▫Power Steering Fluid Check ..............467
 FUEL SAVER TECHNOLOGY 5.7L ENGINE ONLY
– IF EQUIPPED ....................... .468
 PARKING BRAKE ..................... .468
 BRAKE SYSTEM ...................... .470
▫ Four-Wheel Anti-Lock Brake System ........471
▫ Hydraulic Brake Assist – 2500/3500 Models Only
– Except Power Wagon ..................472
 ELECTRONIC BRAKE CONTROL SYSTEM . . . .473
▫ Anti-Lock Brake System (ABS) ............473
▫ Traction Control System (TCS) – If Equipped . .474
▫ Brake Assist System (BAS) – If Equipped . . . .474
▫ Hill Start Assist (HSA) – If Equipped ........475▫
Hill Descent Control (HDC) – If Equipped (Power
Wagon Only) ....................... .479
▫ Electronic Stability Control (ESC) – If
Equipped .......................... .480
▫ ESC Activation/Malfunction Indicator Light
And ESC OFF Indicator Light ............484
▫ Trailer Sway Control (TSC) – If Equipped . . . .485
 TIRE SAFETY INFORMATION .............487
▫ Tire Markings ....................... .487
▫ Tire Identification Number (TIN) ...........490
▫ Tire Terminology And Definitions ..........492
▫ Tire Loading And Tire Pressure ...........493
 TIRES — GENERAL INFORMATION ........498
▫ Tire Pressure ....................... .498
338 STARTING AND OPERATING

▫General Information ...................525
 FUEL REQUIREMENTS ..................526
▫ 3.6L And 4.7L Engine ...................526
▫ 5.7L Engine ......................... .526
▫ Reformulated Gasoline .................527
▫ Gasoline/Oxygenate Blends ..............527
▫ E-85 Usage In Non-Flex Fuel Vehicles .......527
▫ MMT In Gasoline .....................528
▫ Materials Added To Fuel ................529
▫ Fuel System Cautions ...................529
▫ Carbon Monoxide Warnings .............530
 FLEXIBLE FUEL (4.7L ENGINE ONLY) — IF
EQUIPPED .......................... .530▫
E-85 General Information ...............530
▫ Ethanol Fuel (E-85) ....................531
▫ Fuel Requirements ....................532
▫ Selection Of Engine Oil For Flexible Fuel Vehicles
(E-85) And Gasoline Vehicles .............533
▫ Starting ........................... .533
▫ Cruising Range ...................... .533
▫ Replacement Parts ....................533
▫ Maintenance ....................... .534
 ADDING FUEL ....................... .534
▫ Loose Fuel Filler Cap Message ............536
 VEHICLE LOADING ....................536
▫ Certification Label ....................536
340 STARTING AND OPERATING

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belt.
The starter should not be operated for more than 15-
second intervals. Waiting a few seconds between such
intervals will protect the starter from overheating.
WARNING!
Never leave children alone in a vehicle, or with access to
an unlocked vehicle. Leaving children in a vehicle
unattended is dangerous for a number of reasons. A
child or others could be seriously or fatally injured.
Children should be warned not to touch the parking
brake, brake pedal or the shift lever. Do not leave the
key fob in or near the vehicle, or in a location accessible
to children. A child could operate power windows, other
controls, or move the vehicle.
Normal Starting
Normal starting of either a warm or cold engine is
obtained without pumping or pressing the accelerator
pedal. Turn the key fob to the START position and release
when the engine starts. If the engine fails to start within
10 seconds, turn the key fob to the OFF position, wait five
seconds, then repeat the “Normal Starting” procedure.
Automatic Transmission
Start the engine with the shift lever in the NEUTRAL or
PARK position. Apply the brake before shifting into any
driving range.
NOTE: This vehicle is equipped with a transmission
shift interlocking system. The brake pedal must be
pressed to shift out of PARK.
342 STARTING AND OPERATING

Tip Start Feature
Do notpress the accelerator. Turn the ignition switch
briefly to the START position and release it. The starter
motor will continue to run but will automatically disen-
gage when the engine is running.
Keyless Enter-N-Go™
This feature allows the driver to oper-
ate the ignition switch with the push
of a button, as long as the Remote
Start/Keyless Enter-N-Go™ Key Fob
is in the passenger compartment.
Normal Starting
Using The ENGINE START/STOP Button
1. The transmission must be in PARK or NEUTRAL.
2. Press and hold the brake pedal while pressing the ENGINE START/STOP button once.
3. The system takes over and attempts to start the vehicle. If the vehicle fails to start, the starter will
disengage automatically after 10 seconds.
4. If you wish to stop the cranking of the engine prior to the engine starting, press the button again.
NOTE: Normal starting of either a cold or a warm
engine is obtained without pumping or pressing the
accelerator pedal.
5
STARTING AND OPERATING 343

