2013 Ram 2500 seat adjustment

Manual Seat Adjuster — If Equipped
Both front seats are adjustable forward or rearward. The
manual seat adjustment handle is located under the seat
cushion at the front edge of each seat.
While sitting in the seat, pull up on the handle and slide
the seat forward or backward. Release the bar once youhave reached the desired position. Then, using body
pressure, move forward and rearward on the seat to be
sure that the seat adjusters have latched.
WARNING!
•
Adjusting a seat while driving may be dangerous.
Moving a seat while driving could result in loss of
control which could cause a collision and serious
injury or death.
• Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious
injury or death could result from a poorly adjusted
seat belt.
Manual Seat Adjuster
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
The head restraints for all occupants must be prop-
erly adjusted prior to operating the vehicle or occu-
pying a seat. Head restraints should never be ad-
justed while the vehicle is in motion. Driving a
vehicle with the head restraints improperly adjusted
or removed could cause serious injury or death in the
event of a collision.
Front Head Restraints
To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, press the adjust-
ment button, located on the base of the head restraint,
and push downward on the head restraint.
Rear Head Restraints
The rear seats are equipped with adjustable head re-
straints. To raise the head restraint, pull upward on the
head restraint. To lower the head restraint, press the
adjustment button, located on the base of the head
restraint, and push downward on the head restraint.
Adjustment Button
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:
•The rear center head restraint (Crew Cab and Quad
Cab) has only one adjustment position that is used to
aid in the routing of a tether. Refer to “Occupant
Restraints” in “Things to Know Before Starting Your
Vehicle” for further information. •
The head restraints should only be removed by quali-
fied technicians, for service purposes only. If either of
the head restraints require removal, see your autho-
rized dealer.
DRIVER MEMORY SEAT — IF EQUIPPED
This feature allows the driver to store up to two different
memory profiles for easy recall through a memory
switch. Each memory profile contains desired position
settings for the driver seat, side mirrors, adjustable
pedals (if equipped) and a set of desired radio station
presets. Your Remote Keyless Entry (RKE) transmitter
can also be programmed to recall the same positions
when the UNLOCK button is pressed.
NOTE: Your vehicle is equipped with two RKE trans-
mitters. One RKE transmitter can be linked to memory
position 1 and the other transmitter can be linked to
memory position 2.
Adjustment Button
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151

•The pedals cannotbe adjusted when the vehicle is in
REVERSE or when the Electronic Speed Control Sys-
tem is on. The following messages will be displayed on
vehicles equipped with the Electronic Vehicle Informa-
tion System (EVIC) if the pedals are attempted to be
adjusted when the system is locked out (“Adjustable
Pedal Disabled — Cruise Control Engaged” or “Ad-
justable Pedal Disabled — Vehicle In Reverse”.
NOTE:
• Always adjust the pedals to a position that allows full
pedal travel.
• Further small adjustments may be necessary to find
the best possible seat/pedal position.CAUTION!
Do not place any article under the adjustable pedals
or impede its ability to move as it may cause damage
to the pedal controls. Pedal travel may become lim-
ited if movement is stopped by an obstruction in the
adjustable pedal’s path.
WARNING!
Do not adjust the pedals while the vehicle is moving.
You could lose control and have an accident. Always
adjust the pedals while the vehicle is parked.
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Replacement Bulbs....................... .686
Replacement Keys .........................19
Replacement Parts ........................ .641
Replacement Tires ........................ .507
Reporting Safety Defects ....................717
Restraint, Head .......................... .149
Restraints, Child ...........................82
Restraints, Occupant ........................46
Rotation, Tires ............................511
Safety Checks Inside Vehicle ..................118
Safety Checks Outside Vehicle ................120
Safety Defects, Reporting ....................717
Safety, Exhaust Gas ........................117
Safety Information, Tire .....................487
Safety Tips ..............................116
Schedule, Maintenance .....................704
Seat Belt Maintenance ..................... .673
Seat Belt Reminder .........................62 Seat Belts
................................46
Adjustable Upper Shoulder Anchorage .........58
And Pregnant Women .....................63
Child Restraint ..........................82
Extender ..............................63
Front Seat .............................50
Inspection ............................118
Pretensioners ...........................62
Reminder ............................ .259
Untwisting Procedure .....................58
Seats ................................. .136
Adjustment .......................... .136
Folding Floor ......................... .223
Memory ............................. .151
Power .............................. .137
Rear Folding ......................... .146
Reclining Rear ........................ .145
Security Alarm (Theft Alarm) ..................21
Selection of Coolant (Antifreeze) ...............698
734 INDEX
