NOTICE
x Things like trailer draw bars, thin rods, fences, trees, narrow painted vertical poles, posts,
or a rear hatch that is opening may not be detected by the Park Distance Control sensors and
could damage the vehicle.
x If you continue driving closer to an object that the Park Distance Control has already
detected and reported, the object may disappear from the sensor range and may no longer be
detected. This is especially true for low or high objects. The system will no longer sound
warnings about these objects. Ignoring signals from the Park Distance Control system could
result in serious damage to the vehicle.
x The sensors in the bumper can be damaged or become misaligned in low speed impacts
and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report
objects that might be within range of the PDC system.
x To help make sure that the system works properly, always keep the sensors in the bumpers
clean, free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors
directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from
the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for
example, can prevent the Park Distance Control system from accurately detecting and
reporting people and objects that may be within range of the system sensors.
Volkswagen recommends practicing with the Park Distance Control system in a location or
parking space with no traffic in order to become familiar with the system and how it works.
Park Distance Control (PDC)
Fig. Park Distance Control system sensors.
Orientation lines overview
Meaning of the orientation lines and areas projected on screen ⇒ fig. . All distances of the orientation
lines refer to a vehicle on a level surface.
(1) Safety distance: Area up to about 16 inches (40 cm) behind the vehicle on the road.
(2) Vehicle's width limits.
(3) Point to change steering angle.
When the yellow line touches the curb or any other parking space boundary, the steering wheel
must be turned in the opposite direction (close-up view).
(4) The parking area parallel to the vehicle which is needed for parking. The area shown must fit
completely into the parking space.
(5) Parked vehicle at the curb.
Parking
x Position the vehicle about 3 feet (1 meter) away from and parallel to the parking space and shift
into reverse.
x On the screen of the navigation system, activate Mode 2 for parallel parking.
x Back up slowly and steer the vehicle so that the yellow surface on the screen is flush with the side
boundary of the parking space (such as the curb) and stops short of any obstacle (5), such as another
vehicle.
x Turn the steering wheel as far as it will go into the direction of the parking space and slowly back
up.
x Once the yellow line (3) touches the side boundary of the parking space, such as a painted line or
a curb (close-up view), turn the steering wheel as far as it will go in the opposite direction.
x Continue backing up until the vehicles is positioned in the parking space parallel to the roadway. If
necessary, correct the parking position.
It may take up to 5 seconds for the area detected by the sensors to be displayed on the factory-
installed radio or navigation system screen.
