2013 VOLKSWAGEN GOLF Owners Manual

Convenience
menu Function
Driver
Manual unlocking: The driver window opens when the key is
held in the unlocking position.
Manual locking: All windows close when the key is held in the
locking position.
Keyless Access: All windows close when the locking sensor
on the door handle is pressed and held .
Back The display switches back to the Convenience menu.
Mirror adjust

IndividuallyBoth outside mirrors are adjusted separately.
Both mirrorsThe front passenger outside mirror is adjusted at the same
time as the driver outside mirror.
Back The display switches back to the Convenience menu.
Factory
setting Resets the features in the Convenience submenu back to the factory settings.
Back The display returns to the Settings menu.

Lights & Vision submenu

Driving checklists and warnings

d Properly fasten your safety belt before driving the vehicle and wear your safety belt properly at all
times while driving. Make sure that all passengers do the same
d Only transport as many passengers as there are seats and safety belts available.
d Never drive if your driving ability has been impaired, for example by medication, alcohol or illegal
drugs.
d Never let passengers or phone calls distract you while driving, and never take your attention off the
road while using vehicle software or adjusting vehicle equipment or accessories.
d Always adapt your speed and driving style to visibility, weather, road, and traffic conditions.
d Always obey traffic laws and speed limits.
d On long trips make frequent rest stops – at least once every 2 hours.
d Secure animals in the vehicle with a system that corresponds to weight and size.
WARNING
Always observe traffic rules and posted speed limits and use common sense. Your good
judgment can mean the difference between arriving safely at your destination and being
seriously injured in a crash or other kind of accident.
Regular service and maintenance of your vehicle is important both for operational and driving
safety and to help prolong your vehicle's service life. Always follow the scheduled maintenance
intervals in the ⇒ Booklet Warranty and Maintenance, especially for changing the brake fluid. Hard
use, frequent stop-and-go driving, driving in very dusty areas, trailer towing, and other factors may
make it necessary to have the vehicle serviced more frequently. Ask an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility for more information.
Driving in other countries

d Are special or heavy-duty tires necessary for the kind of driving expected?
NOTICE
Volkswagen is not responsible for mechanical damage that may result from substandard fuel
or service or the unavailability of Genuine Volkswagen parts.
Driving through water on roads

Technical data

Fig. 18 Vehicle identification number (VIN).

Maximum power
output (SAE net)
Injection
technology
Engine
ID
code
Maximum torque (SAE net) No. of cylinders
Displacement
170 hp at 5700 rpm
(125 kW at
5700 rpm)
CBTA
CBUA
2.5L
177 lb-ft at 4250 rpm
(240 Nm at 4250 rpm)
5 cylinders
151 CID
(2480 ccm)
256 hp at 6000 rpm
(188 kW at
6000 rpm)
TSI® CRZA
2.0L
243 lb-ft at 2,400 – 5,200 rpm
(330 Nm at 2400 – 5200 rpm)
4 cylinders
121 CID
(1984 ccm)

Diesel engines

Maximum power
output (SAE net)
Injection
technology
Engine
code
Maximum torque No. of cylinders
Displacement
140 hp at 4,000 rpm
(103 kW at 4,000 rpm
with DPF)
TDI® CJAA
2.0L
236 lb-ft at 1750 rpm
(320 Nm at 1750 rpm)
4 cylinders
120 CID
(1968 ccm)

Dimensions

Vehicle key set
