2013 TOYOTA LAND CRUISER warning

5
When trouble arises
619 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
Indicates a malfunction in the intuitive parking
assist
The site of malfunction is shown flashing on the
display.
Indicates a malfunction in the cruise control
system
Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
Indicates a malfunction in the dynamic radar
cruise control system (if equipped)
Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
(If equipped)Indicates a malfunction in the VGRS
A buzzer also sounds.
Warning messageDetails

620 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning message goes off.
Warning messageDetailsCorrection procedure
Indicates that one or
more of the doors is
not fully closed
The system also indi-
cates which doors are
not fully closed.
If the vehicle reaches
a speed of 3 mph (5
km/h), flashes
and a buzzer sounds
to indicate that the
door(s) are not yet fully
closed.Make sure that all the
doors are closed.

5
When trouble arises
621 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
(Flashes)Indicates that the
moon roof is not fully
closed (with the
“ENGINE START
STOP” switch off, and
the driver’s door
open)Close the moon roof.
(Flashes)Indicates, if the vehi-
cle reaches a speed of
3 mph (5 km/h), that
the parking brake is
still engaged.Release the parking
brake.
Indicates that the
automatic transmis-
sion fluid temperature
is too high
A buzzer also sounds.Stop the vehicle in a
safe place, shift the shift
lever to “P” and wait
until the light goes off.
If the light goes off,
you may start the vehi-
cle again. If the light
does not go off, con-
tact your Toyota
dealer.
Warning messageDetailsCorrection procedure

622 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
Indicates that engine
oil level is low
A buzzer also sounds.Check the level of
engine oil, and add if
necessary.
This message may
appear if the vehicle is
stopped on a slope.
Move the vehicle to a
level surface and
check to see if the
message disappears.
Indicates that the
washer fluid level is
lowAdd washer fluid
Low tire inflation pres-
sureCheck the tire inflation
pressure, and adjust to
the appropriate level.
Warning messageDetailsCorrection procedure

5
When trouble arises
623 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle.Indicates that all main-
tenance according to
the driven distance on
the maintenance
schedule
* should be
performed soon.If necessary, perform
maintenance.
Comes on approxi-
mately 4500 miles
(7200 km) after the
maintenance data has
been reset.
Indicates that all main-
tenance is required to
correspond to the
driven distance on the
maintenance sched-
ule
*.Perform the necessary
maintenance.
Please reset the main-
tenance data after
the maintenance is per-
formed (P. 519) Comes on approxi-
mately 5000 miles
(8000 km) after the
maintenance data has
been reset. (The indi-
cator will not work
properly unless the
maintenance data has
been reset.)
Warning messageDetailsCorrection procedure

624 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
Warning messageDetailsCorrection procedure
(Flashes)
(If equipped)Indicates that the pre-
collision system is not
currently functional
because the grille or
the sensor is dirty• Check the grille and the
sensor and clean them
if they are dirty.
• In case of overheating,
the system will become
functional once the sys-
tem cools down. Indicates that the pre-
collision system is not
currently functional
due to overheating.
Indicates that intui-
tive parking assist is
dirty or covered with
iceClean the sensor.
Indicates that remain-
ing fuel is about 4.0
gal. (15.0 L, 3.3 Imp.
gal.) or less Refuel the vehicle.

5
When trouble arises
625 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
Indicates that the
dynamic radar cruise
control sensor is dirty
or covered with iceClean the sensor.
(If equipped)Indicates that the
dynamic radar cruise
control system is
unable to judge vehi-
cle-to-vehicle distance• Switch driving mode to
either normal or power.
• If the windshield wipers
are on, turn them off or
set them to either inter-
mittent or slow mode.
(Flashes)
(If equipped)Indicates that your
vehicle is nearing the
vehicle ahead (in vehi-
cle-to-vehicle dis-
tance control mode)
A buzzer also sounds.Slow the vehicle by
applying the brakes.
Warning messageDetailsCorrection procedure

626 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
Have the malfunction repaired immediately.
After taking the specified steps to correct the suspected problem,
check that the warning message and light go off.
Interior
buzzerExterior
buzzerWarning messageDetailsCorrection
procedure
Once3 times
(Flashes)The electronic key
was carried out-
side the vehicle
and a door other
than the driver’s
door was opened
and closed while
the “ENGINE
START STOP”
switch was in a
mode other than
off.Bring the
electronic
key back
into the
vehicle.
The driver’s door
was opened and
closed while the
electronic key was
not in the vehicle,
the shift lever was
in “P” and the
“ENGINE START
STOP” switch was
not turned off. Turn the
“ENGINE
START
STOP”
switch off
or bring the
electronic
key back
into the
vehicle.
