .......................... 3-14
Rear brake lever ........................... 3-14
Rear brake lock lever .................... 3-15
ABS (for ABS models) . ................. 3-16
Fuel tank cap ................................ 3-17
Fuel ............................................... 3-18
Catalytic converter ........................ 3-19
Seat .............................................. 3-20
Adjusting the rider backrest .......... 3-20
Helmet holder ............................... 3-21
Storage compartments ................. 3-22
Windshield .................................... 3-24 Rear view mirrors ......................... 3-25
Shock absorber assembly ............ 3-26
Sidestand ..................................... 3-26
Ignition circuit cut-o
ff system ........ 3-27
FOR YOUR SAFETY –
PRE-OPERATION CHECKS ............. 4-1
OPERATION AND IMPORTANT
RIDING POINTS ................................. 5-1
Starting the engine ......................... 5-1
Starting off ...................................... 5-2
Acceleration and deceleration ........ 5-3
Braking ........................................... 5-3
Tips for reducing fuel consumption ............................... 5-4
Engine break-in .............................. 5-4
Parking ........................................... 5-5
PERIODIC MAINTENANCE AND
ADJUSTMENT ................................... 6-1
Owner’s tool kit ............................... 6-2
Periodic maintenance chart for the
emission control system ............. 6-3
General maintenance and
lubrication chart .......................... 6-4
Removing and installing panels ..... 6-8
Checking the spark plugs ............. 6-10
Engine oil and oil filter cartridge ... 6-11
Coolant ......................................... 6-14
Replacing the air filter element ..... 6-15 Adjusting the engine idling
speed ........... ............................ .. 6-16
Checking the throttle grip free play ............................................ 6-17
Valve clearance ............................ 6-17
Tires .............................................. 6-17
Cast wheels .................................. 6-19
Checking the front and rear brake
lever free play ............................ 6-20
Adjusting the rear brake lock cable .......................................... 6-21
Checking the rear brake lock ........ 6-21
Checking the front and rear brake pads ........................................... 6-22
Checking the brake fluid level ....... 6-23
Changing the brake fluid ............... 6-24
Drive belt slack ............................. 6-24
Checking and lubricating the cables ........................................ 6-24
Checking and lubricating the
throttle grip and cable ................ 6-25
Lubricating the front and rear brake levers ............................... 6-25
Checking and lubricating the centerstand and sidestand ........ 6-26
Checking the front fork .................. 6-26
Checking the steering ................... 6-27
Checking the wheel bearings ........ 6-27
Battery .......................................... 6-28
Replacing the fuses ...................... 6-30
Replacing the headlight bulb ........ 6-32
59C-9-E1.book 1 ページ ２０１２年６月２６日　火曜日　午前１１時３３分

PERIODIC MAINTENANCE AND ADJUSTMENT
6-3
2
3
4
567
8
9
EAU46861
TIP
The annual checks must be performed every year, except if a kilometer-based maintenance, or for the UK, a
mileage-based maintenance, is performed instead.

From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).

Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technicalskills.
EAU46910
Periodic maintenance chart for the emission control system NO. ITEM CHECK OR MAINTENANCE JOB ODOMETER READING
ANNUAL
CHECK
1000 km
(600 mi) 10000 km
(6000 mi) 20000 km
(12000 mi) 30000 km
(18000 mi) 40000 km
(24000 mi)
1* Fuel line Check fuel hoses for cracks or
damage. 
2* Spark plugs Check condition.
Clean and regap.

Replace. 
3* Valves Check valve clearance.
Adjust. Every 40000 km (24000 mi)
4* Fuel injection Adjust engine idling speed and
synchronization. 
59C-9-E1.book 3 ページ ２０１２年６月２６日　火曜日　午前１１時３３分

PERIODIC MAINTENANCE AND ADJUSTMENT
6-10
1
2
3
4
56
7
8
9To install the panel
Place the panel in the original position,
and then install the screws.
EAU19642
Checking the spark plugs The spark plugs are important engine
components, which should be checked
periodically, preferably by a Yamaha
dealer. Since heat and deposits will
cause any spark plug to slowly erode,
they should be removed and checked
in accordance with the periodic mainte-
nance and lubrication chart. In addition,
the condition of the spark plugs can re-
veal the condition of the engine.
The porcelain insulator around the cen-
ter electrode of each spark plug should
be a medium-to-light tan (the ideal color
when the vehicle is ridden normally),
and all spark plugs installed in the en-
gine should have the same color. If any
spark plug shows a distinctly different
color, the engine could be operating im-
properly. Do not attempt to diagnose
such problems yourself. Instead, have
a Yamaha dealer check the vehicle.
If a spark plug shows signs of electrode
erosion and excessive carbon or other
deposits, it should be replaced. Before installing a spark plug, the spark
plug gap should be measured with a
wire thickness gauge and, if necessary,
adjusted to specification.
Clean the surface of the spark plug
gasket and its mating surface, and then
wipe off any grime from the spark plug
threads.
TIPIf a torque wrench is not available when
1. Screw
2. Panel D
1
2
1
Specified spark plug:
NGK/CR7E
1. Spark plug gapSpark plug gap:0.7–0.8 mm (0.028–0.031 in)
Tightening torque: Spark plug:
13 Nm (1.3 m·kgf, 9.4 ft·lbf)
59C-9-E1.book 10 ページ ２０１２年６月２６日　火曜日　午前１１時３３分

