2013 Peugeot 508 RXH run flat

4
125
Driving

Automatic release

The electric parking brake releases automatically and progressively with the
movement of the vehicle,select position A, Mor Rthen press the accelerator.
Full release of the parking brake is confirmed by:
- the brakin
g warning lamp and of
the Pwarning lamp in the control lever A
going off,
- displa
y of a message.


When stationary, with the hybrid system active, do not press the accelerator pedal unnecessarily, as you may release the parking brake.
Before leaving the vehicle, check thatparking brake warning lamps in theinstrument panel and the control lever Aare on fixed, not flashing.


Immobilising the vehicle,
hybrid system active
With the hybrid system active and the vehicle
stationary, in order to immobilise the vehicle it is essential to manually
apply the parking
brake by pulling
control lever A.
The application of the parking brake is confirmed by:


- illumination o
f the braking warning
lamp and of the Pwarning lamp in
the control lever A ,

- displa
y of a message.
When the driver’s door is opened, a loud beep
is heard and a message is displayed if theparking brake has not been applied.
Particular situations

In cer tain situations (e.g. star ting the engine),
the parking brake can automatically alter itsforce. This is normal operation.
To advance your vehicle a few centimetres
without star ting the engine, but with the ignition on, press on the brake pedal and release the
parking brake by pushing then releasingcontrol lever A
. The full release of the parking
brake is confirmed by the warning lamps in
the control lever Aand in the instrument panel going off and display of a message.
If a parking brake fault occurs while appliedor
if the battery runs flat, an emergency release is
always possible.
In order to ensure correct operation and
so your safety, the number of successive
application/release operations of the parkin
g
brake is limited to eight.
In the event of abuse, you are aler ted by a
message and a warning lamp which flashes.

188
Practical information
2. Infl ation )
Connect the compressor's electric plug to
the vehicle's 12 V socket.) Star t the vehicle again and leave the engine running.

)Adjust the pressure using the compressor (to inflate: switch B
in position "I"
; to deflate: switch B
in position "O"and press button C), in accordance with the vehicle's
tyre pressure label (located on the left hand
door aperture).
A loss of pressure indicates that thepuncture has not been fully plugged; contact a PEUGEOT dealer or qualified
workshop for assistance.)Remove and stow the kit.)Drive at reduced speed (50 mph [80 km/h] max) limiting the distance travelled to
approximately 120 miles (200 km).




As soon as possible, go to a PEUGEOTdealer or a qualified workshop.You must inform the technician that you have used this kit. After inspection, the technician will advise you on whether
the tyre can be repaired or if it must be replaced.
)Turn the selector Ato the "air" position.)Uncoil the black pipe Hfully. )Connect the black pipe to the
valve of the wheel.

8
189
Practical information

Removing the cartridge
)Stow the black pipe. )Detach the angled base from the white pipe.)Suppor t the compressor ver tically.)Unscrew the car tridge from the bottom.
Beware of discharges of fluid.
The expiry date of the fluid is indicated on the car tridge.
The sealant car tridge is designed for single use; even if only partly used, itmust be replaced. After use, do not discard the car tridgeinto the environment, take it to an authorised waste disposal site or a PEUGEOT dealer.
Do not forget to obtain a new sealantcartridge, available from PEUGEOT dealers or from a qualified workshop.

Checking tyre pressures /
inflating accessories
You can also use the compressor, withoutinjecting any product, to:
- check or adjust the pressure of your tyres,
- inflate other accessories (balls, bicycle
tyres...).

)
Turn the selector Ato the "Air"
position.
) Uncoil the black pipe H
fully.)
Connect the black pipe to the
valve of the wheel or accessory.
If necessary, fit one of the adaptorssupplied with the kit first.
) Connect the compressor's electrical connector to the vehicle's 12 V socket. )
Star t the vehicle and let the engine run. )
Adjust the pressure using the compressor (to inflate: switch B
in position "I"
; to deflate: switch B
in position "O"and press button C), according to the vehicle's tyrepressure label or the accessory's pressure
label. ) Remove the kit then stow it.

