2013 VOLVO C70 Owner´s Manual

11 Specifications
Engine specifications
11
279 Fuel system
The engine is equipped with a multiport fuel
injection system.

11 Specifications
Electrical system
11
280
General information
12-volt system with voltage controlled gener-
ator. Single wire system in which the chassis
and engine block are used as conductors,
grounded on the chassis.
Battery
Voltage12 V
Cold start capacity (CCA)700 AA
Reserve capacity (RC)135 min
Capacity (Ah)80
AModels equipped with the Premium Sound audio system,
the Volvo Navigation System and/or keyless drive.
If the battery must be replaced, replace it with
one with the same cold start capacity and
reserve capacity as the original (see the decal
on the battery).
WARNING
PROPOSITION 65 WARNING!
Battery posts, terminals, and related acces-
sories contain lead and lead compounds,
chemicals known to the state of California
to cause cancer and reproductive harm.
Wash hands after handling.

11 Specifications
Three-way catalytic converter
11
281 Three-way catalytic converter –
general information
•Keep your engine properly tuned. Certain
engine malfunctions, particularly involving
the electrical, fuel or distributor ignition
systems, may cause unusually high three-
way catalytic converter temperatures. Do
not continue to operate your vehicle if you
detect engine misfire, noticeable loss of
power or other unusual operating condi-
tions, such as engine overheating or back-
firing. A properly tuned engine will help
avoid malfunctions that could damage the
three-way catalytic converter.
•Do not park your vehicle over combustible
materials, such as grass or leaves, which
can come into contact with the hot exhaust
system and cause such materials to ignite
under certain wind and weather condi-
tions.
•Excessive starter cranking (in excess of
one minute), or an intermittently firing or
flooded engine can cause three-way cata-
lytic converter or exhaust system over-
heating.
•Remember that tampering or unauthorized
modifications to the engine, the Electronic
Control Module, or the vehicle may be ille-
gal and can cause three-way catalytic con-
verter or exhaust system overheating. This
includes: altering fuel injection settings or
components, altering emission systemcomponents or location, or removing com-
ponents, and/the repeated use of leaded
fuel.
NOTE
Unleaded fuel is required for vehicles with
three-way catalytic converters.

11 Specifications
Overview of information and warning symbols
11
282* Option/accessory, for more information, see Introduction.
Introduction
The symbols in the vehicle's various displays
are divided into three main categories:
•Warning symbols
•Indicator symbols
•Information symbols
The following tables list the most common
symbols, their Description and the pages in this
manual that provide more detailed information.
Warning symbol
The red warning symbol lights up to indi-
cate a problem related to safety and/or driva-
bility. A message will also appear in the main
instruments panel's display.
Information symbol
The yellow information symbol lights up
and a text message is displayed to provide the
driver with necessary information about one of
the vehicle's systems.
Symbols in the main instrument panel
Indicator and warning symbols
SymbolDescriptionPage
Warning56
Information56
Malfunction indi-
cator light58
Fault in the ABS
system58
Rear fog light58
Stability system
DSTC*159
SymbolDescriptionPage
Fuel level warning
light58
Trailer turn signal
indicator59
Parking brake
applied59
SRS airbag sys-
tem59
Oil pressure warn-
ing light59
Seat belt reminder59

11 Specifications
Overview of information and warning symbols
11
* Option/accessory, for more information, see Introduction.283
SymbolDescriptionPage
Generator warn-
ing light59
Brake failure
warning light60
High beam indica-
tor54
Left turn signal54
Right turn signal54
Other information symbols
SymbolDescriptionPage
Rain sensor*75
Cruise control*72
Information symbols in the center
console display
SymbolDescriptionPage
G021216
Surround sound
(Premium Sound
only)248
HD radio253
Audio files259
CD folder259
Bluetooth-con-
nected cell phone263
BluetoothTM
hands-free
263
Information symbols in the ceiling
console
SymbolDescriptionPage
Seat belt reminder59
Occupant weight
sensor29

11 Specifications
Volvo programs
11
284
Volvo On Call Roadside Assistance
Your new Volvo comes with a four year ON
CALL roadside assistance. Additional informa-
tion, features, and benefits are described in a
separate information package in your glove
compartment.
If you require assistance, dial:
In the U.S. 1-800-638-6586 (1-800-63-
VOLVO)
In Canada 1-800-263-0475
Technician certification
In addition to Volvo factory training, Volvo sup-
ports certification by the National Institute for
Automotive Service Excellence (A.S.E.). Certi-
fied technicians have demonstrated a high
degree of competence in specific areas.
Besides passing exams, each technician must
also have worked in the field for two or more
years before a certificate is issued. These pro-
fessional technicians are best able to analyze
vehicle problems and perform the necessary
maintenance procedures to keep your Volvo at
peak operating condition.

11 Specifications

11
285

12 Index
12
286
1, 2, 3 ...
12-volt sockets..................................63, 117
A
A/C (air conditioning)................................. 88
ABS (anti-lock brake system).................. 155
Accessory installation warning.................. 14
Adaptive brake lights............................... 154
Airbags
front...................................................... 25
inflatable curtain................................... 34
side impact........................................... 32
Airbag system............................................ 25
Air conditioning.......................................... 88
Air distribution table................................... 95
Air vents..................................................... 90
Alarm system........................................... 135
turning off sensors.............................. 136
Anti-lock Brake System (ABS)................. 155
Approach lighting...................................... 82
Audio files................................................ 259Audio system
audio functions................................... 245
automatic sound control..................... 249
AUX port............................................. 246
Bluetooth streaming audio................. 247
compact disc care.............................. 260
Dolby Surround Pro Logic II............... 248
equalizer............................................. 249
HD digital radio................................... 253
menu settings..................................... 262
radio functions.................................... 251
selecting a sound source.................... 245
SiriusXM
E satellite radio.................... 255
sound settings.................................... 248
steering wheel keypad........................ 245
storing radio stations.......................... 251
subwoofer........................................... 248
USB/iPodŸ connector........................ 246
Auto-dim rearview mirror........................... 78
Autolock..................................................... 81
Automatic locking retractor....................... 40
Automatic sound control.........................249
Automatic transmission........................... 151
kickdown............................................ 152
oil........................................................ 275
shiftlock override................................ 153
Automatic transmission - Geartronic....... 152AUX port.................................................. 246
Axle weight......................................185, 273
B
Bass......................................................... 248
Battery
maintenance....................................... 224
remote key, replacing......................... 124
specifications...................................... 280
warning symbols................................. 224
Battery – replacing................................... 225
Blind Spot Information System (BLIS)..... 168
Bluetooth cell phone connection............. 263
Booster cushion
accessory............................................. 47
Brake fluid........................................ 222, 275
Brake lights........................................ 66, 154
Brake system
anti-lock brakes (ABS)........................ 155
Brake pad inspection.......................... 154
emergency brake assistance.............. 156
fluid..................................................... 222
general information............................. 154
