Description Possible causes,
among others Possible remedy
DSG® Direct Shift
Gearbox too hot.
Stop vehicle as soon as
you can safely do so.
Driver seat and
outside mirrors
move when vehi-
cle is unlocked.
Convenience
settings are stored.
Correct convenience
settings
Memory-seat set-
tings are stored.
– Reassign seat setting
– Clear memory-seat
memory
Front seats can-
not be adjusted
with power con-
trols.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if
necessary
No jack, spare
wheel, or com-
pact spare wheel
in the vehicle.
Equipment differs
depending on the
vehicle.
No direct corrective action
possible; depends on the
vehicle equipment. Con-
tact an authorized
Volkswagen dealer or an
authorized Volkswagen
Service Facility for assis-
tance.
Vehicle has run-flat
tires (mobility tires).
Features do not
work as de-
scribed in this
manual.
Settings were ad-
justed in the
Volkswagen Infor-
mation System.
Check and reset to factory
settings if necessary
Headlights do not
light up the road
as they should.
– Headlights incor-
rectly adjusted.
– Light bulbs burned
out.
– Low beams not
switched on.
– Have the headlight
range adjusted by an au-
thorized Volkswagen
dealer or an authorized
Volkswagen Service Fa-
cility.
– Change light bulbs
– Switch on low beams

WARNING
Using the wrong fuse, using a blown fuse that has been re-
paired, and using metal objects in place of fuses to complete
the electrical connection in the circuit can cause fires and seri-
ous personal injury.
Never replace a fuse with one that has a higher amp rating.
Replace a blown fuse only with a fuse of the same amperage
(same color and same imprint) and same overall size.
Never repair fuses.
Never replace fuses with a metal strip, a paper clip, or a simi-
lar object.
NOTICE
To help prevent damage to the electrical system, switch off all
lights and accessories, switch off the ignition, and remove the
key from the ignition switch before replacing a fuse.
If a fuse is replaced with a fuse with higher amperage, this can
also cause damage at different locations in the electrical system.
Open fuse boxes must be protected from dirt and moisture.
Dirt and moisture in fuse boxes can cause damage to the electri-
cal system.
Fuses in the vehicle

Fig. 196 On the driver side of the instrument panel: Fuse box cover.

Fig. 197 In the engine compartment: Fuse box cover.

Opening the fuse box in the instrument panel
Insert a flat object, such as a screwdriver from the vehicle tool kit,
into the opening ⇒ fig. 196 (arrow) and carefully lift off the cover.
On the inside of the cover there are plastic tweezers for removing
and inserting fuses.
To install, guide the cover from the bottom into the instrument
panel and push until you can hear it latch into place.
Opening the fuse box in the engine compartment
Open the engine hood

For small fuses, slide the tweezers ⇒ fig. 199 (1) onto the fuse from
the top A.
For larger fuses, slide the tweezers (1) onto the fuse from the side
B.
Pull out the blown fuse.
If the fuse is blown, replace the fuse with a new fuse of the same
amperage (same color and same imprint) and same overall size ⇒ .
If necessary, replace the plastic tweezers in the fuse box cover.
Replace the cover.
NOTICE
If a fuse is replaced with a fuse with higher amperage, then dam-
age can occur at various places in the electrical system.