8
195
Practical information





Snow chains


In wintry conditions, snow chains improve traction as well as the behaviour of the vehicle when
braking.
Take account of the legislation in force in your country on the use of snowchains and the maximum running speedauthorised.

The snow chains must be fitted only to the front wheels. They must never be fitted to "space-saver" type sparewheels.
For more in
formation on snow chains, contact a PEUGEOT dealer or a qualified workshop.

Advice on installation
)
If you have to fit the chains during ajourney, stop the vehicle on a flat sur face on the side of the road.)
Apply the parking brake and position anywheel chocks to prevent movement of your
vehicle. ) Fit the chains following the instructions provided by the manufacturer.)
Move off gently and drive for a few moments, without exceeding 30 mph(50 km/h). )
Stop your vehicle and check that the snowchains are correctly tightened.


Avoid driving on roads that have beencleared of snow, to avoid damaging your vehicle's tyres and the road surface. It is recommended that before you leave,you practise fitting the snow chains ona level and dry surface. If your vehicleis fitted with alloy wheels, check thatno par t of the chain or its fixings is incontact with the wheel rim.
Use onl
y the chains designed to be fitted to the
type of wheel fitted to your vehicle:
Original tyre size Maximum link size.
225/55 R17
9 mm
24
5/45 R18

208
Practical information
Starting using another
battery
)Remove the plastic cover from the (+)
terminal, if your vehicle has one. )Connect the red cable to the positive
terminal (+) of the flat battery A , then to the positive terminal (+) of the slave battery B.)Connect one end of the green or blackcable to the negative terminal (-) of the
slave battery B(or ear th point on the other
vehicle).)Connect the other end of the green or black cable to the ear th point Con the broken
down vehicle (or on the engine mounting).)Star t the engine of the vehicle with the good battery and leave it running for a fewminutes.

First check that the slave battery has a nominal voltage of 12 V and a capacityat least equal to that of the discharged battery. Do not try to star t the engine by connecting a battery charger.
Do not disconnect the (+) terminal when the engine is running. When
your vehicle's battery is discharged, theengine can be star ted using a slave battery(external or on another vehicle) and jump lead cables.
) Operate the star ter on the broken down
vehicle and let the engine run
If the engine does not star t straight away, switch off the ignition and wait a few
moments before trying again.) Wait until the engine returns to idle then
disconnect the jump lead cables in the
r
everse order.
) Refit the plastic cover to the (+) terminal, if your vehicle has one.

Do not disconnect the cables tooquickly; leave them connected for a fewminutes (until the engine returns to idle) other wise there is a risk that the battery would be under-charged, with the need then to repeat the operation.
Starting the vehicle when the battery is flat must be done with the electronickey inside the vehicle, the driver's door closed and the driver's seat belt buckled.

210
Practical information








Load reduction mode
System which manages the use of cer tain
functions according to the level of chargeremaining in the battery.
When the vehicle is being driven, the loadreduction function temporarily deactivates certain functions, such as the air conditioning,
the heated rear screen...
The deactivated functions are reactivated automatically as soon as conditions permit.
S
ystem which manages the duration of use of certain functions to conser ve a sufficient level of charge in the battery.
After the engine has stopped, you can still use functions such as the audio and telematics
system, windscreen wipers, dipped beam headlamps, cour tesy lamps, etc. for a maximumcombined duration of about forty minutes.






Energy economy mode


Switching to economy mode

A message then appears in the instrument
panel screen indicating that the vehicle has
switched to economy mode and the activefunctions are put on standby.
If a telephone call is being made at this time, it
will be maintained for around 10 minutes with
the Bluetooth hands-free system of your audio
system.


Exiting economy mode

These functions are reactivated automaticallynext time the vehicle is driven.)In order to restore the use of these functions immediately, star t the engine and let it run:
- for less than ten minutes, to use
the equipment for approximately
five minutes,
- for more than ten minutes, to use the
equipment for up to approximatel
y thirtyminutes.
Let the engine run for the duration specified toensure that the battery charge is sufficient.
Do not repeatedly and continuously restar t theengine in order to charge the battery.
A flat battery prevents the engine from star ting (refer to the "Battery" section).
In this energy economy mode and whenstarting up the hybrid system, it maytake a few seconds before the Readylamp comes on.
