2013 VOLKSWAGEN CC airbag

Upper center console

Fig. 6 Overview of the upper center console.
Key to ⇒ fig. 6:
(1) Switch for emergency flashers
(2) PASSENGER AIR BAG /&& light (front airbag for front seat pas-
senger)
(3) Radio or Radio & Navigation system (factory-installed)
⇒ Booklet Radio or ⇒ Booklet Navigation system.
(4) Climatronic controls
(5) Air vents

Front passenger side overview

Fig. 8 Overview of the front passenger side.
Key to ⇒ fig. 8:
(1) Passenger front airbag location in the instrument panel (approx-
imate)
(2) Opening handle for the lockable glove compartment
(3) Air vent

Initiating or accepting a call on a mobile device connected to
the vehicle's mobile phone package could end any connection to
the Volkswagen Car-Net Response Center made through the •,
> or • buttons.
Calls on a mobile device connected to the vehicle's mobile
phone package cannot be accepted or initiated during an auto-
mated emergency connection to the Volkswagen Car-Net Re-
sponse Center; for example, because an airbag has deployed.

WARNING
Improper seating positions increase the risk of severe or fatal
injuries in a crash or other accidents, especially when the air-
bag deploys.
All occupants must sit properly and be properly restrained at
all times.
Never let more people ride in the vehicle than there are seat-
ing positions with safety belts available.
Always secure children in the vehicle with an approved and
suitable restraint system appropriate for their age, weight, and
height
Always keep your feet on the floor in front of the seat. Never
rest them on the seat, instrument panel, out of the window, etc.
The airbag system and safety belt will not be able to protect
you properly and can even increase the risk of injury in a crash.

WARNING
Always adjust seat, safety belts, and head restraints properly
before driving and make sure that all passengers are properly
restrained.
Push the passenger seat as far back as possible. Always be
sure that there are at least 10 inches (25 cm) between the front
passenger's breastbone and the instrument panel.
Always adjust the driver's seat and the steering wheel so that
there are at least 10 inches (25 cm) between your breastbone
and the steering wheel.
Adjust the driver's seat so that you can easily push the ped-
als all the way to the floor while keeping your knee(s) slightly
bent. The distance to the instrument panel in the knee area
must be at least 4 inches (10 cm).
If these requirements cannot be met for physical reasons,
contact an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility to see whether adaptive equipment
is available.
Always hold the steering wheel on the outside of the steering
wheel rim with your hands at the 9 o'clock and 3 o'clock posi-
tions to help reduce the risk of personal injury if the driver's
airbag inflates.
Never hold the steering wheel at the 12 o'clock position or
with your hands at other places inside the steering wheel rim or
on the steering wheel hub. Holding the steering wheel the
wrong way can cause serious injuries to the hands, arms, and
head if the driver's airbag inflates.
Pointing the steering wheel toward your face decreases the
ability of the driver's airbag to help protect you in a collision.
Never drive with backrests reclined or tilted back farther than
necessary to drive comfortably. The farther back the backrests
are tilted, the greater the risk of injury caused by incorrect posi-
tioning of the safety belts and improper seating position.
Never drive with the front seat passenger backrest tilted for-
ward. If the front airbag deploys, the front backrest can be
forced backward and injure passengers on the rear seat.
Sit as far back as possible from the steering wheel and the
instrument panel.

Always sit upright with your back against the backrest with
the front seats properly adjusted. Never lean against or place
any part of your body too close to the area where the airbags
are located.
Rear seat passengers who are not properly seated and re-
strained are more likely to be seriously injured in a crash.
WARNING
Improper adjustment of the seats can cause accidents and se-
vere injuries.
Never adjust the seats while the vehicle is moving. Your seat
may move unexpectedly and you could lose control of the vehi-
cle. In addition, you will not be in the correct seating position
while adjusting the seats.
Adjust the front seat height, angle and longitudinal direction
only if the seat adjustment area is clear.
The adjustment of the front seats must not be restricted by
things in the footwell in front or behind the seats.
WARNING
Some kinds of cigarette lighters can be lit unintentionally, or
crushed causing a fire that can result in serious burns and ve-
hicle damage.
Always make sure that there are no lighters in the seat tracks
or near other moving parts before adjusting the seats.
Before closing a storage compartment, always make sure
that no cigarette lighter can be activated, crushed, or otherwise
damaged.
Never leave a cigarette lighter in a storage compartment, on
the instrument panel, or in other places in the vehicle. Heat
buildup in the passenger and luggage compartment of a parked
vehicle can result in temperatures in the vehicle that are much
higher than the outside temperatures, particularly in summer.
High temperatures could cause the cigarette lighter to catch
fire.

WARNING
Contact with parts of the vehicle interior can cause serious
personal injury in a crash.
Always make sure that all vehicle occupants stay in a proper
seating position and are properly restrained whenever the vehi-
cle is moving.
Improper seating positions increase the risk of serious and
fatal injury, especially when an airbag deploys and strikes a
passenger in an improper seating position.
Proper seating position

Fig. 43 The driver should never sit closer than 10 inches (25 cm) of
the steering wheel.

Fig. 44 Proper safety belt positioning and head restraint adjustment.

Never hold the steering wheel at the 12 o'clock position or with your
hands at other places inside the steering wheel rim or on the steering
wheel hub. Holding the steering wheel the wrong way can cause seri-
ous injuries to the hands, arms, and head if the driver's airbag in-
flates.
Adjust the steering wheel so that the steering wheel cover points at
your chest and not at your face. Pointing the steering wheel toward
your face decreases the ability of the driver's airbag to help protect
you in a collision.
Adjust the driver's seat so that you can easily push the pedals all
the way to the floor while keeping your knee(s) slightly bent.
Adjust the seat height so that the top point of the steering wheel
can be reached.
Always keep both feet in the footwell so that you are in control of
the vehicle at all times.
Passenger - front seat adjustment:
Push the passenger seat as far back as possible in order to ensure
optimum protection if the airbag is deployed.
Manual controls on the driver and front passenger seats

Fig. 45 Controls on the left front seat.
