2013 SUBARU TRIBECA Owners Manual

11-38Maintenance and service/Replacing bulbs
Left-hand side
2. Use a screwdriver to remove the
secured clip of the washer tank. To make
it easy to access the bulb, move the
washer tank to the horizontal direction
(left-hand side).
3. Disconnect the electrical connector
from the bulb.
4. Remove the bulb from the headlight
assembly by turning it counterclockwise.
5. Replace the bulb with new one. At this
time, use care not to touch the bulbsurface.
6. Reconnect the electrical connector.
7. To install the bulb to the headlight
assembly, turn it clockwise until it clicks.
8. Install the air intake duct with clips
(right-hand side).
9. Set the washer tank to the original
place and secure it by clip (left-hand side). & Parking light (right-hand side)
1. Remove the bulb socket from the headlight assembly by turning it counter- clockwise.
2. Pull the bulb out of the socket.
3. Install a new bulb.
4. Set the bulb socket into the headlight
assembly and turn it clockwise until itlocks. NOTE
Contact your SUBARU dealer for the
bulb replacement of the left-hand side.

&Front turn signal light (right-
hand side)
1. Remove the bulb socket from the
headlight assembly by turning it counter-clockwise.
2. Remove the bulb from the socket by
pushing it and turning counterclockwise.
3. Install a new bulb.
4. Set the bulb socket into the headlight
assembly and turn it clockwise until itlocks. NOTE
Contact your SUBARU dealer for the
bulb replacement of the left-hand side. &Front fog light
It may be difficult to replace the bulbs.
Have the bulbs replaced by your SUBARU
dealer if necessary. &
Rear combination lights
1. Remove the two covers by inserting
the tip of a flat-head screwdriver.
2. Using a Phillips screwdriver, remove
the upper and lower screws. Then, slide
Maintenance and service/Replacing bulbs11-39
– CONTINUED –

11-40Maintenance and service/Replacing bulbs
the rear combination light assembly rear-
ward and remove it from the vehicle.
1) Stop light/Tail light
2) Rear turn signal light
3. Remove the bulb holder from the rear
combination light assembly by turning itcounterclockwise.
4. Remove the bulb from the socket by
pushing it and turning counterclockwise.
5. Install a new bulb.
6. Set the bulb holder into the rear
combination light assembly and turn it
clockwise until it locks.
7. Reinstall the rear combination light
assembly by sliding the two-pronged part
of the combination light assembly securely
to each holder of the vehicle side.
8. Tighten the two mounting screws, and
then close the covers. &
Backup light/Tail light
1. Use a flat-head screwdriver to remove
the light cover from the rear gate trim.
1) Tail light
2) Backup light

2. Turn the bulb socket counterclockwise
and remove it.
3. Pull the bulb out of the bulb socket and
replace it with a new one.
4. Install the bulb socket by turning it clockwise.
5. Install the light cover on the rear gate. &Rear gate light
1. Use a flat-head screwdriver to remove
the rear gate light assembly from the rear
gate trim.
2. Pull the bulb out of the bulb socket and
replace it with a new one.
3. Install the rear gate light assembly on
the rear gate. &License plate light
1. Wrap a flat-head screwdriver in vinyl
tape or cloth, insert it into the gap between
the license plate light assembly and the
rear gate.
2. Carefully pry the light assembly to
remove it.
3. Remove the bulb socket from the
license plate light assembly by turning itcounterclockwise.
Maintenance and service/Replacing bulbs11-41
– CONTINUED –

11-42Maintenance and service/Replacing bulbs
4. Pull the bulb out of the socket. Install a
new bulb.
5. Set the bulb socket into the license
plate light assembly and turn it clockwise
until it locks.
6. Reinstall the license plate light assem-
bly to the rear gate.&
Dome lightModels with Rear Seat Entertainment
Models without Rear Seat Entertainment
1. Remove the lens by prying the edge of
the lens with a flat-head screwdriver.
2. Turn the bulb until the flat surfaces at
its ends are aligned vertically. Pull the bulb
straight downward to remove it.
3. Install a new bulb.
4. Reinstall the lens.

&Map light
1. Remove the lens by prying the edge of
the lens with a flat-head screwdriver.
2. Turn the bulb until the flat surfaces at
its ends are aligned vertically. Pull the bulb straight downward to remove it.
3. Install a new bulb.
4. Reinstall the lens.
& Vanity mirror light
1. Remove the lens by prying the edge of
the lens with a flat-head screwdriver.
2. Pull the bulb out of the socket.
3. Install a new bulb.
4. Reinstall the lens. &Door step light
It may be difficult to replace the bulbs.
Have the bulbs replaced by your SUBARU
dealer if necessary.
Maintenance and service/Replacing bulbs11-43
– CONTINUED –

11-44Maintenance and service/Replacing bulbs
&Cargo area light
1. Remove the cargo area light assembly
by prying the edge of the light with a flat-
head screwdriver.
2. Remove the lens from the cargo area
light assembly.
3. Pull the bulb out of the socket.
4. Install a new bulb.
5. Reinstall the lens to the cargo area
light assembly.
6. Reinstall the cargo area light assembly
to the roof trim.

Specifications........................................................ 12-2
Dimensions ........................................................... 12-2
Engine .................................................................. 12-2
Fuel ...................................................................... 12-3
Engine oil ............................................................. 12-4
Front differential and rear differential gear oil ......... 12-6
Fluids ................................................................... 12-7
Engine coolant ...................................................... 12-7
Electrical system ................................................... 12-7 Tires
..................................................................... 12-8
Fuses and circuits .................................................12-9
Fuse panel located in the passenger compartment ...................................................... 12-9
Fuse panel located in the engine compartment ..................................................... 12-11
Bulb chart .............................................................12-12
Vehicle identification ...........................................12-15Specifications
12