To Turn Off The Engine Using ENGINE
START/STOP Button
1. Place the shift lever/shift selector in PARK, then pressand release the ENGINE START/STOP button.
2. The ignition switch will return to the OFF position.
3. If the shift lever/shift selector is not in PARK, the ENGINE START/STOP button must be held for two
seconds and vehicle speed must be above 5 mph
(8 km/h) before the engine will shut off. The ignition
switch position will remain in the ACC position until
the shift lever/shift selector is in PARK and the button
is pressed twice to the OFF position. If the shift
lever/shift selector is not in PARK and the ENGINE
START/STOP button is pressed once, the EVIC (if
equipped) will display a “Vehicle Not In Park” mes-
sage and the engine will remain running. Never leave
a vehicle out of the PARK position, or it could roll. NOTE:
If the ignition switch is left in the ACC or RUN
(engine not running) position and the transmission is in
PARK, the system will automatically time out after 30
minutes of inactivity and the ignition will switch to the
OFF position.
ENGINE START/STOP Button Functions – With
Driver ’s Foot OFF The Brake Pedal (In PARK Or
NEUTRAL Position)
The ENGINE START/STOP button operates similar to an
ignition switch. It has four positions, OFF, ACC, RUN
and START. To change the ignition switch positions
without starting the vehicle and use the accessories
follow these steps.
1. Starting with the ignition switch in the OFF position:
2. Press the ENGINE START/STOP button once to change the ignition switch to the ACC position (EVIC
displays “ACC”),
344 STARTING AND OPERATING

3. Press the ENGINE START/STOP button a second timeto change the ignition switch to the RUN position
(EVIC displays “RUN”),
4. Press the ENGINE START/STOP button a third time to return the ignition switch to the OFF position (EVIC
displays “OFF”).
Extreme Cold Weather (Below –20°F Or 29°C)
To ensure reliable starting at these temperatures, use of
an externally powered electric engine block heater (avail-
able from your authorized dealer) is recommended.
If Engine Fails To Start
If the engine fails to start after you have followed the
“Normal Starting” procedure, it may be flooded. Push
the accelerator pedal all the way to the floor and hold it
there while cranking the engine. This should clear any
excess fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
WARNING!
•Never pour fuel or other flammable liquids into
the throttle body air inlet opening in an attempt to
start the vehicle. This could result in a flash fire
causing serious personal injury.
• Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
mission cannot be started this way. Unburned fuel
could enter the catalytic converter and once the
engine has started, ignite and damage the converter
and vehicle.
(Continued)
5
STARTING AND OPERATING 345

WARNING!(Continued)
•If the vehicle has a discharged battery, booster
cables may be used to obtain a start from a booster
battery or the battery in another vehicle. This type
of start can be dangerous if done improperly. Refer
to “Jump Starting” in “What To Do In Emergen-
cies” for further information.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the igni-
tion button/key is released. If this occurs, continue
cranking with the accelerator pedal pushed all the way to
the floor. Release the accelerator pedal and the ignition
button/key once the engine is running smoothly.
If the engine shows no sign of starting after two 15-
second periods of cranking with the accelerator pedal
held to the floor, the “Normal Starting” procedure should
be repeated.
After Starting
The idle speed is controlled automatically and it will
decrease as the engine warms up.
STOP/START SYSTEM — IF EQUIPPED
The Stop/Start function is developed to save fuel and
reduce emissions. The system will stop the engine auto-
matically during a vehicle stop if the required conditions
are met. Releasing the brake pedal will automatically
re-start the vehicle.
Automatic Mode
The Stop/Start feature is enabled after every normal
customer engine start. It will remain in STOP/START
NOT READY until you drive forward with a vehicle
speed greater than 5 mph (8 km/h). At that time, the
system will go into STOP/START READY and if all other
conditions are met, can go into an STOP/START AUTO
STOP ACTIVE “Autostop” mode.
346 STARTING AND OPERATING

To Activate The Autostop Mode, The Following Must
Occur:
1. The system must be in STOP/START READY state. ASTOP/START READY message will be displayed in
the Electronic Vehicle Information Center (EVIC)
within the Stop/Start section. Refer to “Electronic
Vehicle Information Center (EVIC)” in “Understand-
ing Your Instrument Panel” for further information.
2. The vehicle must be completely stopped.
3. The transmission Gear Selector must be in Drive and the brake pedal depressed.
The engine will shut down, the tachometer will move to
the zero position and the stop/start telltale will illumi-
nate indicating you are in an Autostop. While in an Autostop, the Climate Controls system may automati-
cally adjust airflow to maintain cabin comfort. Customer
settings will be maintained upon return to an engine
running condition.
Possible Reasons The Engine Does Not AUTO
STOP
Prior to engine shut down, the system will check many
safety and comfort conditions to see if they are fulfilled.
In following situations the engine will not stop:
•
Driver ’s seat belt is not buckled
• Driver ’s door is not closed
• Outside temperature is less than 1°F (–17°C) or greater
than 104°F (40°C)
• Battery temperature too warm or cold
• The vehicle is on a steep grade5
STARTING AND OPERATING 347