PERIODIC MAINTENANCE AND ADJUSTMENT
6-37
2
3
4
567
8
9
EAU42503
Troubleshooting charts Starting problems or poor engine performance
Check the fuel level in
the fuel tank.1. Fuel
There is enough fuel.There is no fuel.
Check the compression.
Supply fuel.
The engine does not start.
Check the compression.
Operate the electric starter.2. Compression
There is compression.
There is no compression.
Check the ignition. Have a Yamaha dealer
check the vehicle.
Remove the spark plugs
and check the electrodes.3. Ignition
Wipe off with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Yamaha dealer check the vehicle.
The engine does not start.
Have a Yamaha dealer
check the vehicle.
The engine does not start.
Check the battery.
Operate the electric starter.4. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The battery is good.Check the battery lead connections,
and have a Yamaha dealer charge
the battery if necessary.
DryWet
Operate the electric starter.
59C-9-E1.book 37 ページ ２０１２年６月２６日　火曜日　午前１１時３３分

SCOOTER CARE AND STORAGE
7-4
1
2
3
4
5
67
8
9stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to pro- tect the cylinders, piston rings, etc.
from corrosion.
a. Remove the spark plug caps and the spark plugs.
b. Pour a teaspoonful of engine oil into the spark plug bores.
c. Install the spark plug caps onto the spark plugs, and then place
the spark plugs on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder walls with oil.)
e. Remove the spark plug caps from the spark plugs, and then
install the spark plugs and the
spark plug caps. WARNING!
To prevent damage or injury
from sparking, make sure to
ground the spark plug elec-
trodes while turning the en-
gine over.
[EWA10951]

4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the scooter so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0  C (30 F) or more than 30
 C (90 F)]. For more information
on storing the battery, see page
6-28.
TIPMake any necessary repairs beforestoring the scooter.
59C-9-E1.book 4 ページ ２０１２年６月２６日　火曜日　午前１１時３３分

INDEX
AABS (for ABS models) ............................. 3-16
ABS warning light (for ABS models) .......... 3-3
Acceleration and deceleration ................... 5-3
Air filter element, replacing ...................... 6-15
Anti-theft alarm (optional) ........................ 3-12
Auxiliary light bulb, replacing ................... 6-35BBattery ..................................................... 6-28
Brake fluid, changing ............................... 6-24
Brake fluid level, checking ....................... 6-23
Brake lever, front ..................................... 3-14
Brake lever, rear ...................................... 3-14
Brake levers, lubricating .......................... 6-25
Braking ...................................................... 5-3CCables, checking and lubricating ............. 6-24
Care ........................................................... 7-1
Catalytic converter ................................... 3-19
Centerstand and sidestand, checking and lubricating ....................................... 6-26
Coolant .................................................... 6-14DDimmer switch ......................................... 3-13
Drive belt slack ........................................ 6-24EEngine break-in ......................................... 5-4
Engine idling speed ................................. 6-16
Engine oil and oil filter cartridge .............. 6-11
Engine stop switch................................... 3-13
Engine trouble warning light ...................... 3-3FFront and rear brake lever free play, checking ................................................ 6-20 Front and rear brake pads, checking ...... 6-22
Front fork, checking................................. 6-26
Fuel ......................................................... 3-18
Fuel consumption, tips for reducing .......... 5-4
Fuel tank cap........................................... 3-17
Fuses, replacing ...................................... 6-30
HHandlebar switches ................................. 3-12
Hazard switch.......................................... 3-13
Headlight bulb, replacing......................... 6-32
Helmet holder .......................................... 3-21
High beam indicator light ........................... 3-3
Horn switch ............................................. 3-13IIdentification numbers ............................... 9-1
Ignition circuit cut-off system ................... 3-27
Immobilizer system ................................... 3-1
Immobilizer system indicator light ............. 3-4
Indicator lights and warning lights ............. 3-3LLicense plate light bulb, replacing ........... 6-34MMain switch/steering lock .......................... 3-2
Maintenance and lubricatio
n, periodic....... 6-4
Maintenance, emission control system ..... 6-3
Matte color, caution ................................... 7-1
Model label ................................................ 9-1
Multi-function display................................. 3-5PPanels, removing and installing ................ 6-8
Parking ...................................................... 5-5
Part locations ............................................ 2-1
Pass switch ............................................. 3-13
RRear brake lock cable, adjusting.............. 6-21
Rear brake lock, checking .......................6-21
Rear brake lock lever ............................... 3-15
Rear view mirrors..................................... 3-25
Rider backrest, adjusting .........................3-20SSafe-riding points .......................................1-5
Safety information ......................................1-1
Seat ......................................................... 3-20
Shock absorber assembly .......................3-26
Sidestand .................................................3-26
Spark plugs, checking ..............................6-10
Specifications.............................................8-1
Speedometer .............................................3-5
Starting off .................................................5-2
Starting the engine.....................................5-1
Start switch ..............................................3-13
Steering, checking ................................... 6-27
Storage ......................................................7-3
Storage compartments ............................3-22TTachometer................................................3-5
Tail/brake light ......................................... 6-33
Throttle grip and cable, checking and lubricating ..............................................6-25
Throttle grip free play, checking............... 6-17
Tires ......................................................... 6-17
Tool kit .......................................................6-2
Troubleshooting ....................................... 6-35
Troubleshooting charts ............................6-37
Turn signal indicator lights .........................3-3
Turn signal light bulb (front), replacing ....6-33
Turn signal switch .................................... 3-13
59C-9-E1.book 2 ページ ２０１２年６月２６日　火曜日　午前１１時３３分
