2013 VOLKSWAGEN CC ESP

WARNING
If you must change the engine oil yourself, be sure to take the
following precautions:
Always wear eye protection.
To reduce the risk of burns from hot engine oil, let the engine
cool down completely before beginning.
When removing the oil drain plug with your fingers, stay as
far away as possible. Always keep your forearm parallel to the
ground to help prevent hot oil from running down your arm.
Drain the oil into a container designed for this purpose, one
large enough to hold at least the total amount of oil in your en-
gine.
To reduce the risk of poisoning, never drain the oil into emp-
ty food or beverage containers that might mislead someone in-
to drinking from them.
Engine oil is poisonous and must be stored out of the reach
of children.
Continuous contact with used engine oil is harmful to your
skin. Always protect your skin by washing thoroughly with
soap and water.
Before changing the oil, first make sure you know where you can
properly dispose of the old oil.
Dispose of the old oil an environmentally-responsible manner.
Never dump the old oil on garden soil, in wooded areas, in the street,
into streams, rivers, or bodies of water, or down sewage drains.
Recycle used oil by taking it to a collection facility for used engine
oil in your area, or contact an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
Volkswagen recommends that you always have your oil and oil
filter changed by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility. They have the required expertise and
special tools and will dispose of the old oil properly.

If the indicator in the engine coolant temperature gauge is located in
the cold range (A), the engine has not reached operating tempera-
ture. High engine speeds and heavy engine loads should be avoided.
Under normal driving conditions, the needle should be in the middle
of the gauge. The temperature may go higher when the engine is
working hard, especially in hot weather.
When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
The following table explains what to do if the engine coolant tempera-
ture warning light ~ does not go out a few seconds after the engine
is started or starts flashing while driving.

Flashes
Temperature
gauge
needle
⇒ fig. 167
Possible
cause Proper response

Flashes
Temperature
gauge
needle
⇒ fig. 167
Possible
cause Proper response
~
(C)
Warning
zone
Engine coolant
temperature
too high.

Flashes
Temperature
gauge
needle
⇒ fig. 167
Possible
cause Proper response
(B)
Normal range
Engine coolant
level too low.
Check the engine coolant
level after the engine has
cooled down and add en-
gine coolant if low.
If the engine coolant level
is correct or the problem
continues after adding
coolant, do not drive any
farther. Contact an au-
thorized Volkswagen deal-
er or authorized
Volkswagen Service Facili-
ty.
These instructions apply
only when the coolant
temperature stays in the
normal range. Stop imme-
diately if the needle goes
into the red warning zone
(C).
–
Engine coolant
system
malfunction.

Automatic electrical load deactivation
If the vehicle battery drain is high, the intelligent onboard electrical
system management automatically takes steps to help prevent bat-
tery drain.
The idle speed is increased so that the alternator provides more
power.
The power to devices that consume a lot of electricity is cut back or
switched off completely.
When the engine is started, the power supply to the 12 Volt sockets
is temporarily interrupted.
The onboard electrical system management cannot always keep the
battery from being drained. For example, the battery will drain if the
engine is not running, but the ignition is switched on or the parking
lights are left on for a long time when parked.
Battery disconnection in an accident with airbag deployment
In vehicles with a battery in the luggage compartment, the electrical
connection to the battery is disconnected automatically in a collision
with airbag deployment. This helps to prevent a short-circuit.
What drains the vehicle battery?
Long periods when the engine is not running, especially when the
ignition is on.
Using electrical systems or devices when the engine is switched
off.
Leaving the vehicle unlocked for several days when not in use.
The selector lever is left for a long period of time in any position
other than P when the ignition is switched off ⇒  Automatic transmis-
sion: Selector lever.
WARNING
Failure to use the proper battery with proper mounting and
connections may cause short circuits, fires, and serious per-
sonal injuries.
Always use only maintenance-free or cycle-free, leak-proof
batteries with the same specifications and dimensions as the
original equipment battery. Specifications are listed on the bat-
tery housing.

