4-3. Do-it-yourself maintenance
4
Maintenance and care
LC200_OM_OM60F57U_(U)
Wheels
If a wheel is bent, cracked or heavily corroded, it should be
replaced.
Otherwise, the tire may separate from the wheel or cause loss of
handling control.
■Wheel selection
When replacing wheels, care should be taken to ensure that
they are equivalent to those removed in load capacity, diameter,
rim width, and inset
*.
Replacement wheels are available at your Toyota dealer.
*: Conventionally referred to as “offset”.
Toyota does not recommend using:
●Wheels of different sizes or types
●Used wheels
●Bent wheels that have been straightened
■Aluminum wheel precautions
●Use only Toyota wheel nuts and wrenches designed for use
with your aluminum wheels.
●When rotating, repairing or changing your tires, check that the
wheel nuts are still tight after driving 1000 miles (1600 km).
●Be careful not to damage the aluminum wheels when using
tire chains.
●Use only Toyota genuine balance weights or equivalent and a
plastic or rubber hammer when balancing your wheels.

669 6-1. Specifications
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Lubrication system
*: The engine oil capacity is a reference quantity to be used when changing the
engine oil. Warm up and turn off the engine, wait more than 5 minutes, and
check the oil level on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows
cold startability. Oils with a lower value before the W allow for easier
starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil when
the oil is at high temperature. An oil with a higher viscosity (one with a
higher value) may be better suited if the vehicle is operated at high
speeds, or under extreme load conditions.
Oil capacity
(Drain and refill —
reference
*)
With filter
Without filter7.9 qt. (7.5 L, 6.6 Imp.qt.)
7.5 qt. (7.1 L, 6.2 Imp.qt.)
Outside temperature

685 6-1. Specifications
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation
pressureTire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a
tire may be inflated, shown on the sidewall of
the tire
Recommended
inflation pressureCold tire inflation pressure recommended by a
manufacturer.
Accessory weightThe combined weight (in excess of those stan-
dard items which may be replaced) of trans-
mission, power steering, power brakes, power
windows, power seats, radio and heater, to the
extent that these items are available as factory-
installed equipment (whether installed or not)
Curb weightThe weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded
vehicle weightThe sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

686 6-1. Specifications
LC200_OM_OM60F57U_(U)
Tire related termMeaning
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weightThe combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
RimA metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter)Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designationThe industry manufacturer’s designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity)The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity
Vehicle maximum load
on the tireThe load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two

691 6-1. Specifications
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
*:Table 1  Occupant loading and distribution for vehicle normal load
for various designated seating capacities
Designated seating
capacity, Number of
occupantsVehicle normal load,
Number of occupantsOccupant distribution in
a normally loaded
vehicle
2 through 4 2 2 in front
5 through 10 32 in front, 1 in second
seat
11 through 15 52 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 72 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

713 Alphabetical index
LC200_OM_OM60F57U_(U)
Keys
Electronic key ......................... 30
If you lose your keys............. 650
If your electronic key
battery is discharged .. 563, 651
Ignition switch ....................... 166
Keyless entry .......................... 32
Key number ............................ 30
Keys ....................................... 30
Mechanical key....................... 30
Wireless remote control key ... 44
Language
Multi-information
display ........................ 189, 700
Licence plate lights
Replacing light bulbs ............ 581
Wattage ................................ 675
Light bulbs
Replacing ............................. 581
Wattage ................................ 675
Lights
Door courtesy lights.............. 423
Emergency flasher switch .... 598
Fog light switch..................... 201
Hazard light switch ............... 598
Headlights switch ................. 196
Interior light switch................ 463
Personal light switch............. 464
Replacing light bulbs ............ 581
Turn signal lever ................... 176
Vanity lights .......................... 478
Wattage ................................ 675
Load capacity .......................... 309Maintenance
Do-it-yourself maintenance ...524
General maintenance ............520
Maintenance data..................666
Maintenance requirements....518
Reset the maintenance
data .....................................519
Meter
Instrument panel light
control .................................182
Meters ...................................179
Micro dust and pollen filter .....342
Mirrors
Inside rear view mirror.............88
Side mirror heater .................351
Side mirrors .............................90
Vanity mirrors ........................478
Moon roof ...................................97
MP3 disc ...................................373
Multi-information display ........189
Multi Terrain ABS .....................282
Multi-terrain Monitor ................257
Multi-terrain Select...................251
Navigation System
*
Noise from under vehicle ..........22
Odometer ..................................179
Off-road precautions ...............297
Oil
Engine oil ..............................530
Opener
Fuel filler door .......................101
Hood......................................527
Outside rear view mirrors
Adjusting and folding ...............90
Mirror position memory ...........68
Outside temperature
display ....................................480
Overhead console ....................469
Overheating, Engine ................658
L
M
N
O
*: For vehicles with a navigation system,
refer to the “Navigation System Owner’s Manual”.

716 Alphabetical index
LC200_OM_OM60F57U_(U)
Tires
Chains ...................................310
Checking ............................... 544
If you have a flat tire ..............633
Inflation pressure...................553
Information ............................ 680
Pressure warning system ......544
Replacing ..............................633
Rotating tires .........................544
Size ....................................... 674
Snow tires ............................. 310
Spare tire............................... 633
Tools ......................................... 633
Total load capacity...................309
Towing
Dinghy towing........................333
Emergency towing.................599
Trailer towing.........................315
TRAC ......................................... 282
Traction control........................282
Trailer towing ...........................315
Trip information display .......... 190
Trip meter .................................179
Turn signal lights
Replacing light bulbs ............. 581
Switch.................................... 176
Wattage .................................675Vanity lights
Vanity lights........................... 478
Wattage................................. 675
Vanity mirrors .......................... 478
Vehicle data recordings ............ 24
Vehicle identification
number ................................... 667
Vehicle stability control .......... 282
Vehicle load limits ................... 309
VIEW switch ............................. 257
Voice command switch
* ....... 429
VSC ........................................... 282
V

717 Alphabetical index
LC200_OM_OM60F57U_(U)
Warning buzzers
Brake system........................ 606
Open door ........................... 608
Seat belt reminder ................ 609
Warning lights
Anti-lock brake system ......... 608
Brake system........................ 606
Charging system .................. 607
Low fuel level........................ 610
Malfunction indicator lamp.... 607
Master warning ..................... 610
Open door ............................ 608
Pre-collision .......................... 608
Seat belt reminder ................ 609
Slip indicator light ................. 608
SRS airbags ......................... 607
Tire pressure ........................ 609
Unengaged “Park” ................ 609
Warning messages ................. 617
Warning reflector holder ........ 495
Washer
Checking .............................. 542
Preparing and checking
before winter ...................... 310
Switch ........................... 202, 208
Washing and waxing............... 512
Weight
Cargo capacity ..................... 302
Load limits ............................ 309
Weight .................................. 666
Wheels...................................... 557
Window glasses ....................... 93
Window lock switch .................. 93
Windows
Power windows ...................... 93
Rear window defogger ......... 351
Washer ......................... 202, 208Windshield wiper de-icer.........352
Windshield wipers ...................202
Wireless remote control key
Replacing the battery ............563
Wireless remote control key ....44
WMA disc ..................................373W
*: For vehicles with a navigation system,
refer to the “Navigation System Owner’s Manual”.