Cleaning upholstery on non-heated seats, manual seats, or seats
without airbag components
Before using any cleaning agent, familiarize yourself with instruc-
tions and warnings on the packaging.
Vacuum upholstery, fabric trim, Alcantara® upholstery, and carpet-
ing regularly with a suitable brush attachment.
Do not use power washers, steam cleaners, or cooling spray.
A soft sponge or a commercially available lint-free microfiber cloth
may be used for general cleaning ⇒ .
Clean Alcantara® surfaces with a damp cotton or wool cloth or a
commercially available lint-free microfiber cloth ⇒ .
Upholstery and fabric trim with light generalized soiling can be
cleaned with a commercially available dry-foam cleaner.
If the upholstery and fabric trim pieces are heavily soiled, see your
authorized Volkswagen dealer or authorized Volkswagen Service
Facility before you begin cleaning to learn about suitable cleaning
options. If necessary, have the cleaning done by a professional.
Treating stains
When treating stains, it may be necessary to clean the entire surface
and not just the stain itself. This is especially true if the entire surface
has become dirty from normal use. Otherwise, the area that is treated
may become lighter than the untreated area. If you have questions or
concerns, consult a professional cleaner.

Type of stain Recommended cleaning for fabric and uphol-
stery
Water-based
stains, such as
coffee or fruit
juice.
– Moisten a sponge with water and rub the stain
gently with a circular motion.
– Wipe dry with an absorbent cloth.
Persistent stains,
such as choco-
late or make-up.
– Use only Volkswagen-approved cleaning prod-
ucts.
– If necessary, have the fabric or upholstery pro-
fessionally cleaned.

After each cleaning, apply cream that waterproofs the leather and
protects it against the sun. Such creams also nourish the leather, let it
breathe, keep it flexible and moisturized. At the same time it protects
the surface.
Clean leather every 2 to 3 months and remove any new stains.
Treat leather with a suitable leather-care product twice a year ⇒ .
Apply cleaning and conditioning materials sparingly and always
with a dry, lint-free cotton or wool cloth. Do not apply cleaning and
conditioning materials directly to the leather.
Remove fresh stains such as ballpoint pen, lipstick, ink, shoe
polish, etc. as soon as possible.
Preserve the leather's color. If necessary, refresh fading spots with
a specially-colored leather cream.
Wipe the leather with a soft cloth.
Cleaning
Volkswagen recommends using a slightly moistened cotton or wool
cloth for general cleaning.
It is important not to let water soak through the leather or penetrate
into seams.
Before cleaning leather surfaces, read and heed the information ⇒ ,
Cleaning upholstery on heated seats and power seats or seats with
airbag components.

Type of stain Cleaning
Heavy stains – Apply a mild soapy solution with a cloth that
has been wrung nearly dry4.
– Dab dry with an absorbent cloth.
Water-based
stains, such as
coffee, tea, juice,
or blood.
– Remove fresh stains with an absorbent cloth.
– If the stains are already dry, use an appropri-
ate cleaning agent ⇒ .
4 Mild soap solution: 2 tablespoons of liquid soap in 1 quart (liter) of water.

⇒ Booklet Radio
⇒ Booklet Navigation system
⇒ Booklet Mobile Phone Package
WARNING
Inappropriate spare parts and accessories as well as improper-
ly performed work, modifications and repairs can cause vehicle
damage, accidents and serious personal injuries.
Volkswagen strongly recommends to only use accessories
approved by Volkswagen and Genuine Volkswagen Parts®.
These parts and accessories have been evaluated by
Volkswagen for their suitability, reliability and safety.
Have repairs and vehicle modifications performed by an au-
thorized Volkswagen dealer or authorized Volkswagen Service
Facility. Authorized Volkswagen dealers and authorized
Volkswagen Service Facilities have the required tools, diagnos-
tic equipment, repair information, and trained personnel to
properly replace any airbag in your vehicle and assure system
effectiveness in a crash.
Only install parts on the vehicle that are consistent with fac-
tory-installed parts with respect to design and characteristics.
Never store, mount, or attach objects, such as cup holders or
phone cradles, on or next to the airbag module covers or within
the airbags deployment zones.
Only use wheel rim/tire combinations approved by
Volkswagen for the respective vehicle type.
Break-in period
